i3TOUCH V-SENSE
V7004 T10 USER MANUAL
SENSE
SENSE
SENSE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i3TOUCH V-Sense V7004 T10 and is the answer not in the manual?

Questions and answers

Related Manuals for i3 i3TOUCH V-Sense V7004 T10

Summary of Contents for i3 i3TOUCH V-Sense V7004 T10

  • Page 1 i3TOUCH V-SENSE V7004 T10 USER MANUAL SENSE SENSE SENSE...

  • Page 2: Table Of Contents

    6. Product specification …..………………………………………………………..............23 6.1 Specification 6.2 OPS Specifications(Optional) 7. Product dimensions ……………………………………………………………................25 7.1 LED Dimensions 8. Troubleshooting ………………………………………………………………................26 8.1 Product self-Diagnosis 8.2 Before Requesting service 9. Customer support and AS guide………………………………………………..............27 9.1 Before Request AS 9.2 AS COST www.i3-technologies.com...

  • Page 3: Safety Precautions

    1. Important Safety Instructions Icons used for safety precautions ICON NAMEN MEANING Failing to follow the precautions marked with this sign Warning may result in a serious injury or even a fatality. Failing to follow the precautions marked with this sign may Caution result in a personal injury or property damage.
  • Page 4 1.1.2.9 Avoid installing the product where children may reach it. » If a child touches the product, the product may fall and this may result in injury. » Since the front part is heavier, install the product on a flat and stable surface. www.i3-technologies.com...
  • Page 5 1.1.2.10 Bend the outdoor antenna cable downwards at the location where it comes in the house so that rainwater does not flow in » If rainwater enters the product, it may result in electric shock or fire. 1.1.2.11 Install the antenna far away from any high voltage cables. »...
  • Page 6 1.1.4.10 When a gas leak occurs, do not touch the product or the power plug and ventilate immediately. » A spark may result inan explosion or fire. » During a thunder or lighting storm, do not touch the power cord or antenna cable. www.i3-technologies.com...
  • Page 7 1.1.4.11 Avoid lifting up or moving the product by holding only the power cord or signal cable. » Otherwise, it may result in electric shock, fire or a problem with the product due to damage to the cable. 1.1.4.12 Avoid using or placing inflammable spray or objects into the product(the vents, ports, etc) »...
  • Page 8 • Table stand and put them on the table by using the installation gets the nose does not necessarily prevent a fall on the floor using the screws fixed. Attention: In order to reduce the risk of electric shock. Do not open the cover or backcover. If you have a product or service, please request our customer support center. www.i3-technologies.com...

  • Page 9: Care And Maintenance

    1.2 Care and Maintenance External Surface and Screen Maintenance Clean the product with a soft dry cloth. • Avoid cleaning the product with an inflammable substance such as benzene or thinner or with a wet cloth. This may result in a problem with the product. •...
  • Page 10 - If any items are missing, contact your dealer. - Contact a local dealer to purchase optional items. LED Display Contents User Manual Cable HDMI Cable TOUCH Senser Cable Power Cable RGB cable Accessory Remote Control Battery(CR-2025 x 1) PEN x 2 www.i3-technologies.com...

  • Page 11: Front View

    3. Each description 3.1 Front View Speaker 1. POWER( ) : Turns the LED Display On/Off. 2. LED Indicator 1 2 3 4 Shows Power ON mode -- BLUE Power Saver mode by blinking RED. Shows Power OFF mode -- RED. . 3.
  • Page 12 2. HDMI cable will be connected to (display and voice are available at the same time)7 8 9. 3. External speaker will be connected to 1, 2 input with using Ø3.5 stereo cable and then connect same as below drawing. L, R connection is same. Internal speaker will not output. Note) Don’t connect NC. www.i3-technologies.com...
  • Page 13 4. Remote Control 4.1 How to insert battery. Insert the battery into proper polarities. Battery model:(CR-2025 3V) i3TOUCH V- SENSE 7004 T10 - operations manual...
  • Page 14 • Custom adjustment CSM Press the buttons to highlight the Red, Green or Blue level. Next, press the ENTER button to select one of them. Once selected, press the buttons to ad- just the Red, Green, or Blue level. www.i3-technologies.com...
  • Page 15 • Picture Select mode Press or the Menu button to move or go back to the previous menu options. Press the buttons to highlight PSM (Picture Status Mode), and press the ENTER button to see the available options. Press the buttons to select highlight either Dynamic/Standard/Mild/Game/User, and press ENTER to select one.
  • Page 16 Menu Button to move or go back to the previous menu options. Press Button to highlight the Balance Menu, and press the ENTER button to adjust the settings. Press the buttons to adjust the Left/Right Balance value. www.i3-technologies.com...
  • Page 17 • Equalizer Adjustment Press or the Menu Button to move or go back to the previous menu options. Press Button to highlight the Equalizer Menu, press the ENTER button to view the settings. Press the buttons to highlight one of the 0.1/0.5/1.0/5.0/10kHz values.
  • Page 18 The other options allow you to choose how often you want the display to automatically turn on (once/daily). Finally, you can choose to have this feature ON or OFF. Exit to save your settings. www.i3-technologies.com...
  • Page 19 • Setup Auto Sleep If Auto Sleep mode is ON, the screen will go to sleep when no input signal is received and 5 minutes have passed. Press or the Menu Button to move or go back to the previous menu options. Press the buttons to highlight Auto Sleep, and press the ENTER button to change the settings.
  • Page 20 • Change the OSD Language Press the buttons to select Language, and press the ENTER button to view and select available languages. Use the buttons to highlight the language you would like to use and press the ENTER button to select it. www.i3-technologies.com...
  • Page 21 • Setup Child Lock (deactivate display buttons) Press or the Menu Button to move or go back to the previous menu options. Press the buttons to highlight Child Lock, and press the ENTER Button. Press the buttons to select ON or OFF. Press the ENTER button to choose either option.
  • Page 22 Press the buttons to select the temperature setting at which the fan will operate. Values between 35˚C~80˚C are possible. Press the ENTER button to select the level. After finishing your adjustments, press the [Exit] button to exit the OSD MENU. www.i3-technologies.com...

  • Page 23: Specification

    6.Product Specification 6.1 Specifications Note: Product design and features without prior notice may be changed. Items 70 inch Detection method IR Bar Touch sensor system Touch tool / Response time Hand or other solid object / 15ms, 10 multi touch points Supported OS Windows 7 / 8, MAC Effective screen size(mm)
  • Page 24 Current Temp. Display (-10 Degree ~ 100 Degree) Temp. Control High Temp Setting Capable(for fan control) Component (Optional) 480i/480P/576I/576P/720P/1080I/1080P HDMI, DisplayPort 1080P(50Hz/60Hz), 1080i(50Hz/60Hz), 720P(50Hz/60Hz), 576P(50Hz), 480P(60Hz) 720*400(70Hz) 640*480(60Hz/72Hz/75Hz) Resolution SVGA 800*600(56Hz/60Hz/72Hz/75Hz) 1024*768(60Hz/70Hz/75Hz) SXGA 1280*1024(60Hz) WXGA 280*768(60Hz/75Hz),1360*768(60Hz/75Hz) WSXGA 1600*1200(60Hz), 1920*1080(60Hz) WUXGA 1920*1080(60Hz) www.i3-technologies.com...
  • Page 25 • Design and Specifications are subject to change without notice. • Table stand (optional) 6.5 OPS(Open Pluggable Specification)-Option Item Description Intel OPS Architecture Thermal Architecture System FAN with heat sink for heat dissipation Chassis Made by heavy steel Dimension 119mm(D) x 200mm(W) x 30mm(H) Color Front Panel in Black Mount...
  • Page 26 1x double-stack type A USB connector for 2x USB 3.0 ports HDMI 1x HDMI connector Antenna Hole 2x SMA-type for WiFi Antenna Environment Specification Operating Temperature Operating: -5°C to +45°C Storage: -20°C~80°C AOPS-554 Specification i5-3210M Memory DDR3 4G 2.5” 500G Embedded Win 8.1 www.i3-technologies.com...

  • Page 27: Led Dimensions

    7. Product Dimensions 7.1 LED Dimensions i3TOUCH V- SENSE 7004 T10 - operations manual...

  • Page 28: Product Self-Diagnosis

    » Check the volume level. If the volume is still too low after turning the control to its maximum, check the volume control on the computer sound card or software program. 8.2.3 PROBLEMS RELATED TO REMOTE CONTROL. 8.2.3.1 The remote control buttons do not respond. www.i3-technologies.com...

  • Page 29: Before Request As

    » Check if a special fluorescent or neon lamp is on in the vicinity. 9. Customer support and AS guide. 9.1 Before request AS 9.1.1 Before requesting support, please check the most up-to-date manual & FAQ on the i3 learning website: www.i3-learning.com 9.2 AS Cost 9.2.1 Our warranty period is 2 years. 9.2.2 A/S is the cost incurred to our bylaws, item rated A/S price is determined according to the criteria, accurate repair cost, please contacts a customer support counseling over the phone.

  • Page 30: Www.i3-Technologies.com
