Page 1: Table Of Contents
1TouchIQ2 Series Fingerprint Lock Table of Contents 1. Features and Technical Specifications: 2. Fingerprint Recognition Notes: 3. Enrollment Options: User Enrollment Changing Master Code Enroll Fingerprint User at Random Enroll Fingerprint User with User ID Enroll Pass Code User 4. Lock Operation:... -
Page 2: Features And Technical Specifications
1TouchIQ2 Series Fingerprint Lock Introduction Features = “Free Passage” mode enables unit to be unlocked when desired = By default, the handle automatically locks door when shut = Audible rapid beep low battery warning = State of the art optical 560 DPI scanner insures quick & reliable fingerprint authentication = Bump-proof “Laser Cut Dimple Keys”... -
Page 3: Fingerprint Recognition Notes
1TouchIQ2 Series Fingerprint Lock Fingerprint Tips Fingerprint Recognition Notes Proper fingerprint placement is important when using any biometric device. Please be sure to use the tips below when using your fingerprint to authenticate with the 1TouchIQ2. Tip 1: Choosing The “Best” Finger Use either your Index, Middle or Ring finger, when enrolling and verifying your fingerprint. -
Page 4: Enrollment Options
1TouchIQ2 Series Fingerprint Lock User Enrollment Enrolling Fingerprint & Password Users When Entering Users into the Lock you have 3 Options: You can enroll fingerprints at random. You can enroll as an ID# (+) fingerprint user. You can assign users a pass code. -
Page 5: User Enrollment
1TouchIQ2 Series Fingerprint Lock User Enrollment NOTE: The scanner cover must be pulled up and activated before adding, deleting, or changing Codes or Fingerprint Users. The 1TouchIQ2 will automatically exit out of Programming Mode after 15 seconds. Please be sure... -
Page 6: Enroll Fingerprint User With User Id
1TouchIQ2 Series Fingerprint Lock User Enrollment 1.3 Enroll Fingerprint Users with User ID’s PRESS: 1 + # + Master Code + 3 digit User ID + # NOTE: At this point the scanner will light up. FIRST SCAN: Place the 1st finger on the scanner and remove when scanner light turns off. -
Page 7: Lock Operation
1TouchIQ2 Series Fingerprint Lock Lock Operation 2.1 Unlocking Door with Fingerprint To open with an enrolled fingerprint simply slide the cover up & place the finger gently on the scanner. NOTE: You will hear a beep & a click sound. Your door is now open. -
Page 8: Deleting Users
1TouchIQ2 Series Fingerprint Lock Deleting Users 3.1 Deleting a Fingerprint User with a User ID PRESS: 2 + # + Master Code + Users 3 Digit ID + Users 3 Digit ID Again + # NOTE: When successful the lock will make a solid single beep. If unsuccessful it makes 3 quick beeps. -
Page 9: Frequently Asked Questions
1TouchIQ2 Series Fingerprint Lock 4.1 Frequently Asked Questions 1) Where does the key go? You remove the decorative cover from the keyway using the black Magnetic Key Cover tool that came with the lock. 2) Can I get more keys made for my lock? This lock comes with 4 high security “Laser Cut Dimple”... -
Page 10: Troubleshooting The Lock
1TouchIQ2 Series Fingerprint Lock Troubleshooting 5.1 Troubleshooting the 1TouchIQ2 1) Be Sure You Are Using Fresh Brand Name Batteries!! The 1TouchIQ2’s internal circuitry and scanner requires a good source of power which is provided by the 4 AA batteries. Even when the audible low battery alarm is not enabled, occasionally the 1TouchIQ2 may not perform well due to insufficient power. -
Page 11: Performing A Factory Default
1TouchIQ2 Series Fingerprint Lock Factory Default 6.1 Performing a Factory Default FIRST: Please remove the back lock body cover NEXT: Disconnect the power cable from the battery pack. NOTE: Before moving on, reconnect the power cable and test your lock. If the lock now works properly it had a slight connection issue. -
Page 12: Disassembly And Assembly
1TouchIQ2 Series Fingerprint Lock 6.1 Disassembly and Assembly Disassembly: Using the tool represented in figure 1, remove the nut highlighted in figure 2. Slide the Back Body Cover, Figure 1 highlighted in figure 3, off of the Back Body of the 1Touch lock. - Page 13 1TouchIQ2 Series Fingerprint Lock 7.1 Accessing the Key Hole with the Magnetic Key Cover Tool FIRST: Locate the Magnetic Key Cover Tool. NEXT: Place the magnetic end of the tool directly on the Key Hole Cover. NEXT: Once magnetically attached, simply pull the tool away from the lock and the Key Hole Cover should separate and remain attached to the tool.
