HEADREST DVD PLAYER OWNERS MANUAL
Rockvillestore.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEADREST DVD PLAYER and is the answer not in the manual?

Questions and answers

Related Manuals for Rockville HEADREST DVD PLAYER

Summary of Contents for Rockville HEADREST DVD PLAYER

  • Page 1 Rockvillestore.com HEADREST DVD PLAYER OWNERS MANUAL Rockvillestore.com...
  • Page 2 Thank you for purchasing this Rockville Headrest DVD unit. We have spared no expense in designing and manufacturing this DVD Headrests to meet the highest quality standards. With proper care and installation this unit should provide you with many years of performance and reliability.

  • Page 3: Table Of Contents

    Rockvillestore.com CONTENTS Accessories Precautions and Warnings Key Features Installation Instructions Headrest Functions Remote Functions Touchscreen Functions Troubleshooting Technical Specifications and Parameters...

  • Page 4: Accessories

    USERS MANUAL FOR ROCKVILLE DVD PLAYER ACCESSORIES • Multifunction Remotes (Remote Type Varies Depending on Headrest Model) • Owner’s Manual • Matching Slip Covers • Power and AV Cables (Cable Type Varies Depending on Headrest Model) • Detachable Steel Posts •...

  • Page 5: Precautions And Warnings

    Rockvillestore.com PLEASE READ ALL DIRECTIONS & PRECAUTIONS CAREFULLY BEFORE YOU BEGIN INSTALLATION PRECAUTIONS & WARNINGS • Do not operate video headrest while driving • Do not attempt to dismantle or repair video headrest • Harsh cleaning chemicals can damage quality of screen •...

  • Page 6: Key Features

    KEY FEATURES • All in one unit, no extra equipment needed! • Built in FM-Stereo Transmitter; allows for wireless connection and play through factory radio • Supports a wide range of formats (see chart below) • Plays mp3/mp4/wma/jpg & other downloadable content •...

  • Page 7: Installation Instructions

    Rockvillestore.com INSTALLATION INSTRUCTIONS *** DOUBLE CHECK ALL MEASUREMENTS TO ENSURE PROPER FIT AND PLACEMENT OF UNIT BEFORE BEGINNING INSTALLATION. EASY FIT INSTALL GUIDE • Remove original headrest • Use the supplied steel pipes to match the factory headrest pole diameter •...

  • Page 8: Headrest Functions

    HEADREST FUNCTIONS DESCRIPTION Power Press the “Power” key to turn the player On or Off. Eject Opens the panel door Play/Pause Push once to play media. Push again to pause media. Used to rewind media. In video mode image can be rewound at various speeds by pressing the key various times (up to 4 times).
  • Page 9 Rockvillestore.com HEADREST FUNCTIONS DESCRIPTION Slow motion key allows you to view the image at up to 1/7th speed in DVD mode. Press the key repeatedly to decrease speed. Press the “Play/Pause” key to return to Slow normal play. The “Program” key allows you to set the order of tracks to be played. Programming is not allowed for MP3 disks.
  • Page 10 HEADREST FUNCTIONS DESCRIPTION Use the “Subtitle” key on the remote control to activate subtitles. Press the key successively to select different subtitle languages.This function is limited to DVD’s Subtitle that have subtitles. DVD’s support multiple languages. To access language menu, press the “Audio” key. Press the “Audio”...
  • Page 11 Rockvillestore.com HEADREST FUNCTIONS DESCRIPTION The “FM-TX” key allows you to enter radio mode. Use the directional keys to FM-TX navigate between stations. Press the “FM-TX” key a second time to exit radio mode. The “Zoom” key is used to zoom in the image on screen. Press the “Zoom” key repeatedly to zoom in closer.

  • Page 12: Remote Functions

    1. PBC / Menu REMOTE FUNCTIONS 2. Title 1. Start 3. Power 2. Function Keys 4. Mute 3. Select 5. Number Keys 4. Mute 6. Goto 5. Power 7. Subtitle 6. Home 8. Rewind / Fast Forward 7. Menu 9. Display 8.
  • Page 13 Rockvillestore.com REMOTE FUNCTIONS Application of Remote Control • Horizontal: ±30° • Vertical: ±30° • Max Distance: 16 ft ±30°...

  • Page 14: Touchscreen Functions

    TOUCHSCREEN MENU FUNCTIONS DISC LOAD 1. Load a disc into the unit. Ensure that the disk is compat- 2. If it is a CD, CDR, or CDR/RW the menu pictured be- ible with your unit. Press the “DISC” icon to begin playing low will appear once you’ve pressed “DISC”...
  • Page 15 Rockvillestore.com USB INPUT Connect USB drive via available USB port. Touch “USB” icon to access the USB drive (Figure 3). In the next screen (Figure 4) select the media you would like to access: Video, Music, Photo, or Text. Touching any of the icons wll take you to a submenu screen which will allow you to view or listen to the desired media.
  • Page 16 SET-UP To enter the set-up menu simply touch the “SETUP” icon on the main screen (Figure 7). Once in the set-up menu you will be able to make changes to the System (Figure 8), adjust Disc options (Figure 9), set up Audio features (Figure 10), adjust Speaker settings (Figure 11), and set digital mode (Figure 12).
  • Page 17 Rockvillestore.com AV1 / AV2 INPUT To access any external AV sources touch either AV1 (Figure 13) or AV2 (Figure 14) in the main menu. Figure 13 Figure 14 IR OUT Touching the “IR OUT” icon (Figure 15) will bring up the IR Settings screen (Figure 16). Here you will be able to select your IR Headphone transmitting frequency, as well as turn off the IR option if desired.
  • Page 18 FM OUT Touching the “FM OUT” icon (Figure 17) will bring up the FM Settings screen (Figure 18). Here you will be able to select the FM band for output of unit audio via your factory speakers. Touching the “OFF” button will turn off this feature. Figure 17 Figure 18 SPEAKER...
  • Page 19 Rockvillestore.com FM OUT The “IMAGE” icon (Figure 20) will bring up image control sliders (Figure 21). Using the “+” and “-” icons the sliders allow you to set Brightnes, Contrast, and Color. Figure 20 Figure 21 During DVD / VCD movie playback touching the top edge of the screen will activate menu options Touching this area again will clear the menu.

  • Page 20: Troubleshooting

    TROUBLESHOOTING SYMPTOM SOLUTION No Power 1. Check all power connections and ensure that the unit is wired properly. 1. Check that the unit is powered on. No Image 2. Ensure that the input cable is connected properly. 3. Check unit settings; ensure that it is set for the proper type of input. 1.

  • Page 21: Technical Specifications And Parameters

    Rockvillestore.com Technical Specifications and Parameters Disk Type DVD, DVD-R, DVD-ROM, CD, CD-R, CD-RW, VCD (Signal Source) Display 7in / 9in Audio: Stereo Output Video: Complex Video Signal Output (AV) USB Port Input SD / MS / MMC Card Reader Video System PAL / NTSC Video 1.0Vp - p (75 ohm)
  • Page 22 © 2012 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
