Recordex Magnifica Electric Screen Control Options
Easy Plug & Play Installation. Simply mount the in-line wall switch using the
supplied mounting hardware, plug in your screen, and start using your
RangePlus IR Remote and wall switch to control the screen motion.
Estimated Installation Time: 5 Minutes
Figure 1. Standard Control Option
DETAIL OF 12V Wireless
IR SCREEN TRIGGER
To Projector's
12V Trigger
Port
Figure 2. Optional Projector Control (12V IR Trigger)
www.recordexusa.com - 478-237-5501
(excludes mounting the screen)
Video Projector
12V IR Trigger
IR TRANSMITTER
BULB
Simple & Professional Screen Solutions from
DETAIL OF WALL SWITCH
& IR RECEIVER
Installation
Simply mount the 12V Trigger Control to the projector using
the supplied two sided Velcro tape and plug the control into
the projector's 12V trigger port using one of the five universal
connector tips included with the trigger control.
Match the 12 V IR Trigger to the Wall Switch/IR Receiver by
following the directions on the reverse of this page.
Estimated Installation Time: 5 - 10 Minutes
From
Screen
IR EYE
65' range (20m)
CEILING
RecordexUSA
To 110V
Outlet
RangePlus
IR Remote
Control
SCREEN
Wall
Switch
Standard
110V Wall
Outlet
