Installing the Unicomp

Quick Install Instructions

General installation points:
Connection: The inputs of this unit are electronically balanced, 3-pin
XLR connectors. Pin 2 is hot, pin 3 is cold, and pin 1 is shield.
The output is a male XLR; pin 2 hot, pin 3 cold, and pin 1 is shield.
This is a single-ended output, meaning that signal is present only on
pin 2 of the XLR. It is also an impedance balanced output in which the
impedance at pin 3 of the output XLR is matched to pin 2.
As far as interconnecting to other devices; treat this output as a
typical balanced output and connect in the same fashion as any balanced
input/output device using typical shielding conventions.
Be sure that the level selector switches (if so equipped) at the rear
of the chassis are in the same positions on both the left and right
sides of the unit.
Mounting: Proper ventilation is important for the longest service life
of components, and it is recommended that the Unicomp be mounted with
at least one full rack space above and below the unit. When not racked,
be sure to allow adequate air flow through the unit. Space the unit up
off the surface so that air can flow freely through its bottom. Do not
place any thing on top of the unit which may restrict airflow through
the chassis.
