5X7REV/RG
5X7REV/RG
INSTALLATION MANUAL
INSTALLATION MANUAL
INCLUDES:
(1) Hogtunes NCA 70.2 Amplifier • (1) Pair Hogtunes 572.2-AA
Speakers • (1) Road Glide Adaptor Kit
For Use on All 1998 and Newer FLTR Road Glide
Models With Factory or After Market Radio
*** Not for use on CVO model bikes with factory amplifier installed
Adjusting Your System--Please Read!
In order to make your new system perform as good as it was designed,
please take a minute to understand and follow these tips:
1) Set your "Automatic Volume Control" (AVC) to 3 bars. After extensive on
road testing, we found that this AVC position works and sounds best. Your
new amplifier has been specifically set-up for this radio setting.
2) Your Hogtunes system is designed specifically for a motorcycle at speed.
Exhaust noise and wind noise have been taken into careful consideration
in how your system performs. How your new system sounds in a driveway
or garage is radically different from how it will sound at highway speeds.
Although your system was set-up with a factory radio with its bass and
treble controls in the middle position, if you feel the need to make
adjustments, please do so (carefully) at your normal cruising speed.
3) If you have an aftermarket car radio on your bike, everything will work
fine, but please remember that car radios are designed to work in an
environment with little or no exhaust or wind noise. Many car radios have
"features" such as equalizers, loudness contours, surround effects, etc., all
designed for a quiet environment, and all of which will hurt your ability to
hear your motorcycle system at speed if left on. Please take a minute and
turn as much of these "features" off. With a car radio in your bike, the
only adjustments you should be able to access for best performance are
volume, bass, treble, balance, and fader.
4) If you're using an external device to supply music through the radios
aux port, we have an article on our website that can help make your
peripheral audio device sound as good as it can. The article is at:
http://www.hogtunes.com/techzone_files/Level_matching.pdf
A video version of this manual is available at
www.hogtunes.com. If you still need
assistance, please consider a professional
installation by your motorcycle dealer.
Thank you for choosing the Hogtunes Model 5x7REV/RG front speaker and
amp kit for Road Glides. Since positive word of mouth is the best way to
grow our business, we want your new system to work as well as it was
designed to. If you have any questions or concerns, we are here to help.
Hogtunes Contact Information:
Email: info@hogtunes.com
Tel: 705-719-6361
