- Page 1 WARRANTY YEARS ERB062VAC ERB063VAC WET/DRY VACUUM TVC125S1 TVC140S1-M-070924.indd 1 2007-9-25 9:44:17...
- Page 2 TVC125S1 TVC140S1-M-070924.indd 2 2007-9-25 9:44:17...
- Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read all instructions. Failure to follow all instructions listed below may result in serious injury. This product should never be left unattended when connected to the mains supply. SAVE THESE INSTRUCTIONS •This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 5 SYMBOLS Read the manual Warning Wear gloves Wear dust mask,eye & ear protection Conforms to relevant safety standards WET/DRY VACUUM TVC125S1 TVC140S1-M-070924.indd 5 2007-9-25 9:44:18...
- Page 6 SOCKET FOR POWER TOOLS FILTER BASKET(SEE FIG 8) LATCH CONTAINER WHEEL HOSE CONNECTION PIECE VACUUM HOSE BLOWER HEAD ON/OFF SWITCH/OPERATING MODE SWITCH 10. BUTTON 11. COMBI NOZZLE 12. DUST BAG (SEE FIG 9) 13. FOAM FILTER (SEE FIG 8) 14. CREVICE NOZZLE 15.
-
Page 7: Technical Data
TECHNICAL DATA Model NO. ERB062VAC ERB063VAC Rated voltage 230V~50Hz 230V~50Hz Rated input power 1250W 1400W With power take-off socket 1500W 1500W Capacity Protection against ingress of water IPX4 IPX4 Machine weight 6.5kg 7 .1kg ACCESSORIES Vacuum hose Extension tube Combi nozzle... - Page 8 Note: Before using the tool, read the instruction book carefully. MOUNTING 1. Assemble the wheels (See Fig 1, 2) Push each wheel into the base of the container ensuring correct orientation. The wheels are friction fit. 2. Assemble the hose Fig 1 Caution: This...
- Page 9 Push the combi nozzle (11) to the other end of the extension tube. (See Fig 5) Pressing the button (10) and pulling the end of the extension tube can change the length of it. 3. The function of the nozzle Fig 5 Fig 6 WET/DRY VACUUM...
-
Page 10: Operation
OPERATION Observe correct mains voltage: The voltage of the power source must agree with the voltage specified on the nameplate of the machine. Equipment marked with 230 V can also be connected to 220V. Operation with remote automatic switching (Fig 7) A socket outlet with earthing contact is integrated Fig 7 in the vacuum cleaner. -
Page 11: Dry Vacuuming
to 0. Note: When the maximum filling height is reached, switch off the machine immediately. Before opening and emptying, always pull the plug from the socket outlet. DRY VACUUMING 1. Slip the dust bag onto the socket for dry vacuum-cleaning. The dust bag is suitable only for dry vacuum-cleaning. -
Page 12: Plug Replacement
PLUG REPLACEMENT If you need to replace the fitted plug then follow the instructions below. Important The wires in the mains lead are coloured in accordance with the following code: Green & yellow - Earth Blue - Neutral Brown - Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in... -
Page 13: Declaration Of Conformity
Declaration of Conformity We, Importer Erbauer (UK) LTD BA22 8RT Declare that the product WET/DRY VACUUM ERB062VAC/ERB063VAC Complies with the following Directives, EC Low Voltage Directive 2006/95/EC EC Electromagnetic Compatibility Directive 2004/108/EC 2002/95/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Standards and technical specifications referred to:... - Page 14 TVC125S1 TVC140S1-M-070924.indd 14 2007-9-25 9:44:28...
- Page 15 TVC125S1 TVC140S1-M-070924.indd 15 2007-9-25 9:44:28...
- Page 16 TVC125S1 TVC140S1-M-070924.indd 16 2007-9-25 9:44:28...
