Storm AXS Strike Master Manual

t o r m
Read this manual carefully before attempting to install, program or operate the
STORM AXS Strike Master Keypad. After installation the Command Summary Chart at the
back of this manual can be used as a quick reference to programming and operating
command sequences.
Page
1
2
3
4
5
6
7
8
i) INTRODUCTION AND FACTORY DEFAULTS
Storm AXS Strike Master Keypads provide comprehensive access control for all outdoor and
indoor locations. Door / system status is indicated by a high intensity LED light source and an
audible sounder. Storm AXS Strike Master Keypads are specified to survive in different service
environments, ranging from exposed unsupervised public locations to general service indoor
applications. Keypads in the Storm AXS Strike Master range are dimensionally and electrically
interchangeable. This allows users, entering codes at both outdoor or indoor access points, to
establish and maintain familiarity with the keypad features.
• Up to 50 user programmable entry codes
• Entry Code indexing system provides a
directory of authorised code holders and
permits secure allocation and re-allocation
of entry codes
• 4, 5, or 6 digit entry codes
• One or two door control
• Anti-tamper alarm
• Entry code entered under duress alarm
• Hidden entry code feature
• Forced door alarm
The STORM AXS Strike Master Keypad is supplied with the following factory configured defaults.
Default settings
FEATURE
'Engineer's' code
Door 1 'Strike Time'
Door 2 'Strike Time'
Invalid code Penalty time
Relay 2 output
Relay 2 Configuration
Door Sensor
®
Secure Keypads
for access control
Section Contents
i) Introduction and Factory Defaults
ii) Installation Instructions
iii) Electrical and Data Connections; Circuit Schematic
iv) Code Entry Mode
v) Programming Mode
vi) Adding and Removing Codes
vii) Changing Door Strike Times
viii) Setting the Invalid Code Penalty Time
ix) Other Features. Remote Exit, Alarms, Relay 2,
Door Monitoring, Entry Under Duress, Alarm Signals
x) Code Index Directory
xi) Command Summary Chart
• Timed strike or latching door operation
• Timed lock out for repeated invalid code
• Remote switch exit facility
• Fail (open) Fail (closed) option
• All weather resistant
• Two protection levels
FACTORY SET DEFAULT
111111
(For security, change default engineer's code on installation)
5 seconds
5 seconds
15 seconds
Set in 'Alarms Mode'
Relay Output set 'normally open'
Bridged. Remove wire bridge to enable this feature
Strike Master
input
– anti vandal keypad for unsupervised
public, outdoor locations
– robust keypad for
regular outdoor / indoor locations
DES-MAN ISS.3
