Summary of Contents for mca MCA-DVBT-TV-01
-
Page 2: Table Of Contents
Using IR Remote Control..............5 Using Board Monitor Display to Control TV functions......7 Installation............................8 Installation overview................8 Replacing existing TV module with MCA-DVBT-TV-01......8 Software....................9 OSD Operation.......................... 10 Using OEM board monitor for menu navigation and control....11 Using remote control for menu navigation and control......12 Advanced Configuration Menu.................... -
Page 3: Overview
Thank you for purchasing Mura Car Accessories TV Tuner. Our product is designed for vehicles operating on the BMW I-BUS protocol. Providing complete integration with OEM car head unit, MCA-DVBT-TV-01 offers an easy to control bult-in digital (DVB-T) HD TV tuner along with a multimedia interface, allowing you to view and record your favorite TV shows when you are on the road. -
Page 4: Package Contents
MCA-DVBT-TV-01 supports both 16:9 and 4:3 displays • To benefit from the rear view camera feature, you must have one • such camera installed on your car. The camera must implement either PAL or NTSC standards. For a Plug & Play installation you must already have an analog TV •... -
Page 5: Hardware
Hardware Rear Panel View Port Connection Blue connector Connects car's blue connector White connector Connects car's white connector... -
Page 6: Using Ir Remote Control
USB port Connect data stick extender cable for data stick IR port IR cable from present package Antenna connectors Connects to OEM car antenna connections All TV module functions can be accessed using both remote control and OEM BMW head unit controls (similar to your old analog TV module). Using IR Remote Control Depending on the tuner version you are purchasing, you will receive one of the two following remote controls versions. - Page 7 Remote Control version 2...
-
Page 8: Using Board Monitor Display To Control Tv Functions
Using Board Monitor Display to Control TV functions MCA-DVBT-TV-01 supports both 16:9 and 4:3 BMW OEM head units. Monitor buttons were mapped to TV tuner functions in such a way as to preserve the manner of operation from the old analog tuner. For the users who are migrating from an analog tuner, controlling Mura Digital TV tuner should be a familiar operation. -
Page 9: Installation
1-5 min Disconnect the negative terminal of the car battery • Remove the old TV module and put the MCA-DVBT-TV-01 in its • place Connect the white and blue car cable connectors to corresponding •... -
Page 10: Software
You will need to be able to point the remote control towards this receiver. Connect USB cable to the USB port on MCA-DVBT-TV-01 and route • the other end of the cable to a convenient position for when you want to use a USB stick Installation is now over. -
Page 11: Osd Operation
Present version of TV tuner does not make use of 'System' functions. Multimedia Photo Configure Movie Configure PVR Configure → Music Access to Music, Photo and Multimedia Photo Movie folders on your memory Movie stick Access to streams recorded using MCA-DVBT-TV-01... -
Page 12: Using Oem Board Monitor For Menu Navigation And Control
Using OEM board monitor for menu navigation and control The following instructions refer to controls described in section “Using Board Monitor Display to Control TV functions” on page 6. Mind that the names by which we refer to them differ from what appears on your board monitor, so please use the above mentioned picture to guide your through the following steps. -
Page 13: Using Remote Control For Menu Navigation And Control
Delete recording: Navigate to the desired file • Press Pause/Blue • Confirm deletion by pressing the rotary button • Using remote control for menu navigation and control Menu navigating and control of TV tuner by means of remote control is, in our opinion, quite intuitive. - Page 14 . After performing the necessary hardware modifications, software configurations must also be made. First set AUX Mode to ON (see instructions above). Back to the menu of your navigation, press MODE button until AUX input is selected (you may need to press it multiple times).
-
Page 15: Specifications
RF Input connector: SMB terminal x2 Antenna power: 12V Technical Support MCA is committed to offering quality products, as well as quality information. If you need help with using Mura TV tuner, please contact our customer support at http://mca.electricmura.ro /en. -
Page 16: Warranty Information
Warranty Information This product is backed by a one-year warranty. In addition, MCA warrants its products against defects in materials and workmanship for the period noted following the initial date of purchase. During this period, the product may be returned for repair or replacement with an equivalent product.
