- Page 1 PROFESSIONAL REMOTE ALARM SYSTEM INSTALLATION & USERS MANUAL This unit is designed for professional installation only and must be installed by an Encore authorized dealer. Please register this product at www.encoreautomotivesystems.com.
- Page 2 Wiring 4 PIN WIRE HARNESS: White wire: POSITIVE PARKING LIGHT RELAY OUTPUT Connect the WHITE wire to the parking light wire coming from the headlight switch. Do not connect the WHITE wire to the dashboard lighting dimmer switch. (Damage to the dimmer will result). The limitation of the WHITE wire is 10 AMP max. Do not exceed this limit or damage to the alarm and parking relay will result.
- Page 3 8 Pin Connector Orange wire – (-) 200mA Grounded Output When Armed – This wire will become grounded when the alarm is armed. The current capacity of this wire is 200mA. This output can control starter disable preventing any unauthorized starting. GREEN wire Orange wire White wire...
- Page 4 Green wire – Negative Door Switch Sensing Input This wire is the ground trigger input wire for negative door pin switch. This wire is connection for "grounding" type factory door pins locate the "common wire" that connects the door pin switches. Make the connection of the GREEN Wire here. The door trigger wires are vital for the operation of the optional anti-carjacking mode.
- Page 5 Button Function: Transmitter Button System Function Remark Lock doors / ARM Button 1 Arm and Delete Button 1 Keep Pressing shock Sensor until the horn chirps a second time Car Locator Press While the Button System is Armed. Unlock Doors / Also Stop Panic and Button 2 DISARM...
- Page 6 Pressing the buttons together will silently arm and disarm the system. Adding or replacing Transmitters. To replace lost or stolen transmitters or to add additional transmitters into the system. Please have all desired transmitters ready and follow the steps below. Note: Up to 4 transmitters can be programmed to operate the system.
- Page 7 The doors will lock. The parking lights will flash once. The LED will turn On, to indicate the starter defeat is activated. 3. 5 seconds after Arming, the LED will start blinking to indicate that the doors and hood/trunk inputs are being monitored. * During Arming, if the system detects a bad sensor or an open zone, the system will chirp 4 additional times and ignore that input, but keep all other areas protected.
- Page 8 Passive Arming When programmed for the optional Passive Arming feature, the system arms itself automatically, each time the ignition is turned off and all of the doors, hood, and trunk are closed. TO start the Passive Arming Process: 1. Turn off the ignition. 2.
- Page 9 2. Enter the vehicle. , The system will trigger and the siren will sound. 3. Turn the ignition key to the ON position. 4. Press and hold the override switch until the alarm shuts off. The system will disarm. 5. The vehicle will now be able to start. Optional Coded Emergency Override As an extra measure of security, the system is equipped with an optional Coded Emergency Override feature.
- Page 10 Valet Mode The Valet Mode temporarily disables the security system so the vehicle may be operated by a mechanic or parking attendant. To activate or deactivate the Valet Mode: 1. Turn on the ignition. 2. press and hold the override switch for 5 seconds. The siren will chirp once and the LED light will stay ON to conform the Valet Mode is on.
- Page 11 To disable the Shock Sensor: 1. Arm the system normally and continue holding the lock button until a second chirp is heard. The siren will chirp a second time and the parking lights will flash 1 extra time to indicate the sensor is disabled. The sensor will remain disabled until the next arming cycle.
-
Page 12: System Programming
Shock Sensor: Adjustment The two stage shock sensor is to be installed under the driver’s side dash as close to the middle of the vehicle as possible. It has two adjustments. One for the first stage known as warn away. This will trigger a few horn and siren chirps if the vehicle has sensed a small impact. -
Page 13: Programmable Options
Default Reset Following this procedure will set all System Programming Parameters to factory default settings. 1. Enter System Programming. 2. Press Transmitter Button 3. The siren will chirp 4 times indicating that the reset signal was received. All System Programming parameters are now set to factory default settings. 3.Turn off ignition Programmable options: Button... - Page 14 2. Arm Mode. Selects one of three modes: Manual Arming or Passive Arming, and Passive Arming w/Countdown. With the Passive Arming w/Countdown mode selected, the siren will chirp every 2 seconds while counting down until the system passively arms. Note: If Auto Rearming is selected, the siren will also chirp during Auto Rearm countdown.
- Page 15 Passive: When selected, the Anti-Carjacking feature will activate whenever a door is opened while the Ignition is ON. Full-time: When selected, the Anti-Carjacking feature will automatically activate each time the Ignition is turned on and must be disabled each time to drive the vehicle. This is not recommended for normal use.
