3.2 Camera Interface

iCube series cameras interfaces are located on the back of the camera (assuming lens mount
is front) as per the follows.
NS-Version (housing)
KS- Version (OEM)
JP3 Trigger / Strobe
JST BM08B-SRSS-TB
CN1 USB 2.0 High Speed
Mini USB Type B
N E T G m b H A l l R i g h t s R e s e r v e d
For More Information Please Call Aegis Electronic Group, Inc. * (888) 687-6877 Phone * aegisg2@aegiselect.com * http://www.aegis-elec.com
(compatible plug JST 08SR-3S)
