3 How to Operate DELTA OP
'(/7$ 23 incorporates the facility of displaying a pre-programmed customer
specified text of maximum 40 characters for each addressable detector and
conventional loop.
Usually, this text information indicates which area of the building a
conventional detector loop protects or where an addressable monitor is
installed.
Detector texts will be automatically displayed when the monitor reports a fault,
pre-alarm or fire alarm. For control purposes, you may manually display the
programmed display text of any detector and conventional loop in the system.
For quick access to a detector's text, press following keys at the keypad:
2WKHU )XQFWLRQV
The advanced technology in '(/7$ 23 incorporates many other facilities
particularly useful to you.
Some of the facilities that make '(/7$ 23 a user-friendly system are
described below.
Most of the '(/7$ 23 functions are accessed via menu options by pressing a
specific sequence of keys on the keypad.
To facilitate activating frequently used functions, (i.e. daily isolation of a
specific zone), the system incorporates an automatic way of entering the
specific sequence of keys — a macro.
A macro is a sequence of key-entries saved by the system for later use.
A macro is programmed by first giving it a name (which you do by choosing a
QXPEHU on the keypad, for example number 8) and then pressing the VSHFLILF
VHTXHQFH RI NH\V necessary for activation of the function you want to automate
(for example to isolate a zone). The system will then save the sequence of key-
entries for later use.
When the function — isolation of the zone — is required, instead of pressing
through the sequence of keys to isolate the zone manually, just enter the PDFUR
QXPEHU from the main menu. The system will then automatically isolate the
zone for you.
Each '(/7$ 23 panel incorporates the possibility of programming 7 different
macros, with storage capacity for up to 100 key-entries for each macro.
Macro numbers 7, 8 and 9 are activated via the panel's numeric keypad. Macro
numbers 1, 2, 3 and 4 are activated via the '(/7$ 23 panel's G\QDPLF µVRIW¶
keys under the graphic display.
30
'LVSOD\LQJ 'HWHFWRU 7H[WV
F
M
(PDLQ PHQX)
F
ö
SYSTEM INFO
(
F
ó
DETECTOR DATA
(
F
ö
SHOW ALARM-TEXT/ZONE INFO
(
$XWRPDWLF .H\(QWULHV 0DFURV
:KDW LV D PDFUR"
User's Guide '(/7$ 23
)
)
)
