XX179-01-00
MODEL V5400QS
DIGITAL COLOR QUAD SPLITTER
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that
the operation will be entirely error free or perform precisely as described in the documentation. This system has not
been designed to be used in life-critical situations and must not be used for this purpose.
Copyright © 2007 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300
WEB: www.vicon-cctv.com
Vicon part number 8009-8179-01-00
Rev 507 Section 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V5400QS and is the answer not in the manual?

Questions and answers

Related Manuals for Vicon V5400QS

Summary of Contents for Vicon V5400QS

  • Page 1 DIGITAL COLOR QUAD SPLITTER Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.

  • Page 3: Fcc Notice

    FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15 for a Class B digital device. WARNING his equipment generates, uses and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television communications.

  • Page 4: Safety Precautions

    Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous voltage within the product’s enclosure that may be of...

  • Page 5: Front Panel

    Front Panel Key/Mode Functions: Button/Mode AUTO/QUAD VCR/PIP/ENTER MENU/ZOOM SHIFT Quad Mode Camera 1, 2, 3, 4 PIP screen Picture 2 x 2 To SHIFT Normal Mode (Live display) screen Full screen display (press display zoom in mode twice for FREEZE mode) Shift Mode Channel Camera 1, 2, 3, 4...

  • Page 6: Rack Installation

    Two brackets are supplied with the V5400QS for installing the unit in a standard 19-inch rack mount, if required. To install the brackets, remove the two screws on the side of the V5400QS, align the top two holes on the bracket with the holes on the side of the unit and fasten with the screws provided in the accessory kit.
  • Page 7 Rear Panel 1, 2, 3, 4 CAMERA IN: BNC connectors for four-camera signal inputs 1, 2, 3, 4 CAMERA OUT: BNC connectors for four-camera signal outputs (looping) VCR In: BNC connector for video signal input from VCR (VCR OUT) VCR Out: BNC connector for video signal output to VCR (VCR IN) Monitor output ALARM #1 6.

  • Page 8: Function Setup

    FUNCTION SETUP (SHIFT + MENU/ZOOM) FUNCTION SETUP 2004/ 12/ 14 10: 37 1. DISPLAY SETUP 2. CAMERA SETUP 3. BUZZER SETUP 4. DATE-TIME SETUP 5. ALARM SETUP 6. MOTION SETUP 7. EVENT LIST 8. SYSTEM SETUP ** VERSION XXX ** 1.

  • Page 9: Display Setup

    1. DISPLAY SETUP: FUNCTION SETUP 1. DISPLAY SETUP DISPLAY SETUP 2. CAMERA SETUP 1. DATE-TIME 3. BUZZER SETUP 2. CAMERA TITLE 4. DATE-TIME SETUP 3. VCR DATE-TIME 5. ALARM SETUP 4. VCR CAMERA TITLE 6. MOTION SETUP 5. BORDER SET WHITE 7.

  • Page 10: Camera Setup

    2. CAMERA SETUP: FUNCTION SETUP CAMERA SETUP PAGE 1. DISPLAY SETUP ** CHANNEL NUMBER 2. CAMERA SETUP 1. BRIGHTNESS 3. BUZZER SETUP 2. CONTRAST 4. DATE-TIME SETUP 3. SATURATION 5. ALARM SETUP 4. HUE 6. MOTION SETUP 5. GAIN 7. EVENT LIST 6.

  • Page 11: Buzzer Setup

    3. BUZZER SETUP: FUNCTION SETUP 1. DISPLAY SETUP BUZZER SETUP PAGE 2. CAMERA SETUP **SYSTEM BUZZER 3. BUZZER SETUP BUTTON BUZZER 4. DATE-TIME SETUP ALARM BUZZER 5. ALARM SETUP MOTION BUZZER 6. MOTION SETUP VLOSS BUZZER 7. EVENT LIST 8. SYSTEM SETUP **SYSTEM BUZZER ON/OFF (Buzzer function)

  • Page 12: Date-Time Setup Page

    4. DATE-TIME: FUNCTION SETUP 1. DISPLAY SETUP 2. CAMERA SETUP DATE-TIME SETUP PAGE 3. BUZZER SETUP 1.DATE 2000/00/00 2.TIME 12:12:12 4. DATE-TIME SETUP 5. ALARM SETUP 6. MOTION SETUP 7. EVENT LIST 8. SYSTEM SETUP 1. DATE : Current Year/Month/Day 2.

  • Page 13: Alarm Setup

    5. ALARM SETUP: FUNCTION SETUP 1. DISPLAY SETUP ALARM SETUP PAGE 2. CAMERA SETUP 1.ALARM SIGNAL1: 3. BUZZER SETUP 2.ALARM SIGNAL2: 4. DATE-TIME SETUP 3.ALARM SIGNAL3: 5. ALARM SETUP 4.ALARM SIGNAL4: 6. MOTION SETUP 5.ALARM DURATION: 7. EVENT LIST 6.ALARM INDICATE: 8.

  • Page 14: Motion Area Setup

    6. MOTION SETUP: FUNCTION SETUP 1. DISPLAY SETUP MOTION SETUP PAGE 2. CAMERA SETUP **MOTION FUNCTION 3. BUZZER SETUP **CHANNEL NUMBER 4. DATE-TIME SETUP 1.SENSITIVITY 5. ALARM SETUP 2.VELOCITY 6. MOTION SETUP 3.MOTION ACTIVE 7. EVENT LIST 4.MOTION AREA SETUP 8.

  • Page 15: Event List

    7. EVENT LIST: FUNCTION SETUP 1. DISPLAY SETUP 2. CAMERA SETUP EVENT LIST PAGE 3. BUZZER SETUP NO OCCURED TIME CH TYPE 4. DATE-TIME SETUP 5. ALARM SETUP 6. MOTION SETUP 7. EVENT LIST 8. SYSTEM SETUP Event List - Menu page displays event list, such as V-loss, alarm and motion list. 10 pages, 10 events per page display, for a total 100 entries.

  • Page 16: System Setup Page

    8. SYSTEM SETUP: FUNCTION SETUP 1. DISPLAY SETUP 2. CAMERA SETUP SYSTEM SETUP PAGE 3. BUZZER SETUP 1. DWELL INTERVAL: 4. DATE-TIME SETUP 2. CLEAN EVENT TABLE 5. ALARM SETUP 3. FACTORY DEFAULT 6. MOTION SETUP 7. EVENT LIST 8. SYSTEM SETUP SYSTEM SETUP PAGE 1.

  • Page 17: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.

  • Page 18: Coaxial Cable Recommendations

    Let the required picture quality and cable distance provide a guide in choosing the best cable type. For cables other than the approved Vicon types below, contact the manufacturers listed below. Note that “BC” refers to bare copper and “TC” refers to tinned copper.

  • Page 19: Vicon Standard Equipment Warranty

    (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion. Vicon reserves the right to make changes to its software in any of its products at any time and without notice.

  • Page 20: Corporate Headquarters

    Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Germany vin-videotronic infosystems gmbh...
