HP-13009-3
Universal Controller
SCX10
STARTUP MANUAL
Thank you for purchasing an Oriental Motor product.
The SCX10 has been designed to be easy to use, and contains several unique functions.
This startup manual should help you to get to know the product quickly. Please read the separately
supplied operating manual for more detailed information.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oriental motor SCX10
Summary of Contents for Oriental motor SCX10
- Page 1 Thank you for purchasing an Oriental Motor product. The SCX10 has been designed to be easy to use, and contains several unique functions. This startup manual should help you to get to know the product quickly. Please read the separately...
- Page 2 Safety Precautions Chapter 1 The precautions described below are intended to prevent danger or injury to the user and other personnel through safe, correct use of the product. Use the product only after carefully reading and fully understanding these instructions. Handling the product without observing the instructions that accompany a Warning "Warning"...
- Page 3 • When an abnormality is noted, stop the operation immediately, or fire or injury may occur. Disposal • When disposing of the device, treat it as ordinary industrial waste. List of Items Chapter 2 • Universal controller (SCX10) 1 unit • CD-ROM 1 pc. (Immediate Motion Creator for CM/SCX Series (GUI Software), Startup manual, Operating manual, CANopen EDS file, USB driver, .NET Framework 2.0)
- Page 4 24 VDC Power supply D-SUB 25pin connector Driver A USB Mini cable and a D-SUB connectors are not supplied with the SCX10. Note For all drivers except AR series Set the driver pulse Input mode to 1 pulse mode. See the driver manual for information on how to set.
- Page 5 Pin assignment for D-SUB 25 pin connector 6: GND 2: DIR+/CCW+ 7: CON 13: 5V /24V OUT 1: PLS+/CW+ 14: PLS-/CW- 15: DIR-/CCW- • Pulse (PLS) / Direction (DIR) signals AR Driver SCX10 PLS+/CW+ PLS+ PLS- PLS-/CW- DIR+ DIR+/CCW+ DIR-/CCW- DIR- • Current ON (CON) signal a.
-
Page 6: Installing The Usb Driver
3.2 Installing the USB Driver Insert the supplied CD into the CD drive of the computer, power on the SCX10 and Connect to a USB port using a Mini-B cable. You will then be asked to install the USB driver. - Page 7 2. Set the distance per revolution 2. Set the parameter DPR to 1 Enter "DPR=1", and press the Enter key. Enter "DPR=1", and press the Enter key. >DPR=1 >DPR=1 DPR=1(1) Rev DPR=1(1) mm Position range = +/- 500000(500000) Position range = +/- 500000(500000) Velocity range = 0.001 - 12400(12400) Velocity range = 0.001 - 12400(12400) 3.
- Page 8 VR=2 Rev/sec >MI > While all commands to the SCX10 can be made using general terminal software, the supplied GUI, Memo Immediate Motion Creator for CM/SCX Series (IMC), is recommended for its ease of use. To install, insert the supplied CD into your CD drive. Open the Explorer, select the applicable CD drive, open the IMC folder, double click on "setup.exe"...
