  • Page 1: User Manual

    User Manual April 2010 Revision 1.1 POSEO 5200 POSEO 5200 POSEO 5200 POSEO 5200 Hardware System Hardware System Hardware System Hardware System...
  • Page 2 Copyright 2008 ~2010 All Rights Reserved Manual Version 1.1 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS 1. To disconnect the machine from the electrial power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. 2.

  • Page 4: Caution On Lithium Batteries

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.

  • Page 5: Revision History

    Revision History Revision Description Revision Date Number Initial release 2008 August Updated specifications Updated motherboard drawing Added Appendix B: Dimensional 2010 April Drawings & Moved BIOS Error Codes to Appendix C...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List........................7 2. System View ........................8 2.1 Front View......................8 2.2 Rear View ......................9 3. Driver Installation ......................10 3.1 Driver List......................10 3.2 Chipset Driver Installation ................... 10 3.3. Installation of Windows XP update for Dual Core CPU........13 3.4.

  • Page 7: Packing List

    1. Packing List Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: a. Power Cable b. Driver CD...

  • Page 8: System View

    2. System View 2.1 Front View Hardware Status Display Key Lock 2 x USB Power Button Powe...

  • Page 9: Rear View

    Connectivity Module 2.2 Rear View Power Power Power AC Power COM2 & 4 Line Out DC Output 24V COM 3 & 5 CD 1 P/S 2 Keyboard COM1 DC Output 12V Note: The maximum current that can be drawn from each COM port is 500 mA. DC output 24 V Pin Assignment...

  • Page 10: Driver Installation

    3. Driver Installation 3.1 Driver List Folder/File File Description <CD>:\Poseo5200.htm POSEO 5200 Driver List <CD>:\Common/Intel/Chipset/i9xx Chipset Driver <CD>:\Common/INTEL/Utility/WindowsXP_update/KB92 Windows XP update (Chipset) 1411(Chipset) <CD>:\Common/INTEL/Utility/WindowsXP_update/KB89 Windows XP update 6256(Dual%20Core%20CPU) (Dual Core CPU) <CD>:\COMMON/INTEL/VGA/i94x VGA Driver <CD>:\Common\INTEL\Raid\ICH7R\Windows\Driver SATA RAID Driver <CD>:\Common\INTEL\Raid\ICH7R\Windows\raid_tools RAID Manager Utility <CD>:\Common\AC97_Codec\Realtek\ALC202A...
  • Page 11 c. Click the "Yes" button on the License d. Click the ”Next” button on the Readme Agreement window. Information window. e. Click the “Finish” button and restart your system.
  • Page 12 Installation of Windows XP update for Chipset * You must install this update after installing the Chipset driver. Without this update, your USB ports may not work correctly. a. Click "WindowsXP-KB921411-x86-ENU” b. Click the "Next" button on the on the My Computer window. KB921411 window.

  • Page 13: Installation Of Windows Xp Update For Dual Core Cpu

    3.3. Installation of Windows XP update for Dual Core CPU Computers that are equipped with a dual core CPU and running Windows XP Service pack 2 should install this update. Without this update, you may experience decreased performance or unexpected behavior. If your CPU is not a Dual Core, you should not need to install this update. a.

  • Page 14: Vga Driver Installation

    e. Click the “Finish” button and restart your system 3.4. VGA Driver Installation a. Double click "win2k_xp1425" on the My b. Click the "Next" button on the Welcome Computer window. window.
  • Page 15 c. Click the “Next” button on the Welcome d. Click the “Next” button on the Readme Window Information Window e. Click the ”Yes”button on the License f. Click the ”Finish”button and restart your Agreement window. system.

  • Page 16: Audio Driver Installation

    3.5. Audio Driver Installation a. Click “A3.71” on the My Computer b. Double click “wdm_a371” on the My window. Computer window. c. Click “Next” button on the Realtek AC’97 d. Click “Yes” button on the Digital d. Audio Setup window. Signature Not Found window.

  • Page 17: Lan Driver Installation

    e. Click “Finish” button on the Realtek AC’97 Audio Setup window. 3.6 LAN Driver Installation a. Double click ”Setup” on the My b. Click the "Finish" button on the Computer window. Maintenance complete window.

  • Page 18: Sata Raid Driver Installation

    c. Click the ”OK” button and restart your system. 3.7. SATA RAID Driver Installation Before the SATA RAID driver installation, please refer to chapter 9.5 ”Enabling RAID in the BIOS” and chapter 9.6 “RAID Volume Creation”. 3.7.1. Create F6 driver disk The SATA RAID Driver is for users who plan to install Windows on SATA HDDs with RAID functions.
  • Page 19 c. Click the “Yes” button on the “Confirm d. Wait for the driver disk to be written. operation” window 3.7.2. F6 driver installation Press the F6 key when prompted in the status line with the Press F6 if you need to install a third party SCSI or RAID driver message.
  • Page 20 The next screen should confirm your selected controller. Press the Enter key again to continue. At this point, you have successfully F6'ed in the Intel® Matrix Storage Manager driver and Windows setup should continue. Leave the floppy disk in the floppy drive until the system reboots. Windows setup will need to copy the files from the floppy again to the Windows installation folders.
  • Page 21 c. Click the “Next” button on the Warning d. Click the “Yes”button on the License window Agreement window e. Click the “Next” button on the Readme f. Select “Yes, I want to restart my window computer now” and click the “Finish” button to complete the installation...

  • Page 22: Peripherals Installation

    4. Peripherals Installation 4.1. Cash Drawer Installation You can install a cash drawer through the Cash Drawer port. Please verify the pin assignment before installation. 4.1.1. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V/24V DOUT bit1 4.1.2. Cash Drawer Controller Register The Cash Drawer Controller use one I/O address to control the Cash Drawer.
  • Page 23 Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 1: Reserved Bit 0: Reserved...

  • Page 24: Hardware Status Display

    5. Hardware Status Display 5.1. Introduction The Hardware Status Display in the front panel of the POSEO 5200 gives information about the working of the main portions of the system hardware. In case of malfunction, it shows which portion of the hardware has an abnormal status: - Power: CPU, 3.3V, 5V, 12V...
  • Page 25 5.2.2 System Power is on (Normal status) Blinking "ON" Temperature means HDD access "ON" (not blinking) Fan is normal means LAN access DC power is normal 5.2.3 System Power is on (Abormal status) If the system hangs during the boot sequence, the Hardware Status Display will show a BIOS Error Code, as shown below.
  • Page 26 5.3. Function Table System Action Display Shows Remarks - CPU and System Temperature (° C) System Off - CPU and System Fan are off Monitor hardware status in standby (standby - DC Power is off power mode power) - HDD access is off - LAN access is off - CPU and System Temperature (°...

  • Page 27: System Disassembly

    6. System Disassembly 6.1. Removing the Front Cover a. Open the front cover door and unlock it b. Lift the front cover up as shown by the with the key. arrows c. Remove the front cover...

  • Page 28: Removing The Top Cover

    6.2 Removing the Top Cover To remove the top cover, please first follow the steps described in chapter 6.1. a. Remove the two screws on each side of b. Slide the top cover towards the front and the top cover remove it from the system.

  • Page 29: Replacing The Dvd-Rom

    c. Pull on the blue tab to remove the HDD. d. Repeat for the second HDD. 6.4. Replacing the DVD-ROM To replace the front cover, please follow the steps as described in chapter 6.1 a. Loosen the thumb screw (1) b.

  • Page 30: Replacing The Power Supply

    6.5. Replacing the Power Supply To replace the power supply, please follow the steps as described in chapters 6.1 and 6.2 If you have a DVD-ROM, disconnect the cables as shown in chapter 6.4, item c. a. Remove the screws (3). b.

  • Page 31: Replacing The I/O & Pci Extension Module

    6.6. Replacing the I/O & PCI Extension Module To replace the I/O and PCI extension module, please follow the steps as described in chapter 6.1 and 6.2 a. Remove the extension module by gently b. Disconnect the cables (2) and remove the pulling it upwards taking care not to screws (2, one on each side) to remove damage the connector.

  • Page 32: Replacing The Memory

    6.7. Replacing the Memory To replace the memory, please follow the steps as described in chapter 6.1, 6.2 , 6.6(a), 6.5(a+c). a. Use your finger to push the DIMM slot b. Remove the memory module from the ejector clips into the down position. slot.
  • Page 33 c. c. Remove the screws (7) d. Remove the hex nuts (16) to release the motherboard from the chassis...

  • Page 34: Specification

    7. Specification Mainboard CPU Support LGA775 Pentium Dual Core 1.8GHz, 1MB cache, 800 MHz FSB Chipset INTEL 945G FSB 533 / 800 / 1066 MHZ / ICH7R System Memory Up to 4GB DDR ll RAM, 2 RAM-DIMM slots Graphic Memory Shared memory up to 224 MB Storage 1 x 3.5"...
  • Page 35 Internal Header 1 ( USB8 ) Power Button 1 ( pin header) COM6 1 (pin header) Peripherals ( special feature) Second HDD (hot swap) (optional) RAID Supports RAID 0, RAID 1 for 2 SATA HDDs System ID Built-in Connectivity Module Powered USB (12V) Powered USB (24V) Powered USB (5V)

  • Page 36: Jumper Settings

    8. Jumper Settings 8.1. B99 Motherboard...

  • Page 37: Connectors

    8.2. Connectors Connectors Function Connectors Function COM6 Connector CN16 HDD Action LED Connector Speaker & MIC Connector CN17 LAN Action LED Connector Hardware Status Display CD-in & Line-in Connector CN18 connector USB8 CN19 LVDS (DVI) FAN_CPU3 CPU Fan Connector Power Connector (+5V/+12V) CN10 Power Connector (+5V/+12V) FAN_SYS3...

  • Page 38: Jumper Settings

    8.3. Jumper Settings 1. COM1 Power Setting ◎Factory Default Setting Function JP4 (SHORT) ◎1-2 DCD# +12V ◎7-8 9-10 +12V 11-12 2. COM 2 Power Setting Function JP8 (SHORT) ◎1-2 DCD# +12V ◎7-8 9-10 +12V 11-12 3. COM 3 Power Setting Function JP6 (SHORT) ◎1-2...
  • Page 39 5. COM 5 Power Setting Function JP3 (SHORT) ◎1-2 DCD# +12V ◎7-8 9-10 +12V 11-12 6. 2ND Display Power Setting Function JP11 (SHORT) +12V ◎1 7. CMOS Operation Mode Setting Function JP13 (SHORT) ◎N/C COMS Normal COMS Reset 8. Power Mode Setting Function JP14 (SHORT) ◎N/C...
  • Page 40 8.4. Connector and Pin Definitions CN5: Speaker & MIC Connector Pin 1 AMP_ORL Pin 2 Pin 3 Pin 4 AMP_ORR Pin 5 Pin 6 MIC1 CN6: CD-IN Connector Pin 1 CDIN_L Pin 2 CDIN_REF Pin 3 CDIN_R Pin 4 CDIN_REF Pin 5 Pin 6 LINE_IN_L...

  • Page 41: Raid Bios Settings

    9. RAID BIOS Settings 9.1. BIOS Setup Utility The BIOS setup defines how the system is configured. You need to run this program the first time you configure this product. You may need to run it again if you change the configuration. You need to connect a PC keyboard to the keyboard connector to run the BIOS setup utility.
  • Page 42 Standard CMOS Features Use this menu for basic system configuration. Advanced BIOS Features Use this menu to set the Advanced Features available on the system. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize the system’s performance.
  • Page 43 Use this menu to load the BIOS default values, i.e., factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the option to change these defaults to meet their needs Set Supervisor Password Enables you to change, set, or disable the supervisor or user password Set Password...

  • Page 44: Enabling Raid In The Bios

    9.5. Enabling RAID in the BIOS Enter the BIOS Setup program by pressing the DEL key. Select Integrated Peripherals, and then press “Enter” Select OnChip IDE Device, and then press “Enter”...

  • Page 45: Raid Volume Creation

    Select SATA Mode, and then press “Enter” Select RAID, and then press “Enter” Press the F10 key to save the BIOS settings and exit the BIOS Setup program. 9.6. RAID Volume Creation When the Intel® Matrix Storage Manager option ROM status screen appears during POST, press the Ctrl and i keys at the same time to enter the Intel Matrix Storage Manager option ROM user interface.
  • Page 46 press the Enter key. Press the Enter key to select the physical disks. Select the appropriate number of hard drives by using the up or down arrow keys to scroll through the list of hard drives and pressing the Space key to select the drive. When finished, press the Enter key.

  • Page 47: Appendix A: Pci Card Dimensions

    Appendix A: PCI Card Dimensions Maximum dimension of the PCI add-on card: Component Side: 130mm x 90.26mm ( D x W ) (Picture 1)

  • Page 48: Appendix B: Dimensional Drawings

    Appendix B: Dimensional Drawings...

  • Page 49: Appendix C: Bios Error Codes

    Appendix C: BIOS Error Codes POST (hex) Description Test CMOS R/W functionality. Early chipset initialization: -Disable shadow RAM -Disable L2 cache (socket 7 or below) -Program basic chipset registers Detect memory -Auto-detection of DRAM size, type and ECC. -Auto-detection of L2 cache (socket 7 or below) Expand compressed BIOS code to DRAM Call chipset hook to copy BIOS back to E000 &...
  • Page 50 POST (hex) Description run time area in F000 for ESCD & DMI support. Reserved Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-time clock power status, and then check for override. Reserved Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers.
  • Page 51 POST (hex) Description 24h ~ 26h Reserved Initialize INT 09 buffer Reserved 1. Program CPU internal MTRR (P6 & PII) for 0-640K memory address. 2. Initialize the APIC for Pentium class CPU. 3. Program early chipset according to CMOS setup. Example: onboard IDE controller.
  • Page 52 POST (hex) Description Reserved Test all memory (clear all extended memory to 0) 53h ~54h Reserved Display number of processors (multi-processor platform) Reserved 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every ISA PnP device. Reserved Initialize the combined Trend Anti-Virus code.
  • Page 53 POST (hex) Description 70h ~ 72h Reserved (Optional Feature) Enter AWDFLASH.EXE if : -AWDFLASH is found in floppy drive. -ALT+F2 is pressed Reserved Detect & install all IDE devices: HDD, LS120, ZIP, CDROM….. Reserved Detect serial ports & parallel ports. 78h ~ 79h Reserved 7Ah ~ 7Eh Detect &...
  • Page 54 POST (hex) Description 6. Program K6 write allocation 7. Program P6 class write combining 1. Program daylight saving 2. Update keyboard LED & typematic rate 1. Build MP table 2. Build & update ESCD 3. Set CMOS century to 20h or 19h 4.
