Trailer Vision Super i-track Instruction Manual

Super i-track
GPS Tracking Device
With 4-years Standby Battery

INTRODUCTION

This stand alone unit is a multi-function state-of-the-art GPS tracker that provides a 4 in 1
solution by utilising GPS/GSM/GPRS/SMS/DTMF; the most flexible tracking device in the world,
a great marriage of the latest technology and affordability.
With this multi-function tracker, you can track, remotely control and locate any object
Globally. The user can also check the real time location from a GPRS tracking web site, or by
using the supplied tracking software installed on any PC. Real time position can also be found via
the regular dial tone transmission (DTMF).
Super i-track is the best tracking solution for use in the widest range of applications, from motor-
homes to horseboxes, from cars to caravans, from agricultural machinery to construction
equipment and from containers to golf carts; all the assets that you feel could be at risk,
especially if they do not have their own source of power.

FITTING

Position the tracker so that it isn't completely surrounded by metal and ideally so that no metal is
above it's location (if this isn't possible, then test the operation in the desired positition, before
completing the installation). The waterproof case allows the tracker to function even when
positioned in the harshest of environments and the internal battery provides an independent
power supply even if there is no external power. The built-in movement sensor enables the
tracker to totally 'switch off' (10 mAh), which means that it can operate for over 4 years, if
stationary for long periods of time. Additionally, the tracker will not drain any external battery (ie if
connected to a leisure/vehicle battery etc).

FEATURES

Super i-track provides many advantages:
• Free GPRS tracking software Platform and server (if you have your own server we can
program the tracker with your server protocol)
• Worldwide coverage with NO additional software/programs to buy or install - no additional or
hidden costs!
• Built-in movement sensor with deep sleep mode (0.1mA)
• Built-in 5,500 mAh battery for independent power
• Stand-by time 4 yrs+ (depending on tracking needs)
• High sensitivity GPS receiver
• Multiple tracking modes
• Waterproof case
• Options for different tracking applications
• Strong Magnetic base/mount for easy attachment
• Stand alone (Internal Antenna - Self Contained Unit)
• Switch between the DTMF mode or GPRS
• Worldwide coverage using GSM/GPRS/SMS/DTMF
• Monitor both on demand, or at regular intervals
