- Page 1 SPECIFICATION | SAFETY INSTRUCTIONS eDM-SBC-iMX8Mm www.data-modul.com...
- Page 2 The purpose of all the figures and illustrations in this User Manual is merely to provide a better explanation and can differ to the actual appearance of the devices. They are to be understood as schematic representations. © 2020 DATA MODUL AG. All rights reserved. Trademarks: Although all the information contained within this document is carefully checked, no guarantee of correctness is implied or expressed.
-
Page 3: Table Of Contents
Specifications .................................. 14 Power Features ................................14 Connector Pinning ................................... 15 General Connector Signal Description ..........................15 Internal Connectors ................................16 M.2 Key-B J9 ..................................16 Graphics Interface Connector J12............................18 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... - Page 4 Micro USB 2.0 Type-B Connector J16 ..........................24 Power over Micro USB 2.0 Type-B Connector J16 ....................... 24 Ethernet RJ-45 Connector J18 ............................24 Power Connectors................................25 Power In (DC Power Jack) J5 .............................. 25 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com...
-
Page 5: Preface
Preface Using this Document In this Document, the eDM-SBC-iMX8Mm is also referred to as „SBC“. Please read this Document before using this Single Board Computer (SBC). This Document contains information about the hardware, software and configuration of the SBC. -
Page 6: Technical Support
Technical Support DATA MODUL's technicians and engineers are committed to provide the best possible technical support for our customers to enable an easy use and implementation of our products. We recommend to visit our website at www.data-modul.com first for the latest documentation, utilities and drivers, which have been made available to assist you. -
Page 7: Technical Data
The packing complies with directive 1994/62/EU. EMC Standards EMI/EMC: according to EN55022 Electrical Safety Designed to meet EN60950 and UL60950. Shock & Vibration Shock and Vibration according to IEC/EN60068-2-6 and IEC/EN60068-2-27. 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 8: Functional Block Diagram
(M4) 1000Base-T (HUB 1) (HUB 2) GPIO optional element 12/24 VDC Feature Connector Micro Dual Micro USB2.0 USB2.0 Block Diagram rev004 RJ45 Connector SD-Card Type-B Type-A Figure 1 Functional Block Diagram 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 9: Ordering Information
I/O Module with 3 x RS232, 1 x RS485, 1 x CAN, 1 x SPI, 1 x I2C, 3 x GPIO eDM-SBC-iMX8Mm-SK 12049886 Starterkit with eDM-SBC-iMX8Mm-Q-4G, eDM-MOD-iMX8Mm-HDMI Modul, eDM- MOD-iMX8Mm-FIO1 Adapter, µSD-Card, DM-USB-Stick, Power Supply 12V 90W, RTC-Battery, Interface-set (Adapter-cable, Power-cable) -
Page 10: Connector Positions
Connector Positions Figure 2 Connector Positions 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 11: Mechanical Design
Mechanical Design PCB Size Mechanical dimensions: 100mm x 72mm Mounting Holes Figure 3 Mounting Holes Positions Refer to the step file for detailed information 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 12: Cooling Solution
Cooling Solution 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 13: Platform Features
Customizable Graphics interface via mezzanine module 4-lane MIPI DSI, dual-channel 24-bit LVDS, 24-bit RGB, 4-lane eDP, HDMI 1.2a (Type A), 4-lane DisplayPort Up to Full HD 1920 x 1080 Pixel @ 60fps 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 14: Environmental Conditions
Environmental Conditions The eDM-SBC-iMX8Mm is able to be operated and stored under the following environmental conditions: Temperature (operating): 0°C … +70°C (commercial grade) Extended temperature ranges on request. Temperature (storage): -40°C … +85°C Relative humidity: < 80% ... -
Page 15: Connector Pinning
1.8V Output O-3.3 3.3V Output 5V Output DP-I/O Differential Pair Input/Output DP-I Differential Pair Input DP-O Differential Pair Output Pull-Up Resistor Pull-Down Resistor Power Connection Table 1 General Connector Signal Description 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 16: Internal Connectors
M2-B_LED# PWR GND NC_M2-B_12 NC_M2-B_13 NC_M2-B_14 NC_M2-B_15 NC_M2-B_16 NC_M2-B_17 NC_M2-B_18 NC_M2-B_19 NC_M2-B_20 NC_M2-B_CONFIG0 NC_M2-B_22 M2-B_WAKE_WWAN_1V8# NC_M2-B_24 M2-B_DPR_1V8 M2-B_W_DISABLE2_GPS_1V8# O-1.8 (S0) PWR GND NC_M2-B_28 NC_M2-B_29 M2-B_UIM_RESET NC_M2-B_31 M2-B_UIM_CLK PWR GND M2-B_UIM_DATA NC_M2-B_35 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... - Page 17 PCIE_CLK_M2_R_N M2-B_PCIE_WAKE# I-3.3 (S0) PU 10K (S0) PCIE_CLK_M2_R_P NC_M2-B_56 PWR GND NC_M2-B_58 NC_M2-B_59 NC_M2-B_60 NC_M2-B_61 NC_M2-B_62 NC_M2-B_63 NC_M2-B_64 NC_M2-B_65 M2-B_UIM_SIM-DETECT M2-B_RESET_1V8# CLK_M2_32K768 NC_M2-B_CONFIG2 V_3V3_M2_S0 PWR GND V_3V3_M2_S0 PWR GND V_3V3_M2_S0 NC_M2-B_CONFIG2 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com...
-
Page 18: Graphics Interface Connector J12
CSI_D0_N I-1.8 (S0) DSI_D0_N O-1.8 (S0) PWR GND PWR GND PU 34K8 (S0) CLK_CCM_CLKO1_1V8 O-1.8 (S0) PD 34K8 (S0) DSI_IRQ_1V8# I-1.8 (S0) PU 10K (S0) CSI_RESET_1V8# O-1.8 (S0) BL_PWM_1V8 O-1.8 (S0) 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... - Page 19 Imax.= 300mA I2S_5_WCLK O-1.8 Series resistor 33R PWR 5.0V (S0), V_5V0_S0 Imax.= 300mA DSI_RESET_1V8# O-1.8 V_IN_VAR_S5 12V/24V (S5), Imax.= 2000mA GRAPHICS_PRNT_1V8# I-1.8 PU 10K (S0) Table 2 Graphics Interface Connector Pin Assignment 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com...
-
Page 20: Feature Connector J18
O-3.3 (S0) UART1_CTS O-3.3 (S0) Optional: (SAI2_TX_SYNC) O-3.3 (S0) UART1_RXD I-3.3 (S0) PU 10K (S0) Optional: (SAI2_TX_BCLK) O-3.3 (S0) UART1_RTS I-3.3 (S0) PU 10K (S0) Optional: (SAI2_TX_RXD0) I-3.3 (S0) PWR GND 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... - Page 21 PU 10K (S0) debug console) PWR GND CPU ON/OFF PWRBTN_KEY# I-1.8V (S0) PU 100K (S0) Button PWR GND System RSRBTN_KEY# I-5.0V (S5) PU 100K (S5) Reset Button Table 3 Feature Connector 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com...
-
Page 22: Rtc Battery Connector J17
PWR GND JTAG_TDO O-1.8 (S0) PWR GND JTAG_TDI I-1.8 PU 10k 1.8V (S0) JTAG_MOD I-1.8 JTAG_RST# I-1.8 PU 10k 1.8V (S0) JTAG_TRST# I-1.8 PD 0R Table 5 CPU JTAG Connector Pin Assignment 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 23: External Connectors
V_5V0_USBHUB_DN1 PWR 5.0V (S5) USBHUB_DN1_J_N DP-I/O USBHUB_DN1_J_P DP-I/O GND_USBHUB_DN PWR GND V_5V0_USBHUB_DN2 PWR 5.0V (S5) USBHUB_DN2_J_N DP-I/O USBHUB_DN2_J_P DP-I/O GND_USBHUB_DN PWR GND Table 7 Dual USB 2.0 Type-A Connector Pin Assignment 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... -
Page 24: Micro Usb 2.0 Type-B Connector J16
Table 8 Micro USB 2.0 Type-B Connector Pin Assignment Power over Micro USB 2.0 Type-B Connector J16 The eDM-SBC-iMX8Mm can be powered with 5V over the micro USB 2.0 Type-B connector, the current is max. 3A. Ethernet RJ-45 Connector J18 ... -
Page 25: Power Connectors
Pin assignment Signal Type Termination Comment V_in: 12V / 24V I_max: 2 A V_IN_VAR P_max: 24W (12V) / 12W (24V) PWR GND PWR GND Table 10 Power IN Connector Pin Assignment 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com... - Page 26 12049720 Rev. 01 (Draft) DATA MODUL AG | www.data-modul.com...
