hayneedle ALZ109 Assembly Instructions Manual

Red ember bronze crossweave firebowl fire pit with free cover and fire tool with optional grill grate
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
ITEM NAME: Red Ember Bronze Crossweave Firebowl Fire Pit with Free Cover and Fire Tool with Optional Grill Grate
SKU: ALZ109
For Outdoor Use Only!
1. Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage.
2. Read the assembly and operating instructions thoroughly before installing or servicing this
equipment.
3. Failure to follow these instructions could result in fire or explosion, which could cause
property damage, personal injury, or death.
1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALZ109 and is the answer not in the manual?

Questions and answers

Related Manuals for hayneedle ALZ109

Summary of Contents for hayneedle ALZ109

  • Page 1 ITEM NAME: Red Ember Bronze Crossweave Firebowl Fire Pit with Free Cover and Fire Tool with Optional Grill Grate SKU: ALZ109 For Outdoor Use Only! 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the assembly and operating instructions thoroughly before installing or servicing this equipment.
  • Page 2 PARTS: PANELS AND FITTINGS IDENTIFICATION: PARTS PARTS Optional HARDWARE LIST: PARTS PARTS 20PC...
  • Page 3 STEP-BY-STEP ASSEMBLY INSTRUCTIONS ★ When applicable, tighten all hardware connections by hand first. ★ Once the step is completed, go back and fully tighten all hardware. ★ Follow all steps in order to properly assemble the product. STEP 1: Attach the Legs (Part H) to the Bowl (Part F) using Bolt 2 (9pcs). STEP 2: Attach the Base Rings (Gx4) to the bowl using Screw 1 (20pcs).
  • Page 4 STEP 3: Attach Handle (A) to the Spark Guard (B) using Nut 3 (1pc). STEP 4: Insert the Fire Wood Grid (D) and the Food Grill Grate (C - optional) into the bowl. Set Spark Guard on top. STEP 5: Assembly is complete...

  • Page 5: For Your Safety

    Note: When not in use, please cover the outdoor fire pit with the enclosed cover. WARNING FOR YOUR SAFETY 1. This appliance is for outdoor use only, and shall NOT be used in a building, garage, or any other enclosed area.
  • Page 6 11. Do NOT alter this outdoor fireplace in any manner. 12. Do NOT use this outdoor fireplace until it is COMPLETELY assembled and all parts are securely fastened and tightened. 13. Do NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.

  • Page 7: Tending The Fire

    OPERATING INSTRUCTIONS: Lighting 1. Make sure there is no more than a small amount of ash in the bottom of the bowl. 2. Place a layer of dry kindling or a natural fire starter onto the center of the grate. 3.
