Korg Krossfour KF4 Quick Start Manual

4 channel video mixer/switcher
Hide thumbs Also See for Krossfour KF4:

Advertisement

Quick Links

EasyStart
4 channel video mixer with DJ mixer feel and control
4 composite inputs and 1 S-Video input, all with Time Based Correction to ensure the highest
quality picture
1 composite and 1 S-Video Main output
1 composite Monitor output allows the performer to "cue up" video sources before mixing
Hold button allows freezing of the video for either of the 2 channels
DJ style cross-fader with 4 adjustable fader curves
Fade to Black and Fade to White modes
Chroma key function rejects blue and allows the other channel to pass through in place of it
Luma key function rejects black, gray or white, and allows the other channel to pass through in
place of it
Clearly laid out and illuminated front panel makes it perfect for low light and club environments
Connections and Setup
Selecting an Input for a Channel
Selecting a Source to Monitor
Holding or Freezing a Source
Adjusting and Using the Cross-fader Curves
Fading to Black or White
Using the Chroma Key Function
Using the Luma Key Function
Combining Features and Functions
Suggested setup for krossfour and entrancer
krossfour Main Features
EasyStart CONTENTS
2
2
3
3
3
3
3
4
4
5
