  • Page 1 RBC-3 RBC-2 RBC-4 RBC-5 RBC-6 RBC SERIES REARVIEW BACK-UP CAMERAS OWNERS MANUAL...

  • Page 2: Wiring Diagram

    WIRING DIAGRAM VIDEO OUT to MONITOR (YELLOW PLUGS) CAMERA RED PLUG POWER DC 12V to REVERSE LIGHTS BLACK PLUG BLACK ( – ) RED ( + ) Connect RED ( + ) wire to RED or positive wire of reverse light.
  • Page 3 IMAGE SHAKING: Make sure MOUNTING SCREWS are tight. IMAGE SLANTING: Adjust CAMERA ANGLE. Never attempt to disassemble camera as there are no user serviceable parts. If probelms persist please contact Rockville for technical assistance: 1-646-758-0144, Monday - Friday, 9am - 5pm EST...
  • Page 4 Rockvilleaudio.com © 2014 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
