TV Connections

The oCOSMO HDTV contains a variety of possible connec-
tions on the back of the TV. Please reference the picture on
p.13 while you read through the explanations.
1. HEADPHONE – This connection is for headphones to be
attached to the TV.
2. Optical Out - This connection port is used for sending out
digital audio signals to digital surround sound receivers.
The square (OPTICAL SPDIF OUT) connector sends out
either bit-stream or PCM digital sound signal to a home
theater receiver with digital coax input.
3. Analog Audio Out – This connection is for connecting to
analog audio receivers.
4. Video – Video connects to devices that use composite
video cables such as VCR or DVD player or Wii™. Con-
nect the yellow for video and the red / white for audio.
This port uses the same the audio jacks with YPbPr. If
you use this connection, you will not be able to use
YPbPr.
5. YPbPr – This connection port is for DVD players or satel-
lite / cable set-top boxes that use component cables.
From left to right, connect green, blue, and red for video,
and then connect white for left channel audio, and red for
right channel audio. This port uses the same audio jacks
14
with Video. If you use this connection you will not be able
to use the yellow Video connection.
6. USB – USB connects to USB flash drives for playing mu-
sic and picture. The USB port is also used for updating
the TV's firmware.
7. VGA - This connection port connects to a PC for video
using VGA cable. Be sure to connect your audio cable to
the VGA Stereo input if you want sound out of VGA video
source.
8. Audio In - This connection port is for people who want to
provide audio to the TV when using a PC or a DVI video
device. The sources use 3.5mm mini-jack audio cable.
9. HDMI1-3 – HDMI connects to devices that use HDMI
cable, such as Blu-ray or HD DVD player, or HD cable /
satellite set-top box. This connection port receives pure
digital audio and high definition signal through one single
cable. This port also can accept a HDCP video device for
video. HDMI 2 also doubles as the MHL connection for
cell phones. MHL is a protocol where the TV will display
what your cell phone displays. If your cell phone supports
MHL you can purchase a MHL cable from any electronic
store and connect it to HDMI 2 and also your cell phone.
Make sure the TV's source is changed to HDMI 2 and turn
on your cell phone. You should see an image of your cell
phone screen. HDMI 2 also supports ROKU™ streaming
stick. Plug the ROKU stick to HDMI 2, and switch your
