Installation Instructions
1.
Check the accessories with your RTX100H-INT. Please contact WiebeTech if any parts are
missing or damaged. The box should contain the following items:
R T X 1 0 0 H - I N T U s e r M a n u a l
RTX100H-INT™
USER'S MANUAL
Revised January 24, 2008
Features
TrayFree™ technology! RTX100H-INT can be used without
•
the use of trays. Simply slip in a SATA drive and shut the door.
All-metal construction. The RTX100H-INT is the Hardened
•
Bay that features 2 new LEDs for power and access.
Standard 5 1/4" internally mountable bay (same size as most
•
CD-ROM drives). A spare internal SATA port is required.
Bay is lockable for added security
•
Shock absorbing bay helps protect your drives against jolts
•
Specially-designed SATA connector is designed for thousands
•
of drive insertions
Accessories
RTX100H-INT
Screw pack with keys
SATA data cable
SATA power cable
Manual for installation
Quantity
1
1
1
1
(on CD)
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WiebeTech RTX100-INT
Summary of Contents for WiebeTech RTX100-INT
- Page 1 RTX100H-INT™ Installation Instructions Check the accessories with your RTX100H-INT. Please contact WiebeTech if any parts are missing or damaged. The box should contain the following items: R T X 1 0 0 H - I N T U s e r M a n u a l USER’S MANUAL...
- Page 2 WiebeTech LLC Take a moment to familiarize yourself with the parts of the RTX100H-INT. This will help you to better understand the remaining instructions for this TrayFree Hardened Bay. Front View Key lock Ejection handle Power LED Access LED Mount RTX100H-INT into your computer. In an open 5 ¼” bay in your computer, install the RTX100H-INT just as you would a CD/DVD ROM.
- Page 3 WiebeTech LLC You are now ready to insert SATA drives using TrayFree™ technology. Simply open the bay door, slip in a SATA drive, and shut the door. For extra security, use the key lock to lock the door in place. Be sure to unlock the door before pulling on the ejection handle.
- Page 4 Shipping Weights: Dimensions: Warranty: RTX100H-INT and TrayFree are trademarks of WiebeTech LLC. Other marks are the property of their respective owners. © 2008 WiebeTech LLC. All rights reserved. FCC Compliance Statement: “This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”...
