- Page 1 WARRANTY YEARS ERB064VAC 50L WET/DRY VACUUM TVC141S1-M-070924.indd 1 2007-9-25 9:45:10...
- Page 2 TVC141S1-M-070924.indd 2 2007-9-25 9:45:10...
- Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read all instructions. Failure to follow all instructions listed below may result in serious injury. This product should never be left unattended when connected to the mains supply. SAVE THESE INSTRUCTIONS •This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 5 SYMBOLS Read the manual Warning Wear gloves Wear dust mask,eye & ear protection Conforms to relevant safety standards 50L WET/DRY VACUUM TVC141S1-M-070924.indd 5 2007-9-25 9:45:11...
- Page 6 SOCKET FOR POWER TOOLS BLOWER HEAD PUSH HANDLE LATCH DRAIN TUBE HOLDER REAR WHEEL DRAIN OUTLET FRONT WHEEL VACUUM HOSE 10. HOSE CONNECTION PIECE 11. FILTER BASKET ( SEE FIG 15) 12. ON/OFF SWITCH/OPERATING MODE SWITCH 13. BUTTON 14. COMBI ZOZZLE 15.
-
Page 7: Technical Data
TECHNICAL DATA Rated voltage 230V~50Hz Rated input power 1400W With power take-off socket 1500W Capacity Protection against ingress of water IPX4 Machine weight 11.9kg ACCESSORIES Vacuum hose Extension tube Combi nozzle Crevice nozzle Foam filter Dust bag Drain tube Front wheels 2pcs Rear wheels 2pcs... - Page 8 Note: Before using the tool, read the instruction book carefully. MOUNTING 1. Assemble the wheels a. Push the front wheels into the base of the container ensuring correct orientation.The wheels are friction fit. b. Unscrew the bolts on the steel bar and take off the bar from the base.
- Page 9 e. Screw the wheel lock-knob into the hole above the rear wheel. Screw tightly to fix the wheel, vice versa. (See fig 5) f. For convenience, put the crevice nozzle into the hole on the base of the container. (See fig 6) 2.
- Page 10 b. Connect one end of the extension tube to the vacuum hose firmly. (See Fig 9) c. Push the combi nozzle (14) to the other end of the extension tube. (See Fig 10) d. Pressing the button (13) and pulling the end of the extension tube can change the length of it.
- Page 11 3. The function of the nozzle Fig 13 50L WET/DRY VACUUM TVC141S1-M-070924.indd 11 2007-9-25 9:45:18...
-
Page 12: Operation
OPERATION Observe correct mains voltage: The voltage of the power source must agree with the voltage specified on the nameplate of the machine. Equipment marked with 230 V can also be connected to 220V. Operation with Remote Automatic Switching (Fig 14) A socket outlet with earthing contact is integrated Fig 14 in the vacuum cleaner. -
Page 13: Dry Vacuuming
reached, switch off the machine immediately. Before opening and emptying, always pull the plug from the socket outlet. DRY VACUUMING 1. Slip the dust bag onto the socket for dry vacuum-cleaning. The dust bag is suitable only for dry vacuum-cleaning. 2. -
Page 14: Plug Replacement
PLUG REPLACEMENT If you need to replace the fitted plug then follow the instructions below. Important The wires in the mains lead are coloured in accordance with the following code: Green & yellow - Earth Blue - Neutral Brown - Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in... - Page 15 Declaration of Conformity We, Importer Erbauer (UK) LTD BA22 8RT Declare that the product 50L WET/DRY VACUUM ERB064VAC Complies with the following Directives, EC Low Voltage Directive 2006/95/EC EC Electromagnetic Compatibility Directive 2004/108/EC 2002/95/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Standards and technical specifications referred to:...
- Page 16 TVC141S1-M-070924.indd 16 2007-9-25 9:45:21...
