Page 1: Table Of Contents
6. Frequently Asked Questions: 7. Troubleshooting the Lock: 8. Performing A Factory Default: 9. Setting the Directions of the Handle 10. Disassembly and Assembly: 11. Accessing the Key Hole 12. Technical Support http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 2: Features And Technical Specifications
FAR(False Acceptance Rate) <0.0001% Battery 4 AA Alkaline battery Working current 150-300mA Standby current 30uA Display Blue LCD Identification mode Fingerprint, Pin, Key Working temperature -4 ° to 140 ° F Working humidity 10%-97% http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 3: Fingerprint Recognition Notes
“core”, located in Tip 2, is making direct contact with the scanner. Apply medium pressure, or just enough to flatten GOOD the skin on your finger. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 4: Enrollment Options
& need to let a neighbor into your house. You tell them the pass code. When you get home you simply delete that pass code. *You can use any combination of all three enrollment options! http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 5: User Enrollment
REPEAT: You can keep adding fingerprints one after another at this stage. HINT: If a scan fails you will hear 3 beeps & the scanner goes off. Just repeat the steps above. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 6: Enroll Fingerprint User With User Id
Example: Master Code (pause) ID# (pause) New Code (pause) Repeat New Code When the new pass code is enrolled, close the slide cover, open it up & try the code to confirm your new code is working. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 7: Lock Operation
* + * + Master Code + # NOTE: Entering the code above will toggle Passage Mode between enabled status and disabled status. NOTE: Unlock by sliding the cover up or hitting the # button. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 8: Deleting Users
5.3 Delete ALL Pass Code Users PRESS: 3 + * + Master Code + # NOTE: When successful the lock will make a solid single beep. If unsuccessful it makes 3 quick beeps. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 9: Frequently Asked Questions
8) Can the lock be set to allow access when just turning the handle? No. The 1Touch evo3 can be set to passage mode that will allow ® access when lifting the slide cover or pressing ‘#’. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 10: Troubleshooting The Lock
5) Unable to change or add a code? When entering the different codes it’s advised to pause 2-3 seconds between entering of the new codes. (ex. Default code (pause) New Code (pause) New Code again.) http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 11: Performing A Factory Default
NOTE: After about 10-15 seconds you will hear a single beep indicating the lock has been reset. HINT: To confirm, slide the cover up & enter the default Master Code 11111111. It will open the lock. For more troubleshooting information visit: http://www.fingerprintdoorlocks.com/help/ http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 12: Setting The Directions Of The Handle
Using a fingerprint pull the switch up to release the handle, then turn the handle to the desired orientation. The handle will click into place and Figure 4 you are ready to install your lock. http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 13: Disassembly And Assembly
2 screws highlighted in figure 8. Replace the Back Body Cover highlighted in figure 7 Replace the nut highlighted in figure 6 Figure 8 For more installation information visit: http://www.fingerprintdoorlocks.com/help/ http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1... -
Page 14: Accessing The Key Hole
Key Hole Cover should separate and remain attached to the tool. 12.0 Technical Support For all technical issues, please contact: FAQ’s & Video Help Files: http://www.fingerprintdoorlocks.com/help/ Phone: 513.239.6322 Email: support@1touchlock.com http://www.1touchlock.com | Intelligent Biometric Controls, Inc. | v1.1...
