INSTRUCTION MANUAL
BatteryMINDer
Charger / Maintainer / Desulfator
BatteryMINDer
12-Volt Maintenance Charger
with Full-Time Desulfator
VDC Electronics, Inc.
147D Woodbury Rd.
Huntington, NY 11743
www.BatteryMINDers.com
techsupport@vdcelectronics.com
READ AND SAVE THESE
INSTRUCTIONS
Rev. C-091911
®
Model 2012
POWER
BATTERY
WEAK
Volts
BAD CELL
Amps
DESULFATING
VDC Electronics, Inc.
FOR LEAD-ACID BATTERIES ONLY
www.BatteryMINDers.com
Technical Support:
800-379-5579 x206 (ET)
Input: 100-240 VAC, 50/60 Hz, 0.65A
Output: 12 Volts @ 2.0 Amps
Developed in the U.S.A.
2000 Series
®
BATTERY
CONNECTION
LOAD
TESTING
TEMPERATURE
COMPENSATION
INCLUDES:
•
2' Fused Ring Terminal Cord
Set with Quick Connector
•
2' Battery Clip Cord Set with
Quick Connector
•
Ambient Temperature Sensor
P/N VDC2000-MNL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VDC Electronics BatteryMINDer 2000 Series
Summary of Contents for VDC Electronics BatteryMINDer 2000 Series
-
Page 1: Instruction Manual
WEAK LOAD Volts BAD CELL TESTING Amps TEMPERATURE DESULFATING COMPENSATION VDC Electronics, Inc. FOR LEAD-ACID BATTERIES ONLY www.BatteryMINDers.com Technical Support: 800-379-5579 x206 (ET) Input: 100-240 VAC, 50/60 Hz, 0.65A Output: 12 Volts @ 2.0 Amps Developed in the U.S.A. INCLUDES: •... -
Page 2: Table Of Contents
2000 Series BatteryMINDer ® TABLE OF CONTENTS Safety Instructions ..............3 - 7 Warning - Risk of Explosive Gases ..........4 Personal Precautions ..............4 Preparing to Charge ..............5 Charger Location ..............5 DC Connection Precautions ............6 Reduce Risk of a Spark Near Battery ..........6, 7 Operation Instructions ..............8 - 14 Indicator Light Table ............... -
Page 3: Safety Instructions
BatteryMINDer 2000 Series. Do not expose charger to rain or snow. Use of an attachment not recommended or sold by VDC Electronics may result in a risk of fire, electric shock, or injury to persons. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when disconnecting charger. -
Page 4: Warning - Risk Of Explosive Gases
Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way; call VDC Electronics Tech Support Dept. 800.379.5579 x206 (ET) for advice. Do not disassemble charger; call VDC Electronics Tech Support Dept. -
Page 5: Preparing To Charge
2000 Series BatteryMINDer ® part that may cause explosion. g) Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid battery. A lead-acid battery can produce a short-circuit current high enough to weld a ring or the like to metal, causing a severe burn. h) Use charger for charging a LEAD-ACID battery only. -
Page 6: Dc Connection Precautions
2000 Series BatteryMINDer ® e) Do not set a battery on top of charger. 14. DC CONNECTION PRECAUTIONS a) Connect and disconnect dc output clips only after setting any charger switches to “off” position and removing ac cord from electric outlet. Never allow clips to touch each other. b) Attach clips to battery and chassis as indicated in 15(e), 15(f), and 16(b) through 16(d). - Page 7 2000 Series BatteryMINDer ® h) See operating instructions for length of charge information. 16. FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE VEHICLE. A SPARK NEAR THE BATTERY MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK OF A SPARK NEAR BATTERY: a) Check polarity of battery posts. POSITIVE (POS, P, +) battery post usually has a larger diameter than NEGATIVE (NEG, N, –) post.
-
Page 8: Operation Instructions
2000 Series BatteryMINDer ® BatteryMINDer 2000 Series Label Indicator Light Table • Power A/C Power Connected • Battery Connection Battery Connected Correctly • Battery Connection Battery Connection Reversed • • Battery Required Soft Start Battery Weak • Battery Tests Under 12.5V •... -
Page 9: Quick Connect Instructions
2000 Series BatteryMINDer ® • Load Light Load Light Off Float Soft Start 0.5 A 2.0 A (Battery < 11V) Constant Float 2.0 A 2.0 A Current (Battery < 12V) Constant CV* (See Float 2.0 A Voltage Voltage Table) (Battery < 13V) Float (Charge FV* (See Float... -
Page 10: Indicator Light Details
2000 Series BatteryMINDer ® Float (sometimes called Maintenance) is the charger’s long term • stage. The charger can and should be left connected indefinitely. This will keep the battery fully charged ensuring no sulfate can form. The charger maintains float voltage FV* (See Voltage Table) using very little power as it actively monitors the battery and adjusts its output several times a second. -
Page 11: Temperature Compensation
2000 Series BatteryMINDer ® Desulfation light flashes BLUE • any time the unit is desulfating. The BatteryMINDer desulfates any time it is outputting current. • Temperature Compensation light is GREEN if the temperature BLUE is over 27°C/80°F, if the temperature is under 21°C/70°F. BatteryMINDer Model 2012 includes an ambient temperature sensor which allows it to vary the output voltage as necessary to properly charge your battery (-0.025 V/°C). -
Page 12: Voltage Table
2000 Series BatteryMINDer ® Voltage Table *CV : Voltage during the Constant Voltage stage *FV : Voltage during the Float stage. Model Battery Types Standard 2012 14.4V 1.4V (Flooded) 2012-GEL 14.1V 1.05V 2012-AGM 14.7V 1.6V 2012-CAL Calcium 15.16V 1.5V Specifications Table Input 100-240 VAC, 50/60 Hz, 0.65A Output... -
Page 13: Maintaining Multiple Batteries
2000 Series BatteryMINDer ® MAINTAINING MULTIPLE BATTERIES To properly charge or maintain multiple batteries they should all be the same type (gel, flooded or AGM) and condition. It is OK to mix deep cycle and starter. Charge each battery individually before connecting together. -
Page 14: Charging Profile
2000 Series BatteryMINDer ® Rev. C-091911 Page 14 P/N VDC2000-MNL... -
Page 15: Repair Or Replacement
FOR REPAIR OR REPLACEMENT All returns must be authorized by VDC Electronics. In the event that you believe your product may be defective, you MUST speak to a VDC Electronics technician at 1-800-379-5579 x206 (ET) before proceeding further. NOTES MODEL BatteryMINDer 20... -
Page 16: Warranty And Registration
IT WAS PURCHASED. BatteryMINDer Five-Year Limited Warranty VDC Electronics, Inc. warrants this product for FIVE years from date of purchase at retail against defective material or workmanship and will be repaired or replaced at no charge. We make no warranty other than this limited warranty and expressly exclude any implied warranty including any warranty for consequential damages.
