EnGenius EUB-3701 EXT Quick Start Manual

IEEE 802.11b/g USB 2.0 Client Adapter
The high-speed wireless USB 2.0 client adapter is the most convenient way to let you put a
desktop/notebook computer almost anywhere without the hassle of running network cables. Now
you don't need to suffer from drilling holes and exposed cables. Once you are connected, you
can do anything, just like the wired network. This USB client adapter operates seamlessly in
2.4GHz frequency spectrum supporting the 802.11b, 802.11g wireless standards. It's the best
way to add wireless capability to your existing wired network or simply surf the web.
For advanced configuration, refer to the User's Manual in the CD-ROM provided.

USB Adapter Description

The USB adapter is a standard USB adapter that
fits into any USB interface. The USB adapter has
two LED indicators and a built-in antenna.
USB Adapter for Windows Vista & XP– Installation
During the installation, Vista may need to copy systems files from its installation CD. Therefore,
you may need a copy of the Windows installation CD at hand before installing the drivers.
Follow the steps below in order to install the USB adapter drivers:
1. Insert the CD-ROM that was provided to you in this package. The setup should run
automatically. If the setup does not run automatically, then you must manually select the
setup.exe file from the CD-ROM drive.
2. Once the setup begins you will see the InstallShield Wizard. Select EnGenius
Configuration Tool and then click on the Next> button.
3. Click on the Install button to begin the installation.
4. The installation is complete. Click on the Finish button.
5. Carefully insert the USB adapter into the USB port. Windows will then detect and install the
new hardware.
6. An EG icon will then appear in the system tray. Right click on the EG icon and then click on
Launch Config Utilities.
Note: Click on Use Zero Configuration as Configuration Utility if you would like to use
Windows Zero Config.
USB Adapter Adding a Profile – Windows Vista & XP
The Profile tab is used to store the settings of multiple Access Points such as home,
office, café, etc. When adding a profile you are required to enter a profile name and SSID
as well as configure the power-saving mode, network type, RTS/fragmentation threshold
and encryption/authentication settings.
1. Profile: Enter a name for the profile; this does not need to be the same as the SSID.
2. SSID: Enter the SSID of the network or select one from the drop-down list.
3. Network Type: Select Infrastructure from the drop-down list.
4. TX Power: Select a transmit power from the drop-down list..
5. Click on the Apply button to save the changes.
