Novibo SX GSM SMS Auto-dial Alarm System Installation And User Manual page 5

3. How to setup the alarm phone numbers (5 groups) and the content of SMS alerts (5 groups)?
1. User can send a SMS to set the alarm phone number, and the SMS command should be sent as follow:
password#command 51-55#phone number#
Send SMS: 123456#51#1
Send SMS: 123456#52#2
Send SMS: 123456#53#3
Send SMS: 123456#54#4
Send SMS: 123456#55#5
Send SMS to delete a stored phone number: 123456#51##, means deleting the 1
numbers can be deleted using similar method but changing to 52##, 53##, 54##, and 55##.
Send a SMS to acquire the phone numbers stored: 123456#50##.
2. The alarm system has fixed 5 SMS alerts, alert No.1-3 correspond to wireless zones (0-2), alert No.4
corresponds to wireless zones (3~15), alert No.5 corresponds to the wired zones (1-3).
When wireless Zone 0 is triggered: Wireless Activated (0).
When wireless Zone 1 is triggered: Wireless Activated (1).
When wireless Zone 2 is triggered: Wireless Activated (2).
When wireless Zone I is triggered: Wireless Activated (I) (I = 3-15).
When I1, I2, or I3 wired zone is triggered: Wired Activated (J) (J=1-3).
User can send a SMS to replace the content of the alarming SMS:
Send SMS: 123456#81#Front Door Open#, replaces the "Wireless Activated (0)" for alert No.1.
Send SMS: 123456#82#Back Door Open#, replace the "Wireless Activated (1)" for alert No.2.
Send SMS: 123456#83#Fire Alarm#, replace the "Wireless Activated (2)" for alert No.3.
Send SMS: 123456#84#Other Sensors#, replace the "Wireless Activated (I)" for alert No.4.
Send SMS: 123456#85#Wired Sensors#, replace the "Wired Activated (J)" or alert No.5.
Acquire the content of SMS: 123456#80##
Note:
the content of SMS edited cannot exceed 24 letters.
Advanced Instructions (Only performed under technical guidance)
1. Resetting the system.
NOTICE! Resetting the system will cause all coded information and messages to be lost.
System will be loaded with basic factory settings. The passwords will be back to the default value 123456.
You must code/register all wireless sensors again after reset.
Reset procedures:
- System must be disarmed and then power off.
- Press and hold the reset button, meanwhile connect a 12Vdc supply to the alarm system.
- Release the reset button, the alarm LED will flash once.
- Wait until the status / signal LED changes to green colour.
Now system is reset and back to factory settings (the password is 123456).
2. How to add new sensors to the alarm system (Registering wireless sensors with control unit)
Sensors and remote controls delivered in kit are already added (registered) to the system. Plug in DC 12V
power supply to the alarm system.
If the alarm system needs to add new sensors, such as PIR motion sensors, remote controls, and so on, you
can do so within the 20 seconds after the power is on. After applying 12Vdc to the system, when signal
V3.0_JUL_2012
SX GSM SMS Auto-dial Alarm System
st phone number#, means storing 1
nd phone number#, means storing 2
rd phone number#, means storing 3
th phone number#, means storing 4
th phone number#, means storing 5
st phone number.
nd phone number.
rd phone number.
th phone number.
th phone number.
5
st phone number. Other phone
