oCOSMO CE3230 Quick Start Manual

QUICK START GUIDE
CE3230 PACKAGE CONTENTS
oCOSMO TV
User's Manual Quick Start Guide Warranty Card
Thick Thread Screws (A)x 4
Fine Thread Screws (B) x 4
Screw Driver
Circular Metal Plate
Attaching the TV Base
1.
2.
AAA
Batteries
3.
Remote Control
4.
Preparing your TV for a Wall Mount
TV Base
1.
2.
3.
Neck
INSTALLATION
Screws (A)
Find a cloth covered table. Please lay the TV flat on the table with the TV screen facing down-
wards.
If your TV comes with the neck pre-installed, then you may skip to step 3. To install the neck,
place it in the slot at the bottom of the back of the TV. Use four of the included screws (B) to
secure the neck to the TV.
Install the TV base onto the neck of the TV with the protruding plastic block on the circular hole
facing downwards.
Screws (A)
Fit the included metal circular plate to the bottom of the base and screw in the 4 included screws
(A). Please make sure the rail on the metal plate fits the protruding plastic block on the base.
Also make sure the 3 small circular holes fit the neck piece.
Screws (B)
Find a cloth covered table. Please lay the TV flat on the table with the TV screen facing down-
wards.
Locate the neck on the back of the TV and unscrew the 4 screws (B). The neck will come off
once the screws are removed.
The TV uses 200mm horizontal by 100mm vertical mounting specification. The screw size to
mount with the TV is M4. The mounting holes on the TV are 6mm deep. Please write down
your TV p/n number and s/n number (located on the back of the TV on a barcode sticker)
before you mount the TV. Mounting screws and wall mount hardware are not included.
Screws (B)
