Page 1: User Manual
CCTV LCD Monitor User Manual For models: EL-17MC2RFTC EL-19MC2RFTC ______________________________________... -
Page 2: Table Of Contents
Contents 1. Introduction………............................1 2. Work Safety Information..........................2 2.1. Product Safety Precautions information......................2 2.2. Safety Guidelines............................3 2.3. Important Notice Concerning Power Cord Selection..................3 2.3.1 For the United States and Canada....................... 3 2.3.2 For European Countries........................3 2.3.3 For the United Kingdom........................4 3. -
Page 3: Introduction
Introduction Thank you for purchasing the professional CCTV LCD Monitor and welcome to a fantastic new technology that will completely change the way you look at monitors. The following sections describe just a few of the major advantages of this LCD monitor. You’ll discover more of its wonderful features as you use it. -
Page 4: Work Safety Information
Work Safety Information Caution and Warning CAUTION !! RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No internal parts can be serviced by users. Refer servicing to qualified personnel. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS CCTV LCD MONITOR TO RAIN OR MOISTURE. -
Page 5: Safety Guidelines
Safety Guidelines WARNING This device must be operated with the original power supply. The socket outlet should be installed near the equipment and should be CAUTION easily accessible. Use a power cord that is properly grounded. Always use the appropriate AC power cord that is certified for the individual country. -
Page 6: For The United Kingdom
2.3.3 For the United Kingdom For your safety please read the following text carefully. If the fitted molded plug is unsuitable for the socket outlet, then the plug should be cut off and disposed of safely. Do not plug the cut-off plug into a socket outlet! There is a danger of severe DANGER electrical shock! If a new plug is to be fitted, please observe the wiring code as shown below. -
Page 7: Standards And Guidelines
Standards and Guidelines FCC Requirements This device complies with Part 15 of the FCC Rules and Regulations. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must tolerate any interference encountered, including interference that may cause improper operation. -
Page 8: Rohs Compliance Statement
RoHS Compliance Statement This display defined in this user manual is 100% RoHS complaint and meets all the requirements set forth in European Union Directive 2002/95/EC, Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment. Information on Disposal for Your Old Product Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. -
Page 9: Hardware Installation
Hardware This chapter will guide you through the correct installation procedures for the LCD monitor. 4.1. Checking the Accessories Supplied LCD monitor body x 1 pc Desk Stand x 1 pc AC power cord x 1 pc Adaptor x 1 pc D-Sub 15-pin cable (1.8 Meter) x 1 pc Ø... -
Page 10: Connections
5.2 Connections 2 3 4 5 Item Connector Function Connect to PC to initiate the touch panel Please connect the Ø 3.5mm Alarm cable to DVR alarm output and provide Alarm +3~5V DC Voltage to trigger the PIP, the sub screen will show the “Alarm Message”... -
Page 11: Id Remote Controller
6. ID Remote Controller . POWER switch. Press to turn ON or turn OFF the LCD Monitor. VIDEO SIGNAL Selection: Press the “AV1” , “S-VIDEO”, “D-SUB”, “HDMI” button to enter the selected video source or press the “SOURCE” button to have the cycle video selection. Remark: “AV2”... - Page 12 . ID and Number Key: Step 1: Setup the Monitor ID No. Press “MENU“ to enter the OSD menu and press “ “ button to select the “Function“ menu and press ”ENTER” to access into item option. Press “ DOWN” to choose “ID ▼...
-
Page 13: Osd Setup
7. OSD Setup Picture (Video / HDMI Mode) 1. Press the “Menu/Enter” key on the buttons to call out the OSD Menu . Press “ to select ▲ / + ” o r “ ▼ / - “ “Picture” mode and press “Menu/Enter” key again to access into item option . - Page 14 Sound Effect (Video/HDMI Mode) 1. Press the “Menu/Enter” key on the buttons to call out the OSD Menu . Press “ to select “Sound ▲ / + ” o r “ ▼ / - “ Effect” and press “Menu/Enter” key again to select the item you want to adjust.
- Page 15 language you want. There are 7 languages to select (1) English (2) French (3) Germany (4) Spanish (5) Italian (6) Russian (7). Chinese Image Mode (Video/HDMI mode) In order to meet different applications in video output, there are 5 image ratio to choose (1) Full Scan (2) Under Scan-V (3).
-
Page 16: Osd Time
4. Over Scan-1 The format is over scan mode to make the image fill up the screen and cut about 3% on both “Vertical” and “Horizontal” lines. 5. Over Scan-2 The format is another over scan mode to make the image fill up the screen and cut about 6% on both “Vertical”... - Page 17 (2) Medium (3) Low (4) Off. Press “Menu/Enter” and press “ key to select the level. ▲ / + ” o r “ ▼ / - “ ID Controller The ID function is only applicable for some specific models, if the model you brought has the ID function, Please check the ID setup procedure on page 9.
-
Page 18: Color Temp
swap the main screen and sub-screen Picture (VGA Mode) 1. Press the “Menu/Enter” key on the buttons to call out the OSD Menu . Press “ to select ▲ / + ” o r “ ▼ / - “ “Picture” mode and press “Menu/Enter” key again to access into item option . -
Page 19: Auto Adjust
select “V-Position” . Press “ key to increase “Pink bar” to shift the picture up or press to decrease ▲ / + ” “ ▼ / - “ “Pink bar” to shift the picture down. Auto Adjust Use “Auto Adjust” to fine-tune the display to perfectly synchronize to the video signal source under RGB mode. Press “Menu/Enter”... -
Page 20: Troubleshooting Guide
1. Full The image fully fills up the 5:4 screen on both “Vertical” and “ Horizontal” lines. 2. 4:3 The format is the “Letter Box” under scan mode that will create a black bar on top and bottom of frame Multi Screen (VGA Mode) The setup is the same as page No. - Page 21 Check if the LCD Monitor power switch is at the “on” position and the LED on the front of LCD Monitor is in still green. Check if the computer or AV equipment video (signal) cables are properly secured. Abnormal image Check and make sure the computer or AV equipment video (signal) cables are properly and securely connected to the sockets on back of the LCD Monitor.
-
Page 22: Applicable Video Timing For Pc- Analog Video
Applicable Video Timing for PC- analog Video The following table list are the better display quality modes for analogy signal (PC) supported by this LCD monitor. The LCD monitor will stop working or has poor picture quality when other modes out of below list input. -
Page 23: Technical Data
10. Technical Data Model EL-17MC2RFTC EL-19MC2RFTC System Panel Size 17" LCD 19" LCD Touch Plate Capacitive Type Capacitive Type Resolution 1280 x 1024 1280 x 1024 Pixel Pitch (H xV) 0.264(H) x 0.264(V) 0.294(H) x 0.294(V) Contrast Ratio 1000:1 1000:1... -
Page 24: Drawing & Dimension
11.Drawing & Dimension For Model No.: EL-17MC2RFTC For Model No.: EL-19MC2RFTC...
