6. ADJUSTABLE OUTER FLANGE CLAMPING
The outer flange should be adjusted to suit different
disc thickness. For thinner cutting discs the raised part
of the outer flange is fitted facing away from the disc.
For thicker grinding discs the raised part of the outer
flange is fitted facing towards the disc to provide
improved support for the disc hole. Always ensure your
disc is securely clamped.(Fig.6)
Fig.6

7. REMOVING DISC

To remove the disc, press the spindle-lock button in
deep and hold it in this position continuously. If
necessary, turn the spindle slightly with the free hand
until it locks into position.
Loose the flange with the spanner provided and then
removes the disc from spindle.
CAUTION!
Check the diameter of disc regularly during use. If it is
less than 80mm, replace it!
810W 115mm ANGLE GRINDER ENB461GRD
