ViewSonic VP201b-1 Service Manual page 47

ViewSonic Model Number: VLCDS26064-2W
Rev: 1c
Item ViewSonic P/N Ref. P/N
1 E-L-0407-1587 2921021404
2 E-L-0407-1587 2921021437
3 M-SW-0815-0224 3000725101
4 M-MS-0808-8555 3080323801
5 A-VC-0101-0390 3080427000
6 A-VC-0101-0370 3080428100
7 A-PC-0106-0150 3090107601
8 HW-00002546 3100430500
9 M-SCW-0824-0690 3105051501
10 M-SCW-0824-0775 3105123700
11 M-SCW-0824-0776 3105221000
12 M-SCW-0824-0777 3105225300
13 M-SCW-0824-0784 3109010700
14 M-SCW-0824-0732 3109010900
15 M-SCW-0824-0413 3109011400
16 M-MS-0808-8040 3110250000
17 M-LB-0813-0785 3200158900
18 M-LB-0813-0712 3200449700
19 M-MS-0808-8556 3200649100
20 M-LB-0813-0978 3200787200
21 DC-00001889 3201985200
22 M-LB-0813-0714 3202310700
23 DC-00000424 3202334500
24 DC-00000639 3209216600
25 M-MS-0808-8624 3211030700
26 #N/A 3220130500
27 M-00001851 3220130800
28 M-MS-0808-7011 3220131000
29 M-MS-0808-8202 3220133600
30 M-MS-0808-0724 3220161733
31 M-MS-0808-7463 3220501600
32 M-MS-0808-7810 3220605633
33 M-MS-0808-4975 3221101500
34 M-MS-0808-0918 3221903300
35 M-MS-0808-1679 3222201300
36 M-00001850 3222201510
37 M-MS-0808-1680 3222400310
38 M-MS-0808-8557 3240055600
39 M-MS-0808-2276 3240160801
40 M-MS-0808-5271 3240498900
41 M-MS-0808-2631 3240946900
42 PL-PD-0714-0066 3240954400
43 PL-PD-0714-0140 3240970900
44 M-MS-0808-8627 3241127400
45 M-00002548 3241194300
46 PL-NB-0707-0192 3360624900
47 M-CV-0830-2446 3362010801
48 #N/A 4020374207
49 #N/A 4020374208
50 #N/A 4020374209
51 #N/A 4020374214
52 C-00001884 3368224100
53 M-MS-0808-8622 3200649200
54 #N/A 4020374207
55 #N/A 4020374208
56 #N/A 4020374209
57 #N/A 4020374214
58 #N/A 3360257200
59 #N/A 4020374207
60 #N/A 4020374208
61 #N/A 4020374209
62 #N/A 4020374214
63 M-MS-0808-8561 3460146100
64 M-MS-0808-8563 3460146300
65 C-00002551 3368321000
66 M-MS-0808-8559 3360506800
67 #N/A 4020370614
68 #N/A 3361502000
69 #N/A 4020372907
70 #N/A 4020372908
71 #N/A 4020372909
72 #N/A 4020372914
73 C-00001885 3368990304
74 M-SCW-0824-0781 3105127100
75 M-SCW-0824-0778 3105229400
76 M-SCW-0824-0782 3105280200
77 M-SCW-0824-0779 3109017700
ViewSonic Corporation
BOM LIST (VP201b-1 for "AUO Panel")
Description
CORE BEAD 40*6.5*10 W5H+TAPE
CORE BEAD 40*6.5*10 A5 +TAPE
SWITCH MEMBRANCE PET 99.5*9 VP181-2
CABLE USB 2.0 A_B L1800 BLACK
CABLE D-SUB/D-SUB L1800 BLK OD7.5
CABLE DVI-D TO DVI-D L1800 P001
AC POWER CORD L=1800 BLK NA #18*3C SVT C
SCREW M M3*0.5*5 PAN C S18C ZN BLK
SCREW M #4-40*7 HEXH #4-40*3 S18C NI
SCREW M M4*0.7*10 FF C S18C ZN BLK NYLOK
SCREW M M3*0.5*6 FF C S18C ZN
SCREW M M3*0.5*4 FF C S18C ZN
SCREW T M3*0.5*7 PAN C S+P S20C ZN
SCREW T M3*0.5*4 BIND C S18C ZN YEL
SCREW T M3*0.5*6 BIND C S18C ZN YEL
WASHER SPRING SWRT
LABEL STICKER OD10 WHT HI-POT
LABEL WARING
NAME PLATE VSC 3-BIRD LOGO AL 11.07*7.92
LABEL BAR CODE 124*82
LABEL ID 100*50 VSC VP201B L20DBW
LABEL HV WARNING 100*25
LABEL WARNING 81.7*81.7 VSC
LABEL USB 35*20 VSC VP SERIES
MYLAR FILM 430*330 T.1 L20CBR05ACA
TAPE W=17 #1350F-1 3M
TAPE W=20 #1350F-1 3M
TAPE W=23 #1350F-1 3M
TAPE W=10 #1350F-1 3M
TAPE W=20 #3800A NITTO
TAPE W=30 #10 3M
TAPE W=45 #7290 NITTO
TAPE W=76 PP47 914M 4P
TAPE PE W=50 VIEWSONIC SECURITY
TAPE AL FOIL W=25 #80023 CATERON
TAPE AL FOIL W=50 TAPE AL-35FR 3M
TAPE W=16 #897 3M
CONDUCTIVE TAPE AL W50*L55 1120
SPONGE EVA 5.8*5 T.5 BLK
RUBBER PAD 25*10*1.5 BLACK STICK
RUBBER SILICON 12*12 T5
RUBBER PAD 25*25*2
RUBBER PAD 22*4 T3 BLK
INSULATOR PC 231*13 T.5
INSULATOR PC 130*118.5 T.43 BLK
POWER KNOB POM M270 MIDNIGHT GRAY S8LRB1
COVER VESA ABS MIDNIGHT GRAY-2 S8LRB1LS
PLASTIC ABS 94HB MIDNIGHT GRAY-2 D-180
PLASTIC ABS 94HB MIDNIGHT GRAY-2 HF-380
PLASTIC ABS 94HB MIDNIGHT GRAY-2 SD-0150
PLASTIC ABS 94HB MIDNIGHT GRAY-2 PA-707
CABINET ASSY L20DBW05ABB S0LRA1AT
NAME PLATE VIEWSONIC ABS 82.83*34.98
PLASTIC ABS 94HB MIDNIGHT GRAY-2 D-180
PLASTIC ABS 94HB MIDNIGHT GRAY-2 HF-380
PLASTIC ABS 94HB MIDNIGHT GRAY-2 SD-0150
PLASTIC ABS 94HB MIDNIGHT GRAY-2 PA-707
CABINET BACK ABS MIDNIGHT GRAY-2 S0LRA1A
PLASTIC ABS 94HB MIDNIGHT GRAY-2 D-180
PLASTIC ABS 94HB MIDNIGHT GRAY-2 HF-380
PLASTIC ABS 94HB MIDNIGHT GRAY-2 SD-0150
PLASTIC ABS 94HB MIDNIGHT GRAY-2 PA-707
BRACKET VESA SECC 110*20 T1
BRACKET KEYLOCK SECC 20.4*16.45*4.9 T.6
F/B ASSY L20DBW05DBB S0LFA1AT
LED LENS ABS 1865-12 S8LRB1LS
PLASTIC ABS 94HB 1865-12 PA-758
F/B ABS MIDNIGHT GRAY-2 VP201B S0LFA1AT
PLASTIC ABS 94HB 5140 D-180
PLASTIC ABS 94HB 5140 HF-380
PLASTIC ABS 94HB 5140 SD-0150
PLASTIC ABS 94HB 5140 PA-757
STAND ASSY L20CBW05ABB S8LBB1LS
SCREW M M4*0.7*12 FF C S18C ZN NL
SCREW M M3*0.5*10 FF C S18C ZN
SCREW M M3*0.5*4 FF C S18C ZN BLK
SCREW T M3*2.7*7.5 FF C S18C ZN YEL
44
Location
Confidential - Do Not Copy
Q'ty Unit
1 PCE
0 PCE
1 PCE
1 PCE
1 PCE
1 PCE
1 PCE
4 PCE
4 PCE
4 PCE
6 PCE
6 PCE
1 PCE
4 PCE
4 PCE
4 PCE
1 PCE
0 PCE
1 PCE
1 PCE
1 PCE
1 PCE
1 PCE
1 PCE
0 PCE
0.05 MTR
0.062 MTR
0.05 MTR
0.04 MTR
0.15 MTR
0.29 MTR
0.128 MTR
0.8 MTR
1.028 MTR
0.465 MTR
0.11 MTR
0.03 MTR
1 PCE
1 PCE
1 PCE
2 PCE
1 PCE
1 PCE
1 PCE
1 PCE
1 PCE
1 PCE
64 GRM
0 GRM
0 GRM
0 GRM
1 PCE
1 PCE
4 GRM
0 GRM
0 GRM
0 GRM
1 PCE
520 GRM
0 GRM
0 GRM
0 GRM
1 PCE
1 PCE
1 PCE
1 PCE
0.1 GRM
1 PCE
160 GRM
0 GRM
0 GRM
0 GRM
1 PCE
4 PCE
1 PCE
2 PCE
2 PCE
VP201b/s-1
