Instruction Manual
TENS device - «Easy Free» TENS
Please read before using!
Hydas GmbH & Co. KG | Hirzenhainer Straße 3 | 60435 Frankfurt, Germany
Tel.: +49 (0)69 / 95 40 61 10 | Fax: +49 (0)69 / 95 40 61 40 | e-Mail: info@hydas.de
www.hydas.de
Artikel | Item | Article
Artikel | Articolo | Articulo
4507.1.00
4507GAz1_1404
0483

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-2011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hydas AD-2011

  • Page 1 TENS device - «Easy Free» TENS Please read before using! 0483 Hydas GmbH & Co. KG | Hirzenhainer Straße 3 | 60435 Frankfurt, Germany Tel.: +49 (0)69 / 95 40 61 10 | Fax: +49 (0)69 / 95 40 61 40 | e-Mail: info@hydas.de www.hydas.de...
  • Page 2: Table Of Contents

    Inhaltsverzeichnis DEUTSCH ENGLISH 1 Introduction TENS ............................19 2 General description ............................20 2.1 Content ..............................20 2.2 Description of the device ......................20 2.3 Display indicators ..........................20 3 Intended use..............................20 3.1 Contraindications ..........................21 4 Product description ............................21 4.1 Technical data.............................21 5 Important safety information ........................22 6 Setup and operating procedures......................24 6.1 Function and use of buttons ......................25 7 Program ................................26...
  • Page 3: Introduction Tens

    1 | Introduction of TENS 1. Theory of therapy Transcutaneous electrical nerve stimulation (TENS) is a non-invasive tech- nique in which a low-voltage electrical current is delivered through wires from a small power unit to electrodes located on the skin. Electrodes are temporarily attached with paste in various patterns, depending on the spe- cific condition and treatment goals.
  • Page 4: General Description

    1. It blocks the body‘s pain signals. These are normally transmitted from the area of damage through the nerve fibers to the brain, TENS interrupts these pain signals. 2. TENS stimulates the body‘s production of endorphins-its own natural painkillers. 2 | General description 2.1 | Contents •...
  • Page 5: Contraindications

    • People with abnormal feeling of their body except the abovge cases 4 | Product description The AD-2011 is a battery operated pulse generator that sends electrical im- pulses through electrodes to the body and reaches the underlying nerves and muscle.
  • Page 6: Important Safety Information

    Number of treatment program: Anzahl Intensities: Range of pulse frequency: 2 ~ 150 Hz Range of output voltage: 40 V ± 20% (500 Ohm load) Classification: Internally powered, Type BF applied part, IPX0, No AP or APG, Continuous operation Machine size: approx.
  • Page 7 • Do not make sharp kinks in the connecting leads or electrodes. • Do not use the device if you are connected to, or in the vicinity of, high-frequency surgical or industrial equipment. This may cause burn injuries on the skin under the electrodes, as well as problems with the stimulator.
  • Page 8: Setup And Operating Procedures

    avoidance of such interference please see part ELECTROMAGNETIC COMPATIBILITY INFORMATION. (p. 90) • Never stick two adhesive gel pads to each other. • Keep the adhesive gel pads clean and do not expose to heat or direct sunlight. • If the gel pads do not attach or are dirty, wipe with a wet cloth or replace with new ones.
  • Page 9: Function And Use Of Buttons

    4. Finishing the operation You should hold the plug when pulling it out. Please do not pull the wire. • Please use clear water to wash or use wet cloth (instead of facial tissue) to gently wipe up the electrodes when cleaning them. •...
  • Page 10: Program

    • Press the [MODE/STOP]-button will change the stimulation setting from one mode to another. 7 | Program The changing process is as follows: Program Function Pain Relief Tapping (Slow) Pain Relief Tapping (Fast) Pain Relief Vibrating (Slow) Massage Kneading (Slow) Massage Kneading (Fast) Pain Relief/Massage...
  • Page 11: Operating Instructions

    8 | Operating instructions Be sure you know the right points where to place the electrodes and affix them there then, connect the electrodes to Digital Pain Relief with wire. Switch power on. After setting mode, intensity and time, you could feel stimulation at electrodes and treatment starts.
  • Page 12: Troubleshooting

    Shoulder Foot 9 | Troubleshooting The following table provides information on troubleshooting: Malfunction The reason Countermeasure You have no Are the batteries exhausted? Replace the batteries. feeling of Are the batteries Correctly load the stimulus. properly loaded? batteries. Is the wire properly connected? Firmly connect the wire. Have you removed the Remove the transparent transparent protection film...
  • Page 13: Maintenance

    Power sources cut Have the electrode pads come Turn off the power and stick off in the therapeutic off the skin? the electrode pad firmly to process. the skin. Are the wires disconnected? Turn off the power and properly connect the wire. Have the batteries been Please replace them with new exhausted?
  • Page 14: Warranty

    40 € value free of charge within the BRD. We require your address. This you may provide to the above listed telephonic Hotline or by e-mail to: technik@ hydas.de. Prepare the package for shipping and include the reciept and de- scription of the problem. Please be aware of the fact that collect packages may not be accepted.
  • Page 15 EMC TABELLE - ELEKTROMAGNETISCHE KOMPATIBILITÄT Leitlinien und Herstellererklärung zur elektromagnetischen Strahlung Der Artikel 4508 ist für die Verwendung in einer Umgebung mit den nachstehend defi- nierten elektromagnetischen Eigenschaften vorgesehen. Der Kunde oder der Benutzer des Artikels hat sich zu vergewissern, dass er in einer solchen Umgebung eingesetzt wird. Emissionstest Konformität Elektromagnetische Umgebung - Anleitung...
  • Page 16 Stoßspannungen ± 1 kV line(s) to Nicht Nicht zutreffend IEC 61000-4-5 line(s) zutreffend Spannungsein- <5% Ut Nicht Nicht zutreffend brüche, (Spannungsein- zutreffend Kurzzeitunter- bruch >95% Ut) brechungen und in 0.5 Zyklus Spannungs- schwankungen <40% Ut (Spannungsein- ankommenden bruch >60% Ut) Stromversor- in 5 Zyklen gungsleitungen...
  • Page 17 Leitlinien und Herstellererklärung zur elektromagnetischen Strahlung Der Artikel 4508 ist für die Verwendung in einer Umgebung mit den nachstehend defi- nierten elektromagnetischen Eigenschaften vorgesehen. Der Kunde oder der Benutzer des Artikels hat sich zu vergewissern, dass er in einer solchen Umgebung eingesetzt wird. Funkstörfestig- Leistungstest Richtwerte...
  • Page 18 AM- und FM-Radio-und TV-Signalen, sind nicht exakt vorherzubestimmen. Eine Analyse der elektromagnetischen Umgebung des Ortes ist zu erwägen, um die elektromagneti- sche Umgebung, die von festen RF-Sendern ausgeht, berechnen zu können. Wenn die Stärke des in der Umgebung des Compex Performance gemessenen Feldes den oben angegebenen RF-Richtwert überschreitet, ist die korrekte Funktionsweise des Compex Performance zu überprüfen.
  • Page 19 ELECTROMAGNETIC COMPATIBILITY INFORMATION For all ME EQUIPMENT and ME SYSTEMS Guidance and manufacture’s declaration - electromagnetic emissions The 4508 is intended for use in the electromagnetic environment specified below. The customer or the user of the 4508 should assure that it is used in such an environ- ment.
  • Page 20 Surge ± 1 kV line(s) to not applicable not applicable IEC 61000-4-5 line(s) (For INTERNALLY POWERED ME EQUIPMENT) Voltage dips, <5% UT not applicable not applicable short inter- (>95% dip in (For INTERNALLY POWERED ruptions and UT) for 0.5 cycle ME EQUIPMENT) voltage variations on power supply...
  • Page 21 For ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacturer‘s declaration - electromagnetic immunity The 4508 is intended for use in the electromagnetic environment specified below. The customer or the user of the 4508 should assure that it is used in such an environ- ment.
  • Page 22 and TV broadcast cannot be predicted theoretically with accuracy. To assess the elec- tromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the 4508 is used exceeds the applicable RF compliance level above, the 4508 should be observed to verify normal operation.
  • Page 23 Hydas GmbH & Co.KG Hirzenhainer Straße 3, 60435 Frankfurt/M., Germany Tel.:069/9540610, Fax: 069/95406140 e-mail: info@hydas.de GARANTIE & SERVICE Hydas GmbH & Co. KG c/o atrikom fulfillment GmbH Haagweg 12 65462 Ginsheim-Gustavsburg OFFICE USA Hydas Inc. P.O. Box 420, Hershey, PA. 17033 Tel.
