  • Page 1 User Manual Ed - Version: January 2013...
  • Page 2 For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com/eplatform For technical support and service, please visit our support website at: http://www.advantech.com/support This manual is for the PCM-9375. Part No. 2006937511 2nd Edition Printed in Taiwan Sep. 2007 PCM-9375 User Manual...
  • Page 3 - 1700002150 COM2 cable for RS-422/485 - 1703200201 ATX Power control cable • Floppy Disk module - 9696937580E PCM-9375 FDD module - 1701340700 Flat cable 34-pin for FDD - 170000212 2x LPT cable If any of these items are missing or damaged, contact your distributor or sales representative immediately.
  • Page 4 • Description of your peripheral attachments • Description of your software (operating system, version, application software, etc.) • A complete description of the problem • The exact wording of any error messages PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 5 Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recom- mended by the manufacturer. Discard used batter- Achtung! ies according to the manufacturer’s instructions Data Modul AG - www.data-modul.com...
  • Page 6 PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 7: Table Of Contents

    1.3.6 Mechanical and Environmental ........4 Board layout: dimensions..........5 Figure 1.1:Dimension of PCM-9375F ......5 Figure 1.2:Dimension of PCM-9375E......5 Figure 1.3:Dimension of PCM-9375 for H..... 6 Figure 1.4:PCM-9375 Mechanical Drawing(Solder side) Chapter 2 Installation ............8 Jumpers................8 Table 2.1:Jumpers............8 2.1.1...
  • Page 8 3.2.11 Save & Exit Setup............40 3.2.12 Quit Without Saving ............. 41 Chapter 4 PCI SVGA/LCD Setup ........44 Introduction ..............44 4.1.1 Display type ..............44 4.1.2 Dual Simultaneous Display ......... 44 PCM-9375 User Manual viii Data Modul AG - www.data-modul.com...
  • Page 9 Table A.11:IDE (CN11) ..........75 A.10 CRT (CN12)..............77 Table A.12:CRT (CN12) ..........77 A.11 USB1/2 (CN13), USB3/4 (CN15)........78 Table A.13:USB1/2 (CN13), USB3/4 (CN15) ..... 78 A.12 COM2/3/4 (CN16) ............79 Table A.14:COM2/3/4 (CN16)........79 Data Modul AG - www.data-modul.com...
  • Page 10 Appendix C Mechanical Drawings........94 Mechanical Drawings............94 Figure C.1:Dimension of PCM-9375F (TTL) ....94 Figure C.2:Dimension of PCM-9375E (LVDS) ... 95 Figure C.3:Dimension of PCM-9375 for H ....95 Figure C.4:PCM-9375 Mechanical Drawing(Solder side) Appendix D Watchdog Timer..........98 PCM-9375 User Manual...
  • Page 11 General Information This chapter gives background infor- mation on the PCM-9375. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Data Modul AG - www.data-modul.com...

  • Page 12: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Introduction The PCM-9375 is a fanless, best-cost, performance 3.5" SBC (Single Board Computer) geared to satisfy the needs for various industrial comput- ing equipment. PCM-9375 is ideal for communication, gaming and medical applications that require flat panel support using digital displays with TTL or LVDS interfaces and two Ethernet ports.

  • Page 13: Specifications

    • LCD Interface: Supports up to 24-bit TFT LCD (TTL signal) (PCM- 9375F) • LVDS Interface: Supports one channel 18-bit LVDS Interface (PCM- 9375E) • Dual Simultaneous Display: CRT + TTL LCD, CRT + LVDS Chapter 1 Data Modul AG - www.data-modul.com...

  • Page 14: Ethernet Interface

    • Audio interface: Microphone in, Line in, Line out, Speak out 1.3.5 OS support • This board supports Win XP, Win CE and Win XPe. • For further information about OS support in your PCM-9375, visit the following web resource Advantech: website: www.advantech.com or please contact technical support center 1.3.6 Mechanical and Environmental...

  • Page 15: Board Layout: Dimensions

    95.25 95.25 94.30 87.63 89.99 86.36 88.58 83.82 74.92 73.66 70.49 65.76 19.60 18.14 17.10 15.60 12.40 10.16 8.61 9.84 7.77 6.95 7.62 5.77 3.18 5.84 5.77 0.00 Figure 1.2: Dimension of PCM-9375E Chapter 1 Data Modul AG - www.data-modul.com...

  • Page 16: Figure 1.3:Dimension Of Pcm-9375 For H

    Figure 1.3: Dimension of PCM-9375 for H 92.93 53.98 0.00 Figure 1.4: PCM-9375 Mechanical Drawing(Solder side) PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 17 Installation This chapter explains the setup proce- dures of the PCM-9375 hardware, including instructions on setting jump- ers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Data Modul AG - www.data-modul.com...

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation 2.1 Jumpers The PCM-9375 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function AT/ATX Selector...

  • Page 19: Audio Power (J4)

    Table 2.5: Audio Power (J4) Setting Function 1-2* With + 12 v Without + 12 V *: default 2.1.5 TV enable (J5) Table 2.6: TV enable Setting Function 1-2* TV Enable NONE TV Disable *: default Chapter 2 Data Modul AG - www.data-modul.com...

  • Page 20: Connectors

    2.2 Connectors Onboard connectors link the PCM-9375 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the func- tion of each of the board’s connectors. Table 2.7: Connectors Label Function Stand-by Power Input...

  • Page 21: Locating Connectors

    2.3 Locating Connectors Figure 2.1: Connectors (component side) Figure 2.2: Connectors (solder side) Chapter 2 Data Modul AG - www.data-modul.com...

  • Page 22: Setting Jumpers

    If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 23: Installing So-Dimm

    Push the module into the socket until the module bottoms. There should be a slight insertion force to engage the module into the con- tacts. Chapter 2 Data Modul AG - www.data-modul.com...

  • Page 24: Ide, Cdrom Hard Drive Connector (Cn11)

    The parallel port is designated as LPT1, and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup. The parallel port interrupt channel is designated to be IRQ7. You can select ECP/EPP DMA channel via BIOS setup. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 25: Keyboard And Ps/2 Mouse Connector (Cn14)

    10 mA, 5 V. 2.11 Power connectors (CN2) 2.11.1 Main power connector, +5 V, +12 V (CN2) Supplies main power to the PCM-9375 (+5 V), and to devices that require +12 V. 2.11.2 ATX Feature connector (CN1, CN8) The PCM-9375 can support ATX power supply by CN1 connector as well as J1 jumper setting.

  • Page 26: Audio Interfaces (Cn22)

    Serial port can be configured to operate in RS-422 and RS-485 mode. This is done via using connector CN18 and setting jumper J3. Table 2.8: Serial Port RS-422/485 (J3) Setting Function RS-232 RS-485 RS-422 PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 27: Vga/Lcd/Lvds Interface Connections

    An onboard watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause. This is an invalu- able protective device for standalone or unmanned applications. Setup involves one jumper and running the control software (refer to Appendix Chapter 2 Data Modul AG - www.data-modul.com...

  • Page 28: Usb Connectors (Cn13,Cn15)

    The board supports 8-bit GPIO through GPIO connector. The 8 digital inputs and outputs can be programmed to read or control devices, with each input or output defined. The default setting is 8 bits input. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 29 BIOS Operation Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 30: Chapter 3 Bios Operation

    You can use Advantech’s utilities to select and install features to suit your own designs. 3.2 BIOS Setup The PCM-9375 Series system has build-in Award BIOS with a CMOS SETUP utility which allows user to configure required settings or to acti- vate certain system features.

  • Page 31: Main Menu

    This setup page includes all the items of Award BIOS enhanced fea tures. • Advanced Chipset Features This setup page includes all the items of Chipset configuration features. • Integrated Peripherals This setup page includes all onboard peripheral devices. • Power Management Setup Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 32 Establish, change or disable password. • Save & Exit Setup Save CMOS value settings to CMOS and exit BIOS setup. • Exit Without Saving Abandon all CMOS value changes and exit BIOS setup. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 33: Standard Cmos Features

    The Item identifies the types of floppy disk drive A or drive B. None No floppy drive installed 360K, 5.25" 5.25 inch PC-type standard drive; 360K byte capacity 1.2M, 5.25" 5.25 inch AT-type high-density drive; 1.2M byte capacity Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 34 The POST of the BIOS will determine the amount of extended memory (above 1MB in CPU’s memory address map) installed in the system. • Total Memory This item displays the total system memory size. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 35: Advanced Bios Features

    USB-ZIP Select boot device priority by USB-ZIP. USB-CD ROM Select boot device priority by USB-CDROM. USB-HDD Select boot device priority by USB-HDD. Select boot device priority by LAN. Disabled Disable this boot function. Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 36 • Video BIOS Shadow [Enabled] Enabled copies Video BIOS to shadow RAM improves performance C8000-CBFFF Shadow [Disabled] It’s for shadow control of item. CC000-CFFFF Shadow [Disabled] It’s for shadow control of item. D0000-D3FFF Shadow [Disabled] PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 37 [Disabled] • Small Logo (EPA) Show [Enabled] Show EPA logo during system post stage • Cyrix 6X86/MII CPUID [Enabled] This item allows user to control bios enabled or disabled CPUID for CPU Cyrix/MII. Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 38: Advanced Chipset Features

    • Flat Panel Configuration [Press Enter] (Show Only) This item is provided Flat panel function for user to adjustment. • Onboard Audio [Enabled] This item is controller to enabled or disabled motherboard of audio device. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 39 [Disabled] This item is enabled or disabled that usb overcurrent report function. Bios default suggest to Disabled. • Port 4 assignment [Host] This item allows user to changed USB port 4 of mode. Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 40: Integrated Peripherals

    Bios default value suggest to “Auto”. • IDE DMA transfer access [Enabled] This item allows user to adjust IDE DMA mode. It will increase IDE Data transfer of speed. Bios default value suggest to “Enabled”. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 41 This item allows user to change com 3 of address. Bios default value suggest to “3E8”. • Onboard Serial Port 3 use [IRQ10] This item allows user to change com 3 of IRQ. Bios default value sug- gest to “IRQ10”. Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 42 Port).ECP(Extended Capabilities Port). EPP(Enhanced Parallel Port). Bios default value suggest to “Normal”. • ECP Mode Use DMA This item allows user to change DMA channel for parallel port. Bios default value suggest to “3”. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 43: Power Management Setup

    This item allows user to select standby of time. Range from 1 sec to 120 Min. • Suspend Mode [Disabled] This item allows user to select suspend of time. Range from 1 sec to 120 Min. Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 44 • WDT Time-out Value Unit [Minutes] This item allows user to choose watch dog timer of unit. • WDT Time-out Value [00] This item determines which count times for watch dog timer. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 45: Pnp/Pci Configurations

    This item allows you respectively assign a memory block from N/A to DC00. • PCI VGA Palette Snoop [Disabled] The item is designed to solve problems caused by some non-standar d VGA cards. A built-in VGA system does not need this function. Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 46: Pc Health Status

    60°C through 70°C. • Current System/CPU Temp [Show Only] This item displays current system and CPU temperature. • 3.3V / 5V / 12V [Show Only] This item displays current CPU and system Voltage. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 47: Load Optimized Defaults

    NOTE: Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable). These defaults will load automatically when you turn the PCM-9375 Series system on. Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 48: Set Password

    1. Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. 2. When you see “Enter Password”, enter the existing password and press <Enter>. 3. You will see “Confirm Password”. Type it again, and press <Enter>. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 49 4. Select Set Password again, and at the “Enter Password” prompt, please don’t enter anything; just press <Enter>. 5. At the “Confirm Password” prompt, again, don’t type in anything; just press <Enter>. 6. Select Save to CMOS and EXIT, type <Y>, then <Enter>. Chapter 3 Data Modul AG - www.data-modul.com...

  • Page 50: Save & Exit Setup

    3.2.11 Save & Exit Setup NOTE: Type “Y” will quit the BIOS Setup Utility and save user setup value to CMOS. Type “N” will return to BIOS Setup Utility. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 51: Quit Without Saving

    3.2.12 Quit Without Saving NOTE: Type “Y”will quit the BIOS Setup Utility without saving to CMOS. Type “N” will return to BIOS Setup Utility. Chapter 3 Data Modul AG - www.data-modul.com...
  • Page 52 PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 53 The AWARD System BIOS is covered in Chapter 4. Sections include: • Installation of SVGA drivers - for Window XP • Connections for standard LCDs • Further information Data Modul AG - www.data-modul.com...

  • Page 54: Chapter 4 Pci Svga/Lcd Setup

    Chapter 4 PCI SVGA/LCD Setup 4.1 Introduction PCM-9375 has an onboard AMD Geode LX800 chipset for its AGP/ SVGA controller. It supports TFT LCD displays and conventional analog CRT monitors with 64 MB frame buffer shared with system memory. The...

  • Page 55: Connections To Two Standard Lcds

    4.2 Connections to Two Standard LCDs Connector Table of 12.1" TTL Sharp LQ121S1DG31 800 x 600 5/3.3 V (18 Bit) for PCM-9375 AMD Geode LX. AMD Geode LX 4.2.1 Table 4.1: Connections to Sharp LQ121S1DG31 / PCM-9375 Sharp LQ121S1DG31 PCM-9375 DF9MA-41P-1V DF-13 4OP-1.25V...
  • Page 56 Table 4.1: Connections to Sharp LQ121S1DG31 / PCM-9375 ENAB +3.3 V +3.3 V * The polarity of both synchronous signals are negative. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 57: Installation Of The Vga And Aes Driver

    2. For convenience, the CD-ROM drive is designated as "D" throughout this chapter. 4.3.1 Installation chipset AES driver 1. Open device manager, right click on entertainment then, click on prop- erties Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 58 2. Go to driver page and click on update driver. 3. Click on install from specific folder and click on next. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 59 4.Click on browse and select target folder, then, click OK. 5.Click on next. Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 60 6. Click on finish. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 61: Installation Of Vga Driver

    4.3.2 Installation of VGA driver 1. Right click on video, and click “ Properties”. 2. Go to driver page and click on update driver. Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 62 3. Click on install from specific folder and click on next. 4. Click on browse and select target folder, then click OK. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 63 5. Click on next, then click on finish. 6. Then click on continue anyway. Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 64 7. Click on finish. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 65: Pci Bridge

    The system may detect the PCI bridge automatically. If the question mark is shown on device manager, please install the driver as below: 1. Click “Add Hardware Wizard” and add new hardware wizard Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 66 2. Search the right directory of PCI bridge for IT8888G driver. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 67: Further Information

    4.4 Further Information For further information about the AGP/VGA installation of your PCM- 9375, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: AMD website: www.AMD.com Advantech websites: www.advantech.com www.advantech.com.tw Chapter 4 Data Modul AG - www.data-modul.com...
  • Page 68 PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 69 Audio Setup The board is equipped with an audio interface that records and plays back CD-quality audio. This chapter pro- vides instructions for installing the soft- ware drivers included on the audio driver diskettes. Data Modul AG - www.data-modul.com...

  • Page 70: Chapter 5 Audio Setup

    The files on the software installation diskette are compressed. Do not attempt to install the drivers by copying the files manually. You must use the sup- plied SETUP program to install the drivers. PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 71: Windows Xp Drivers

    5.2.2 Windows XP drivers Open device manager, right click on audio and click on “proper- ties”. Go to driver page and click on update driver. Chapter 5 Data Modul AG - www.data-modul.com...
  • Page 72 Click on install from specific folder and click on next. Click on browse and select target folder, then click OK. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 73 Click on next. Click on continue anyway. Chapter 5 Data Modul AG - www.data-modul.com...
  • Page 74 Click on finish. Notes: The Audio driver is provided by AMD, do not down- load other audio drivers from Realtek website. PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 75 • ATX Power Button • GPIO • CF • IDE • CRT • USB1/2, USB3/4 • COM2/3/4 • Print Port • RS-422/485 • COM1 • ISA - 5 V & - 12 V • Audio • LAN1/LAN2 Data Modul AG - www.data-modul.com...

  • Page 76: Appendix A Pin Assignments

    Signal Type +5 VSB A.2 Power Input (CN2) Table A.2: Power Input (CN2) Part Number: 1655204030 Description: Housing 5.08mm 4P 180D Male w/o Lock Pin Name Signal Type +12 V +5 V PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 77: Reset Button (Cn3)

    Signal Type A.4 TFT LCD (CN4) Table A.4: TFT LCD (CN4) (PCM-9375F) Part Number: 1653920200 Description: *CONN. DF13-40DP-1.25 V Pin Name Signal Type +5 V +5 V +3.3 V +3.3 V TV-CLK CLK48M Appendix A Data Modul AG - www.data-modul.com...
  • Page 78 Table A.4: TFT LCD (CN4) (PCM-9375F) Part Number: 1653920200 Description: *CONN. DF13-40DP-1.25 V Pin Name Signal Type DOTCLK PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 79 DRGB2 DRGB3 DRGB4 DRGB5 DRGB6 DRGB7 DRGB8 DRGB9 DRGB10 DRGB11 DRGB12 DRGB13 DRGB14 DRGB15 DRGB16 DRGB17 DRGB18 DRGB19 DRGB20 DRGB21 DRGB22 DRGB23 DOTCLK HSYNC HSYNC HSYNC VSYNC VSYNC VSYNC LDEMOD VDDEN ENLVDD ENLVDD Appendix A Data Modul AG - www.data-modul.com...
  • Page 80 LVDS0-D1+ LVDS LVDS1-D1+ LVDS LVDS0-D1- LVDS LVDS1-D1- LVDS LVDS0-D2+ LVDS LVDS1-D2+ LVDS LVDS0-D2- LVDS LVDS1-D2- LVDS LVDS0-CLK+ LVDS LVDS1-CLK+ LVDS LVDS0-CLK- LVDS LVDS1-CLK- LVDS V-LCD +5 Vor+3.3 V V-LCD +5 Vor+3.3 V PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 81: Inverter Power (Cn5)

    Table A.7: Inverter Power (CN5) Part Number: 1655305020 Description: Wafer box 2.0mm 5P 180D Male w/Lock Pin Name Signal Type Signal Level +12 V +12 V ENABKL +3.3 V +3.3 V +5 V +5 V Appendix A Data Modul AG - www.data-modul.com...

  • Page 82: Atx Power Button (Cn8)

    PWRBTN# A.7 GPIO (CN9) Table A.9: GPIO (CN9) Part Number: 1653005261 Description: Pin Header SMD 5*2P 180D(M) 2.0mm Pin Name Signal Type +5 V GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 83: Cf (Cn10)

    A.8 CF (CN10) Table A.10: CF (CN10) Part Number: 1653025211 Description: Header for CF Type I 50P 90D(M) Standoff 2.0mm Pin Name Signal Type CS#1 +5 V Appendix A Data Modul AG - www.data-modul.com...
  • Page 84 Table A.10: CF (CN10) Part Number: 1653025211 Description: Header for CF Type I 50P 90D(M) Standoff 2.0mm Pin Name Signal Type IOCS16# CS#3 IOR# IOW# IRQ15 +5 V RST# IORDY DREQ DACK# PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 85: Ide (Cn11)

    A.9 IDE (CN11) Table A.11: IDE (CN11) Part Number: 1653222262 Description: Box Header SMD 22*2P 180D(M) 2.0mm Pin Name Signal Type RST# DREQ IOW# Appendix A Data Modul AG - www.data-modul.com...
  • Page 86 Table A.11: IDE (CN11) Part Number: 1653222262 Description: Box Header SMD 22*2P 180D(M) 2.0mm Pin Name Signal Type IOR# IORDY CSEL# DACK# IRO14 D66DET# CS#1 CS#3 ASP# +5 V +5 V PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 87: Crt (Cn12)

    A.10 CRT (CN12) Table A.12: CRT (CN12) Part Number: 1654515304 Description: D-SUB CONN. 15P 90D(F) DIP 5mm Blue Pin Name Signal Type +5 V DDAT OD I/O HSYNC VSYNC DCLK OD I/O Appendix A Data Modul AG - www.data-modul.com...

  • Page 88: Usb1/2 (Cn13), Usb3/4 (Cn15)

    A.11 USB1/2 (CN13), USB3/4 (CN15) Table A.13: USB1/2 (CN13), USB3/4 (CN15) Part Number: 1653005260 Description: Pin Header 5*2P 180D(M) 2.0mm SMD Pin Name Signal Type +5 V +5 V PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 89: Com2/3/4 (Cn16)

    A.12 COM2/3/4 (CN16) Table A.14: COM2/3/4 (CN16) Part Number: 1653000221 Pin Name Signal Type DCD#2 DSR#2 RXD#2 RTS2 TXD2 CTS#2 DTR#2 RI#2 DCD#3 DSR#3 RXD3 RTS#3 TXD3 CTS#3 DTR#3 RI#3 DCD#4 DSR#4 RXD4 RTS#4 TXD4 Appendix A Data Modul AG - www.data-modul.com...
  • Page 90 Table A.14: COM2/3/4 (CN16) Part Number: 1653000221 Pin Name Signal Type CTS#4 DTR#4 RI#4 PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 91: Print Port (Cn17)

    A.13 Print Port (CN17) Table A.15: Print Port (CN17) Part Number: 1653000272 Description: Box Header SMD 13*2P 180D(M) 2.0mm Pin Name Signal Type STB# AFD# ERR# INIT# SLIN# ACK# BUSY Appendix A Data Modul AG - www.data-modul.com...
  • Page 92 Table A.15: Print Port (CN17) Part Number: 1653000272 Description: Box Header SMD 13*2P 180D(M) 2.0mm Pin Name Signal Type SLCT PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 93: Rs-422/485 (Cn18)

    485-422-TXD+ 485-422-TXD- A.15 COM1 (CN19) Table A.17: COM1 (CN19) Part Number: 1654409108 Description: D-SUB CONN 9P 90D(M) DIP 5mm GRN 225A- 09MSPBBB6 Pin Name Signal Type DCD# RXD# TXD# DTR# DSR# RTS# CTS# Appendix A Data Modul AG - www.data-modul.com...

  • Page 94: 12 V Input (Cn21)

    A.16 ISA -5 V & -12 V Input (CN21) Table A.18: ISA -5 V & -12 V Input (CN21) Part Number: 1653003101 Description: Pin Header 3*1P 180D(M) SQUARE 2.0mm Pin Name Signal Type -12 V -5 V PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 95: Audio (Cn22)

    A.17 Audio (CN22) 14 16 13 15 Table A.19: Audio (CN22) Part Number: 1653008260 Description: Pin Header 8*2P 180D SMD Male SQUARE PIN 2.0mm Pin Name Signal Type LOUT LOUT MIC2 MIC1 Appendix A Data Modul AG - www.data-modul.com...

  • Page 96: Lan1 (Cn23)

    A.18 LAN1 (CN23) Table A.20: LAN1 (CN23) Part Number: 1652508200 Description: Phone Jack RJ-45 8P 90D(F) DIP 677-088-D06 Pin Name Signal Type LAN1-TX+ LAN1-TX- LAN1-RX+ LAN1-LCT LAN1-LCT LAN1-RX- LAN1-LCT LAN1-LCT PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 97: Lan2 (Cn24)

    A.19 LAN2 (CN24) Table A.21: LAN2 (CN24) Part Number: 1653205260 Description: Box Header SMD 5*2 180D (M) 2.0mm Pin Name Signal Type +3.3 V LAN2-ACTLED LAN2-RX+ LAN2-RX- LAN2-LILED LAN2-LCT LAN2-LCT LAN2-TX+ LAN2-TX- Appendix A Data Modul AG - www.data-modul.com...
  • Page 98 PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 99 System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Data Modul AG - www.data-modul.com...

  • Page 100: Appendix B System Assignments

    Serial port 2 378-37F Parallel printer port 1 (LPT 2) 3B0-3BF Monochrome display and printer adapter (LPT1) 3D0-3DF Color/graphics monitor adapter 3E8-3EF Reserved (Series port 3) 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 101: 1St Mb Memory Map

    Floppy disk (8-bit transfer) Available (parallel port) Cascade for DMA controller 1 Available Available Available * Audio DMA select 1, 3, or 5 ** Parallel port DMA select 1 (LPT2) or 3 (LPT1) Chapter B Data Modul AG - www.data-modul.com...

  • Page 102: Interrupt Assignments

    Reserved (COM4) IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10 Reserved (COM3) IRQ 11 Reserved IRQ 12 PS/2 mouse IRQ 13 INT from co-processor IRQ 14 Primary IDE PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 103 Mechanical Drawings Data Modul AG - www.data-modul.com...

  • Page 104: Appendix C Mechanical Drawings

    94.30 87.63 89.99 86.36 88.58 83.82 74.92 73.66 70.49 65.76 19.60 18.14 17.10 15.60 12.40 10.16 8.61 9.84 7.77 6.95 7.62 5.77 3.18 5.84 5.77 0.00 Figure C.1: Dimension of PCM-9375F (TTL) PCM-9375 User Manual Data Modul AG - www.data-modul.com...

  • Page 105: Figure C.2:Dimension Of Pcm-9375E (Lvds)

    74.92 73.66 70.49 65.76 19.60 18.14 17.10 15.60 12.40 10.16 8.61 9.84 7.77 6.95 7.62 5.77 5.84 3.18 5.77 0.00 Figure C.2: Dimension of PCM-9375E (LVDS) Figure C.3: Dimension of PCM-9375 for H Appendix C Data Modul AG - www.data-modul.com...
  • Page 106 92.93 53.98 0.00 Figure C.4: PCM-9375 Mechanical Drawing(Solder side) PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 107 Watchdog Timer Data Modul AG - www.data-modul.com...

  • Page 108: Appendix D Watchdog Timer

    .model small .486p .stack 256 .data SCH3114_IO EQU 800h .code 100h .STARTup ;=================================================== ;47H ;enable WDT function bit [3:2]=11 ;=================================================== mov dx,SCH3114_IO + 47h mov al,0ch out dx,al ;=================================================== ;65H PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 109 ;WDT timer time-out value ;bit[7:0]=0~255 ;=================================================== mov dx,SCH3114_IO + 66h mov al,01h out dx,al ;=================================================== ;bit[0] status bit R/W ;WD timeout occurred =1 ;WD timer counting = 0 ;=================================================== mov dx,SCH3114_IO + 68h mov al,01h Appendix D Data Modul AG - www.data-modul.com...
  • Page 110 .exit PCM-9375 User Manual Data Modul AG - www.data-modul.com...
  • Page 111 WS9 8UG - United Kingdom Phone: +44-1922-457358 Data MoDul Inc. / uSa 275 Marcus Blvd, Unit K Hauppauge, NY 11788 - USA Phone: +1-631-951-0800 Data MoDul aG | landsberger Str. 322 | 80687 Munich | tel. +49-89-56017-0 | Fax +49-89-56017-119 | www.data-modul.com...
