Forensic RTX™410-3QJ
Thank you for purchasing WiebeTech's Forensic RTX410-3QJ.
WiebeTech's write-blocked technology, quadruple connectivity for each bay, and power/access LEDs all
inside of a tough, durable aluminum frame and lid. The latest feature of Forensic RTX is the new front
panel, with write-block indication LEDs as well as HPA/DCO detection. Whether in the field or in a lab,
Forensic RTX is a must-have for forensic investigators.
Models covered:
• Forensic RTX
410-3QJ SATA
• Forensic RTX
410-3QJ IDE +
SATA
Features
TrayFree™ technology! Simply slide in a SATA drive and shut the door. Each SATA bay offers a
•
lock for additional security, and shock protection for longer drive life. All metal bays.
Copy data from IDE or SATA drives. Bays one (PATA) and three (SATA) are write-blocked. Bays
•
two and four (SATA) are read/write making it possible to write to SATA drives from the write-
blocked drives.
Forensic RTX410-3QJ comes with all the cables you need to connect to eSATA, FireWire 800,
•
and USB 3.0, and USB 2.0.
Each hard drive has its own data channel for maximum speed.
•
Power and access LEDs let you know status of your hard drives.
•
Sturdy aluminum case provides excellent heat dissipation and rugged durability.
•
Heavy duty handle allows for easy transport.
•
HPA/DCO detection.
•
F o r e n s i c R T X 4 1 0 - 3 Q J U s e r M a n u a l ( A 9 - 4 1 0 - 0 0 0 4 ) R E V 1 . 0
USER MANUAL
Revised April 3, 2012
Forensic RTX410-3QJ features
- 1 -
