2800/2820/2850
Notebook Computer

Service Manual

1
2
3
4
5
6
7
8
i

Advertisement

Table of Contents
loading

Related Manuals for Clevo 2800

Summary of Contents for Clevo 2800

  • Page 1: Service Manual

    2800/2820/2850 Notebook Computer Service Manual...

  • Page 2: Preface

    P r e f a c e OTICE The company reserves the right to revise this publication or to change its contents without notice. Information con- tained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor.

  • Page 3: About This Manual

    Chapter 3, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to up- grade elements of the system. Chapter 4, Troubleshooting, provides recommendations on how to solve possible system problems. Appendix A, Part Lists Appendix B, 2800 Circuit Diagrams Appendix C, 2820/2850 Circuit Diagrams the manual...

  • Page 4: Related Documents

    The ‘expanded’ manual also describes the installation & opera- tion of the utility programs and how to upgrade the system’s RAM and HDD. Last Resort: The Manufacturer If you can’t find the information you need in these documents or your up-line source, contact the manufacturer at: www.clevo.com.tw related...

  • Page 5: Table Of Contents

    ABLE OF ONTENTS Preface Cover ........................................i Notice ........................................ii About This Manual .................................... iii Related Documents ................................... iv Table of Contents ....................................v Chapter 1: Introduction System Specifications ..................................1-2 CPU ......................................1-2 Memory ...................................... 1-2 Core Logic ....................................1-2 BIOS ......................................1-3 Video ......................................
  • Page 6 P r e f a c e South Bridge, PCI ISA IDE Xcelerator, 82371EB/MB (PIIX4E/M) ....................2-6 Supporting Chips .................................... 2-8 Ricoh 5C475 PCI-CardBus Bridge ............................2-8 SMSC FDC37N869 PC 99 ............................... 2-10 Compliant 5V and 3.3V Super I/O Controller with Infrared Support .................. 2-10 ATI RAGE LT Pro Graphics Controller ............................
  • Page 7 Checking the Software Configuration ..........................4-25 Checking the Volume ................................ 4-25 Checking the Speaker Cable ............................4-26 Suspend Function Failure ............................... 4-27 Charge LED Failure .................................. 4-27 Appendix A: Part Lists Appendix B: 2800 Circuit Diagrams Appendix C: 2820/2850 Circuit Diagrams table of contents...

  • Page 8: Chapter 1: Introduction

    The notebook is designed to be upgradable. The 2800 supports Intel Pentium II & Celeron CPUs of different speeds and 12.1” & 14.1” TFT color LCD screens. The 2820 supports Intel Pentium III & Celeron CPUs of different speeds and 12.1”...

  • Page 9: System Specifications

    Introduction YSTEM PECIFICATIONS (2800) (2820 & 2850) Package MicroPGA1 MicroPGA2 Type Pentium II, 300MHz~400MHz Pentium III, 450MHz or faster Celeron, 300MHz~400MHz Celeron, 450MHz or faster EMORY L1 cache (in CPU) 16KB code + 16KB data 16KB code + 16KB data...

  • Page 10: Bios

    BIOS 512KB Flash ROM, Plug ‘n Play 1.0a, LBA, APM 1.2, ACPI IDEO memory 4MB/8MB SGRAM chipset ATI 3D Rage LT Pro AGP (with 3D, AGP & ZV support/proprietary driver) architecture 64-bit 2x AGP bus with Windows Acceleration display TFT (active matrix) 12.1”...

  • Page 11: I/O

    Introduction 2 ports, compliant with UHCI 1.1, USB 1.0 & PCI 2.1 Serial 1 9-pin, 16C550 compatible Serial 2 infrared, IrDA v 1.1, FIR, SIR compatible Parallel 25-pin, ECP, output-only, bi-directional 15-pin VGA PS/2 6-pin, mini-din, mouse or keyboard PC Card one Type I or Type II socket, PC Card 3.0, ZV port &...

  • Page 12: Other Features (Optional)

    10% to 90%, non-condensing altitude 8000 feet shock (unpacked) 5G (11 + 1 microsecond pulse) HYSICAL 2800 (12.1”/14.1” LCD capable): dimensions 312mm(w) x 262mm(d) x 34.5mm(h) weight 2.95Kg (with Li-Ion battery, FDD, HDD, CD-ROM & 14.1” LCD) 2820 (12.1”/14.1”...
  • Page 13 Introduction XTERNAL OCATOR The following figures show the external locations of the computer’s main subsystems. RONT . 1 – 1 2. Cover latch 3. Speakers 4. On/Off switch 5. LED system status indicators 6. Keyboard 7. TouchPad & buttons 8. LED power status indicators 9.

  • Page 14: External Locator

    . 1 – 3 Kensington lock port 2. PC Card slot 3. IrDA (serial 2) port 4. USB ports 5. FDD IGHT . 1 – 4 6. CD-ROM module (option) or DVD ROM module (option) 7. Adapter port . 1 – 5 8.
  • Page 15 Introduction OTES 1 – 8 notes...

  • Page 16: Chapter 2: Chipset

    Chipset The computer is completely AT-compatible. Its chipset supports a high-performance PCI bus video interface and state-of-the-art power management features. This chapter mainly describes the following major system components: • CPU • Core logic chipset • Supporting chips The following figures are the system block diagram and the chipset site diagram. These provide an overview of the computer’s layout and a practical locator for chipset components.
  • Page 17 6. Keyboard Controller Hitachi HB/3434 7. SW1 & SW2 8. CN28 DIMM socket “0” 9. CN29 DIMM socket “1” 10. Core Logic chip 82371EB (2800) 82371MB (2820 & 2850) 11. Audio controller YAMAHA YMF744B 12. Super I/O controller SMSC FDC37N869 13.
  • Page 18 CONT HIPSET IAGRAM . 2 – 2 15. LAN Transformer LF-H71P 16. Video SGRAM 17. CPU component sites 2 – 3...

  • Page 19: Cpu - Intel Mobile Pentium Iii/Pentium Ii/Celeron

    ENTIUM ELERON The 2800 uses the Intel Mobile Pentium II/Celeron processor in a microPGA1 package. The Intel Mobile Pentium II/Celeron processor features an integrated L2 cache (256KB for Pentium II and 128KB for Celeron) and a 64-bit high performance system bus.

  • Page 20: Core Logic Chipset - Intel 440Bx Agpset

    440BX AGP OGIC HIPSET NTEL The Intel 440BX AGPset consists of the BX System Controller (443BX) and the PCI ISA IDE Xcelerator (PIIX4E/ PIIX4M). The AGPset forms a Host-to-PCI bridge and provides the second level cache control and a full function 64-bit data path to main memory.
  • Page 21 RIDGE CELERATOR The 2800 uses the 82371EB (PIIX4E) while the 2820 & 2850 use 82371MB (PIIX4M). The PCI ISA IDE Xcelerator (PIIX4E/PIIX4M) is a multi-function PCI device implementing a PCI-to-ISA bridge function, a PCI IDE function, a Universal Serial Bus host/hub function, and an Enhanced Power Management function. As a PCI-to-ISA bridge, the PIIX4E/PIIX4M integrates many common I/O functions found in ISA-based PC systems - a seven channel DMA Controller, two 82C59 Interrupt Controllers, an 8254 Timer/Counter, and a Real Time Clock.
  • Page 22 - Supports full positive decode or subtractive decode of PCI • Interrupt Controller based on two 82C59 - Supports ISA/EIO at 1/4 of PCI frequency - 15 interrupt support • Supports both mobile and desktop deep green environments - Independently programmable for Edge/Level sensitivity - Supports optional external I/O APIC - 3.3 V operation with 5 V tolerant buffers - Serial interrupt input...

  • Page 23: Supporting Chips

    C h i p s e t UPPORTING HIPS The following subsections describe major supporting chips: • Ricoh 5C475II PCI-CardBus Bridge • SMSC FDC37N869 PC 99 Compliant 5V and 3.3V Super I/O Controller with Infrared Support • ATI RAGE LT Pro Graphics Controller •...
  • Page 24 • CardBus PC card Bridge – PC Card Standard 95/97 compliant – Compliant with Yenta register set Rev2.2 – The maximum frequency 33MHz – CardBus Master/Target protocol support – Transfer transactions - All memory read/write transaction(bi-direction) - I/O read/write transaction(bi-direction) - Configuration read/write transaction(PCI ®...

  • Page 25: Smsc Fdc37N869 Pc 99

    C h i p s e t SMSC FDC37N869 PC 99 C 3.3V S I/O C OMPLIANT UPER ONTROLLER WITH NFRARED UPPORT The FDC37N869 features: • Serial ports • 5 volt and 3.3 volt operation - Two high speed NS16C550 compatible UARTs with send/ •...

  • Page 26: Ati Rage Lt Pro Graphics Controller

    ATI RAGE LT P RAPHICS ONTROLLER The RAGE LT Pro is a highly integrated graphics accelerator with superior support for 3D and motion video — ideal for notebooks and LCD desktops. It incorporates comprehensive support for Intel’s Accelerated Graphics Port (AGP), including 1X or 2X mode with sidebands.

  • Page 27: Yamaha Ymf744B Ds-Xg

    C h i p s e t YAMAHA YMF744B DS-XG The YMF744B (DS-1S) is a high performance audio controller for the PCI Bus. DS-1S consists of two separated functional blocks. One is the PCI audio block and the other is the Legacy Audio block. PCI Audio block allows Software Driver to handle maximum of 73 concurrent audio streams with the Bus Master DMA engine.
  • Page 28 We suggest you completely review any procedure before you take the computer apart. The computer comes in two (2) models: 2800 and 2820/2850 and several “variations”: The 280 is based on the Pentium II CPU. Different versions may have cosmetic and minor structural variations of the top and bottom covers (mostly concerning LCD panel sizes).

  • Page 29: Connections

    Disassembly The disassembly procedures appear in the following order: • Keyboard – CPU upgrade/replacement • LCD Module – LCD assembly, inverter • Top Cover – TouchPad assembly • Bottom Cover – HDD, FDD, mainboard, and DC/DC board • Connector Locator All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too).

  • Page 30: Maintenance Precautions

    AINTENANCE RECAUTIONS The following precautions are a reminder. To avoid personal injury or damage to the notebook while performing a removal and/or replacement job, take the following precautions: Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components could be damaged.

  • Page 31: Cleaning

    Disassembly LEANING Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. AINTENANCE OOLS The following tools are recommended when working on the notebook: M3 Phillips-head screwdriver M2.5 Phillips-head screwdriver (magnetized)* M2 Phillips-head screwdriver...

  • Page 32: General Disassembly: Under The Keyboard

    ENERAL ISASSEMBLY NDER THE EYBOARD & H EMOVING THE EYBOARD LATE Make sure the com- puter is turned off. " " " " " " " " " " " " " " " Remove the rubber caps and screws on the status panel.

  • Page 33: Changing The Cpu

    CPU, be sure to note the position of the CPU’s “Pin 1”. Make sure any replacement CPU is also properly locked into position. CPU settings for the Intel Pentium II -based 2800 are controlled from SW1 which is accessible from the RAM bay on the notebook’s bottom.
  • Page 34 f f o f f o f f o f f o f f o f f o f f o 3 - 1 ABLE f f o f f o f f o f f o f f o CPU S WITCH ETTINGS FOR...

  • Page 35: General Disassembly: Removing & Replacing The Lcd Module

    Remove the two (2) rear screws (J ~ K), set them aside. f f o Note: On models 2800 & 2820 these are the upper rear screws. f f o f f o f f o...
  • Page 36 LCD M EMOVING THE ODULE . 3 – 4 ! ! ! ! ! This procedure involves: screws connectors: 3 – 9 LCD module...

  • Page 37: Replacing The Lcd

    Disassembly EPLACING THE The LCD module has two elements, the LCD itself, and its inverter card. First separate the LCD module from the main body of the computer as described on pages 3-4 and 3-5. If you are upgrading to a different LCD, this entire assembly, except for the side frame and hinge elements and possibly the inverter card, will be replaced.
  • Page 38 LCD & F EPARATING THE RAME . 3 – 5 ! ! ! ! ! This procedure involves: 15.1” screws connectors: 3 – 11 LCD module...

  • Page 39: General Disassembly: Top Cover Assembly

    For models 2800 & 2820, remove 13 screws (C~O). Remove the 2 screws on the rear panel (the lower outer corner screws 2800 & 2820 versions only). Return the notebook to its upright position and disconnect the TouchPad to mainboard connector at CN18 (P).
  • Page 40 ISASSEMBLY OTTOM CREWS . 3 – 6 ! ! ! ! ! This procedure involves: screws 11 (2850) 13 (2800 & 2820) OVER ISASSEMBLY CREWS . 3 – 7 ! ! ! ! ! This procedure involves: connector(s) top cover & TouchPad...

  • Page 41: General Disassembly: Top Cover Components

    Disassembly ENERAL ISASSEMBLY OVER OMPONENTS The 2 TouchPad daughterboards in this assembly are unlikely to require any service. OUCH The TouchPad module is in 2 parts: the TouchPad itself and the “mouse” buttons. To take them out of the top cover assembly, first separate the top cover assembly as described on pages 3-12 and 3-13. Remove the 8 screws anchoring the TouchPad assembly (A~H) Lift the TouchPad assembly away from the top cover.
  • Page 42 OVER SSEMBLY . 3 – 8 A - H ! ! ! ! ! The TouchPad module has: screws connectors 1 top cover assembly 3 – 15...

  • Page 43: General Disassembly: Bottom Cover Assembly

    Disassembly ENERAL ISASSEMBLY OTTOM OVER SSEMBLY The Bottom cover assembly includes the mainboard, HDD module, FDD module, power board, PCMCIA socket, and optional fax/modem module (not shown). HDD M ODULE The HDD module (A) is held in place with two screws. Remove the HDD module anchor screws (B &...
  • Page 44 " " " " " " " " " " ' ' ' ' ' OTTOM OVER SSEMBLY . 3 – 9 ! ! ! ! ! Separating the mainboard from the bottom cover in- cludes: screws connectors 2 3 – 17 bottom cover...
  • Page 45 Disassembly HDD M ODULE SSEMBLY When you’re ready to install a new hard disk, AKING IT PART After you’ve removed the HDD module, 1. Remove the four (4) bracket screws (A~D), and set them aside. 2. Remove screws E &F and carefully pull off the HDD adapter board (G). 3.
  • Page 46 ETTING FOR THE IRST Before you can use a new HDD for the first time, you have to do two things: • tell the computer about the HDD (refer to the User’s Manual Chapter 3: Firmware). • prepare the HDD to accept data (refer to your operating system manual). Use the following directions to prepare the new HDD for use.

  • Page 47: Switches & Connectors

    Disassembly & C WITCHES ONNECTORS These figures show the locations of the principal switches and connectors. & C WITCHES ONNECTORS . 3 – 11 AINBOARD Mainboard (top view) CN1 LAN port 2. CN2 Fax/Modem port 3. CN3 VGA port 4. CN5 to Fax/Modem card 5.
  • Page 48 TATUS ANEL OTTOM & C WITCHES ONNECTORS . 3 – 12 DC/DC Board 27. CN4 to #6 (Mainboard) 28. Parallel port 29. Serial 1 (COM1) port 30. PS/2 port TATUS OARD 31. DC-in 19V 32. SW1 system power switch Status Panel AINBOARD BOTTOM 33.
  • Page 49 Disassembly OTES 3 – 22 notes...

  • Page 50: Chapter 4: Troubleshooting

    Troubleshooting If you are having trouble diagnosing and solving problems, this chapter has several tools which should help: • Troubleshooting chart – a system flow chart indicating the location of possible system abnormalities. • Pre-POST assistant – a rundown of possible problems before the POST and solutions. •...

  • Page 51: Before You Begin

    Troubleshooting EFORE EGIN Before you start a troubleshooting job, be sure that: • All peripheral devices are disconnected from the notebook. (They should be tested separately.) • You have reviewed the safety precautions in the beginning of Chapter 3: Disassembly. OOLS In addition to the tools listed in Chapter 3, troubleshooting jobs may call for some additional devices: •...

  • Page 52: System Troubleshooting Chart

    YSTEM ROUBLESHOOTING HART Use the following troubleshooting flow chart to locate the problem areas systematically. ROUBLESHOOTING LOWCHART . 4 – 1 4 – 3 flow-chart...

  • Page 53: Pre-Post Assistant

    Troubleshooting -POST A SSISTANT This section describes possible problems before the Power-On-Self-Test (POST) and ways to solve them. Possible Problems Possible Causes AC power LED fails The AC/DC adapter has malfunctioned. 1. The DC/DC board has failed. 2. The battery pack has malfunctioned or its AC power &...

  • Page 54: Ac Power Led Fails

    AC P LED F OWER AILS Under normal conditions, plugging in the AC/DC adapter makes the AC Power LED light up. If it fails to light up, it is possible that the AC/DC adapter is malfunctioning. If you think this is the case, try the following: •...

  • Page 55: Ac Power & Charge Leds Fail

    Troubleshooting AC P & C OWER HARGE There may be other problems responsible for a system status LED’s failure to appear: • The DC/DC board failed. • The battery pack malfunctioned or its connection with the mainboard is bad. • There is a short circuit in the mainboard. Try the following troubleshooting procedures.
  • Page 56 DC/DC Board (top) OWER OMPONENTS . 4 – 3 CN5 DC/DC board to M/B 3. CN1 for DC IN Jack 3. F2 Fuse for AC-IN DC/DC Board (bottom) Mainboard (top) DC/DC board 4 – 7...
  • Page 57 Troubleshooting CN5 DC/DC Board to M/B (on the DC/DC Board) Signal Signal CN1 DC IN JACK Signal LPSTROBE# LPD0 LPACK# LPD1 +20V LPBUSY LPD2 LPPE LPD3 LPSLCT LPD4 LPAFD# LPD5 LPERROR# LPD6 LPINIT# LPD7 LPSLCTIN# SUSB# V_CORE DCD1# DSR1# DTR1# RXD1 RTS1# CTS1#...

  • Page 58: Checking The Battery Pack And Its Cabling

    HECKING THE ATTERY ACK AND ABLING A malfunctioning battery pack or a bad connection between the battery pack and the power board may be the cause of the LEDs’ failure. HECKING THE ATTERY Whether the battery pack functions well or not can be checked by measuring the voltage across battery contacts BAT and GND.

  • Page 59: Checking The Cabling

    Troubleshooting HECKING THE ABLING If the battery pack is functioning properly, check if the measured voltage across pins 1 to 5 of connector CN20 on the mainboard (Fig. 4-3) is the same as the voltage measured for the battery pack. If the measured voltages are not the same, check if the fuse on the power board has been damaged.

  • Page 60: Lcd Screen Failure To Display

    LCD S CREEN AILURE TO ISPLAY The LCD screen’s inability to display may be due to any of the following problems: • There is bad connection between the LCD screen and the mainboard • The inverter board has malfunctioned • The LCD screen has malfunctioned HECKING THE AINBOARD ONNECTION...

  • Page 61: Checking The Inverter Board

    Troubleshooting HECKING THE NVERTER OARD Table 4-3 suggests areas where problems may occur and provides corresponding corrective actions. The component sites of the inverter board are shown in Figure 4-6. Warning Inverter boards have high- voltage areas. To prevent electrical shock, do not Area to Check Action touch the board when the...

  • Page 62: Checking The Lcd Screen

    LCD S HECKING THE CREEN If you found no problems with the inverter board and its connection to the mainboard and the LCD lamp, and the LCD still doesn’t work, it is possible that the LCD screen itself may have malfunctioned. Replace the LCD screen to see if the problem can be solved.

  • Page 63: No Errors Found During The Post

    Troubleshooting POST — T ESTING THE YSTEM Each time the system is powered on, it automatically performs a Power-On-Self-Test (POST). The POST tests major system hardware and checks the system configuration. Error beeps and messages If the system can’t pass the POST, an error beep or message may be issued or displayed. This will indicate the problem with the system.
  • Page 64 POST E & S RROR EEPS CREEN ESSAGES Errors, fatal or non-fatal, can occur during the POST. All fatal errors and some non-fatal errors are communicated through a series of audible beeps. Table 4-4 below lists the error beep messages. Fatal errors do not allow the system to continue the boot process.
  • Page 65 Troubleshooting Meassage Description & Suggested Solution nnnn Cache SRAM Passed description: nnnn is the amount of system cache in kilobytes successfully Where tested. description: Drive A: or B: is present but fails the BIOS POST diskette tests. Diskette drive A error or Diskette drive B error solution: Check to see that the drive is defined with the proper diskette type in Setup and that the diskette drive is attached correctly.
  • Page 66 Meassage Description & Suggested Solution description: The keyboard is not working. Keyboard Error solution: Reboot the computer. If the problem persists, replace the computer. Keyboard Error nn description: The BIOS discovered a stuck key and displays the scan code nn for the stuck key.
  • Page 67 Troubleshooting Meassage Description & Suggested Solution Real time clock error description: The on-board clock fails the BIOS test. solution: May require board repair. Shadow RAM failed at offset: nnnn description: The shadow RAM failed at the offset nnnn of the 64K block at which the error was detected.
  • Page 68 Error Code Definition Error Code Definition Verify real mode Test DRAM refresh code 3-1-1 Test 8247 keyboardcontroller Get CPU type (beep code 3-1-3) Initialize system hardware Set ES segment gegister to 4GB Initialize chipset registers with initial POST values Autosize DRAM Set in POST flag Clear 512K base DRAM Initialize CPU registers...
  • Page 69 Troubleshooting Error Code Definition Error Code Definition Load alternate registers with CMOS values Test extended memory Set initial CPU speed Test extended memory address lines Jump to UserPatch1 Initialize interrupt vectors initialize BIOS interrupts Configure advanced cache registers Check ROM copyright notice Enable external and CPU caches (beep code 2-1-2-3) Display external cache size...
  • Page 70 Error Code Definition Error Code Definition Initialize extended BIOS data area POST done - prepare to boot operating system Initialize floppy controller One beep initialize hard disk controller Initialize local-bus hard disk controller Display MultiBoot™ menu Jump to user patch2 Check password (optional) Build MPTABLE for multi-processor boards Clear global descriptor table...
  • Page 71 Troubleshooting The table below is for the boot block in the Flash ROM. Error Code Definition Initialize the chipset Initizlize refresh counter Check for Forced Flash Check HW status of ROM BIOS ROM is OK Do a complete RAM test 4 –...

  • Page 72: Post-Post Problems

    -POST P ROBLEMS This section describes possible problems the user might encounter after the POST and suggests problem-solving methods. Possible problems and possible causes leading to them are outlined below. Problems Possible Causes 1. Something wrong with the socket. PCMCIA socket fails to work 2.

  • Page 73: Pc Card Socket Malfunction

    Troubleshooting PC C OCKET ALFUNCTION The faulty conditions the user might encounter when using the PC Card socket are listed below along with corre- sponding solutions. Possible faulty condition Solution Failure to insert the card into the socket If the card cannot be inserted into the socket, check for obstructions.

  • Page 74: Sound Output Failure

    OUND UTPUT AILURE The notebook’s internal audio unit consists of the audio circuitry, built-in speakers, and built-in microphone. If the user cannot receive sound from the notebook’s internal speakers, it may be due to any of the following problems: • The audio chip is not configured with the supplied audio driver. •...

  • Page 75: Checking The Speaker Cable

    LED board (on the status panel) at connector CN1 and then to the mainboard at connector CN8 on its upper middle area while the left speaker connects to the mainboard at connector CN12 on its upper left area. 2800 Status Panel status LED board PEAKERS .

  • Page 76: Suspend Function Failure

    USPEND UNCTION AILURE Pressing the suspend key combination will enable the system to enter Suspend mode after few seconds. The power status LED will not light if the system is in Save to Disk mode. If the system can’t enter Suspend mode it may be because the Power Savings in your BIOS setup are not set properly.
  • Page 77 Troubleshooting OTES 4 – 28 suspend & battery status...
  • Page 78 Appendix A 2800/2820 Part Lists This appendix breaks down the notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.
  • Page 79 P a r t s 2800 F RONT . A – 1 A – 2 front assembly...
  • Page 80 2820 F RONT . A – 2 A – 3 front assembly...
  • Page 81 P a r t s 2800 LCD A SSEMBLY . A – 3 A – 4 lcd assembly...
  • Page 82 2820 LCD A SSEMBLY . A – 4 A – 5 lcd assembly...
  • Page 83 P a r t s 2800 W SSEMBLY . A – 5 A – 6 work assembly...
  • Page 84 2820 W SSEMBLY . A – 6 A – 7 work assembly...
  • Page 85 P a r t s 2800 T OVER SSEMBLY . A – 7 A – 8 top cover assembly...
  • Page 86 2820 T OVER SSEMBLY . A – 8 A – 9 top cover assembly...
  • Page 87 P a r t s 2800 B OTTOM OVER SSEMBLY . A – 9 A – 10 bottom cover assembly...
  • Page 88 2820 B OTTOM OVER SSEMBLY . A – 10 A – 11 bottom cover assembly...
  • Page 89 P a r t s 2800 S TATUS ANEL SSEMBLY . A – 11 2820 S TATUS ANEL SSEMBLY . A – 12 A – 12 status panel...
  • Page 90 2800 M AINBOARD SSEMBLY . A – 13 2820 M AINBOARD SSEMBLY . A – 14 A – 13 mainboard...
  • Page 91 P a r t s 2800 B RACKET SSEMBLY . A – 15 2820 B RACKET SSEMBLY . A – 16 A – 14 bracket...
  • Page 92 2800/2820 R SSEMBLY . A – 17 rear assembly A – 15...
  • Page 93 P a r t s 2800/2820 B OTTOM SSEMBLY . A – 18 A – 16 bottom...
  • Page 94 2820 HDD A SSEMBLY . A – 19 2800 HDD A SSEMBLY . A –20 HDD assembly A – 17...
  • Page 95 P a r t s 2820/2800 FDD A SSEMBLY . A – 21 A – 18 FDD assembly...
  • Page 96 2820/2800 CD-ROM A SSEMBLY . A – 22 CD-ROM assembly A – 19...
  • Page 97 P a r t s OTES A – 20 notes...

  • Page 98: Appendix A: Part Lists

    Appendix B 2850 Part Lists This appendix breaks down the notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.
  • Page 99 P a r t s PARTS Q'TY NAME PARTS NUMBER DESCRIPTION A.35-B9125-4R0 SCREW M2.5*4.0L K1 BNI B.35-B1125-22A SCREW M2.5*22L KI NI NY CENTER COVER ASS'Y E.35-49120-100 SCREW M2*10L B BN NY F.35-41125-3R0 M2.5*3L*0.45P BIND HEAD HDD MODULE 2850 K EYBOARD .
  • Page 100 PARTS Q'TY NAME PARTS NUMBER DESCRIPTION A.35-41120-130 SCREW M2*13L B NI NY B.33-28201-002 TOP HEAT PLATE C.79-282HE-0A2 TOP HEAT SINK & FAN CABLE COVER ASS'Y \M+2A544\M+2C5E9\M+2A562\M+2A6A8\M+2AB7E F.35-B9125-17A SCREW M2.5*17L KI NY 2850 H . B – 2 B – 3 heat sink assembly...
  • Page 101 P a r t s PARTS Q'TY NAME PARTS NUMBER DESCRIPTION C.47-28H01-041 SPEAKER RUBER D.39-28505-000 LED COVER,PC+ABS 285 E.35-41120-3RA SCREW M2*3L B NI ICT NY 2850 S TATUS ANEL F.33-28206-000 COVER S/W BRACKET . B – 3 G.79-282HD-0B0 COVER SWITCH & CABLE LED BOARD V1.0 282H H.77-28205-001H I.43-2800D-001...
  • Page 102 PARTS Q'TY NAME PARTS NUMBER DESCRIPTION A.35-49125-8R0 SCREW M2.5*8L B BN NY LCD\M+2A562\M+2A6A8\M+2AB7E \M+2A544\M+2C5E9\M+2A562\M+2A6A8\M+2AB7E D.35-B9125-5R0 SCREW M2.5*5L K1 BNI NY SCREW M2.5*12L B BN NY E.35-49125-120 2850 LCD A SSEMBLY . B – 4 B – 5 lcd assembly...
  • Page 103 P a r t s PARTS NAME Q'TY PARTS NUMBER DESCRIPTION A.35-B1120-4RB SCREW M2*4L KI NI ICT B.39-28503-001 LCD F-CVR 15.1" X-TFT \M+2ABE1\M+2BB5C\M+2A94DLCD,\M+2C54B\M+2AC5B\M+2B5A5 2850 LCD F RAME D.35-B9125-5R0 SCREW M2.5*5L K1 BNI NY . B – 5 E.47-28502-010 CONDUCTIVE GASKET B –...
  • Page 104 PARTS NAME Q'TY PARTS NUMBER DESCRIPTION A.33-28505-000 LCD BRACKET (L) FOR LG B.50-L6707-63L LG 15" LCD C.35-B1120-4RB SCREW M2*4L KI NI ICT D.35-B1120-5R0 SCREW M2*5L K1 NI NY E.39-28504-001 \M+2ABE1\M+2BB5C F.43-28501-001 COAXIAL CABLE FOR LG G.33-28504-000 LCD BRACKET (R) FOR LG H.47-28501-040 BACK RUBBER L120*W20*H1 I.33-28H25-000...
  • Page 105 P a r t s PARTS Q'TY NAME PARTS NUMBER DESCRIPTION \M+2ABE1\M+2BB5C\M+2A94DLCD,\M+2C54B\M+2AC5B B.79-2850Y-020 HINGE (L) ASS'Y 285 C.35-B9125-5R0 SCREW M2.5*5L K1 BNI NY D.43-2800Q-001 WIRE CABLE FOR INVERTER INVERTER F.79-2850Y-010 HINGE (R) ASS'Y 285 G.35-B1120-4RB SCREW M2*4L KI NI ICT H.39-28511-001 LCD HOOK,POM 285 2850 LCD C...
  • Page 106 PARTS Q'TY NAME PARTS NUMBER DESCRIPTION A.35-B9125-5R0 SCREW M2.5*5L K1 BNI NY \M+2A455\M+2BB5C\M+2A94DM/B..\M+2A562\M+2A6A8\M+2AB7E \M+2A457\M+2BB5C\M+2A562\M+2A6A8\M+2AB7E D.35-41125-8R0 SCREW M2.5*8L B NI NY 2850 B OTTOM OVER SSEMBLY . B – 8 B – 9 bottom cover assembly...
  • Page 107 P a r t s PARTS Q'TY NAME PARTS Q'TY NAME PARTS NUMBER DESCRIPTION PARTS NUMBER DESCRIPTION \M+2A457\M+2BB5C\M+2A94D\M+2A8E4\M+2A5A6\M+2B2D5\M+2A5F3 \M+2A457\M+2BB5C\M+2A94D\M+2C54B\M+2A5F3 B.43-2800B-001 FPC CABLE FOR T/P T/P \M+2AA4F C.43-2800E-00 CABEL FOR CLICK BOARD C.35-21120-3RA SCREW M2.0*3L F NI NY T/P \M+2C54B\M+2A5F3 E.39-28507-001 TOUCH PAD BUTTON (R) F.39-28508-001 TOUCH PAD BUTTON (L)
  • Page 108 PARTS Q'TY NAME PARTS NUMBER DESCRIPTION A.79-2850C-0B0 T/P BRACKET ASS'Y 285 285 CLICK BOARD C.35-41120-3RA SCREW M2*3L B NI ICT NY 2850 T OUCH SSEMBLY . B – 10 PARTS NAME Q'TY PARTS NUMBER DESCRIPTION A.33-28503-000 TOUCH PAD BRACKET B.40-28501-000 TOUCH-PAD MYLAR 285 CLICK BOARD D.40-28502-000...
  • Page 109 P a r t s Q'TY PARTS NAME PARTS NUMBER DESCRIPTION A.79-2850C-0A0 TOP CASE ASS'Y 285 LCD\M+2A564\M+2B95F\M+2C54B\M+2AC5B C.39-28513-001 LCD HOOK KNOB D.38-28501-000 LCD HOOK SPRING \M+2A3723.4mm E.35-41120-3RA SCREW M2*3L B NI ICT NY 2850 L ATCH SSEMBLY . B – 11 PARTS Q'TY NAME...
  • Page 110 2820/2850 M AINBOARD SSEMBLY . B – 13 B – 13 mainboard...
  • Page 111 P a r t s 2820/2850 B RACKET SSEMBLY . B – 14 B – 14 bracket...
  • Page 112 PARTS NAME Q'TY PARTS NUMBER DESCRIPTION A.35-41125-5RA SCREW M2.5*5L B NI NY M/B ASS'Y C.34-28H04-000 HEX STUD,\M+2BBC9 NI-PL FDD MODULE E.33-28H20-000 K/B SUPPORT BRACKET \M+2A455\M+2BB5C G.79-280HF-00A MICRO PHONE & CABLE 2850 B OTTOM SSEMBLY . B – 15 bottom assembly B –...
  • Page 113 P a r t s PARTS Q'TY NAME PARTS NUMBER DESCRIPTION B.33-28205-002 HDD BRACKET,SUS C.35-B1130-4RB SCREW M3*4L KI NI ICT D.77-28203-003 HDD CONVERTER BOARD V3 E.35-B6120-2R0 SCREW M2*2L KI BZ NY F.40-28H13-001 HDD BRACKET MYLAR G.33-28H11-000 HDD HANDLE,SUS H.47-28201-010 HDD RUBBER,SILICONE 2820/2850 HDD A SSEMBLY .
  • Page 114 PARTS NAME Q'TY PARTS NUMBER DESCRIPTION A.35-06125-3R0 SCREW M2.5*3L P BZ NY B.33-28501-000 FDD BRACKET (L) D.39-26857-000 BUTTON OF FDD MODULE E.33-28502-000 FDD BRACKET (R) F.43-28008-003 FPC CABLE FOR FDD V3.0 2850 FDD A SSEMBLY . B – 17 FDD assembly B –...
  • Page 115 CD BRACKET,SPCC 280H D.35-21120-35B M2*3.5L F BNI ICT NY E.39-28H13-001 FPC CABLE (W/CU TAPE) F.85-605OX-T01 CD-ROM TOSHIBA XM-7002B CD-ROM BEZEL(TOS1902B) G.39-28H39-000 H.47-28H01-090 CD-ROM RUBBER I.45-28001-000 CD CAUTION LABEL 2800 2850 CD-ROM A SSEMBLY . B – 18 B – 18 CD-ROM assembly...

  • Page 116: Appendix B: 2800 Circuit Diagrams

    2800 Circuit Diagrams This appendix has circuit diagrams of the major parts of the 2800 notebook’s mainboard. We’ve included all available diagrams for version 3 and revised diagrams for version 4. So, if you are examin- ing a version 4 mainboard and the diagram you want is not available, refer to one provided for version 3.
  • Page 117 1206 Z0148 +1.8V INT R R(10K) Z0149 PRE Q# +1.8V +1.6V IGNNE# 25,26 SMBCLK SMBCLK F LUSH# A20M# FE RR# G ND A DD0 R(10K) Q(BSS 138) G ND A DD1 + 3VS MAX1617 C – 2 2800 rev. 3...
  • Page 118 RS1# DRDY # HREQ3# HREQ1# C125 C127 DEFER# RS0# B REQ0# 1 RES ET # HLO CK# BNR# 1 RS2# ADS# 1 HREQ4# HREQ2# 0.1U 0.1U 0.1U DB SY # 1 HREQ0# 8P 4RX120 2800 rev. 3 C – 3...
  • Page 119 ST OP# RBF# 10 GDEVSEL# GST OP# 9 7,16,18,19,23,31 DEVSEL# SERR# 7,16,18,19,23,31 GAD-ST BA 10 GT RDY# GIRDY# 9 7,16,18,19,23,31 IRDY# GNT 0# 16 GAD-ST BB 10 7,16,18,19,23,31 FRAME# GNT 4# 8P4RX8.2K T RDY# 7,16,18,19,23,31 C – 4 2800 rev. 3...
  • Page 120 MD29 O N= 0= L OFF=1=H A20M#_CPU SDMD52 MD52 IGNNE#_CPU INT R_CPU CPU SELECT NMI_CPU +1.6V QS3257 CA35 CA36 CA87 CA63 CA19 CA71 CA21 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U D efault: OFF=1 2800 rev. 3 C – 5...
  • Page 121 CA119 CA129 CA128 C176 CA120 CA121 CA130 CA122 C180 VSS1 Z0531 Z0511 VSS2 SDRAM8 T P45 VSS3 VSS4 0.01U 0.1U 0.1U 10U/16V 0.1U 0.1U 0.1U 0.1U C181 Z0512 10U/16V VSS5 SDRAM9 T P46 W40S11-02 C – 6 2800 rev. 3...
  • Page 122 DIMM144_R DIMM144 G ND :145.146 G ND :145.146 INHIB INHIBIT DRAMENA SM-CLK DRAMENB SDRAMACLK SDRAMBCLK Z0622 PX4-SMBCLK T P63 PX4-SMBDAT A SM-DAT A 5 SDRAMADAT A SDRAMBDAT A R361 Z0623 T P64 HC4052_T SSOP 2800 rev. 3 C – 7...
  • Page 123 0.1U 0.1U 10U/16V T P74 Z0708 0.1U 0.1U 10U/16V 10U/16V 0.1U 0.1U T P75 T P76 21,25 IOR# 21,25 IOW# 14,21 MEMR# SD[0..15] SD[0..15] 14,21,25 14,21 MEMW# RST DRV IOCHRDY SA[0..18] SA[0..18] 14,21,25 IOCHK C – 8 2800 rev. 3...
  • Page 124 10P8RX10K T P326 R296 150K Z0811 +3VS RST -IN DRAMENA PHDPWR + 3V +5VS SHDRESET # R288 PHDRESET # SHDPWR DRAMENB R276 100K CA133 MAX6306 RSMRST # 0.1U CA131 0.1U GPI5 GPI16 FUNCTION HiFD 2800 rev. 3 C – 9...
  • Page 125 G C/BE3# 3 3,7,16,23,31 CLKRUN# R(0_0805) Install for Mobility-P GAD[0..31] PIPE# VMD54 R(10K) VMD41 Z0940 VMD59 PVDD VMD61 R(10K) R(0_0805) +2.5V R(0_0805) +2.5V +2.5V 10,27 0_0805 AVDD 0_0805 0.1U 10U/10V CA13 0.1U 10U/10V 0.01U/50V C – 10 2800 rev. 3...
  • Page 126 Close to VGA VPP (AGPVDD) 2,3,4,5,6,7,8,9,11,12,13,14,16,17,20,21,27,28,31 Close to VGA VDDR (VGAVDD) 0_0805 VDDC CA12 CA16 CA15 CA175 0.01U 0.1U 10U/10V 0.1U 10U/10V 0.1U 0.1U 10U/10V 0.1U 10U/10V 10U/10V 10U/10V 0.01U 0.1U 0.1U 0.1U 0.001U 2800 rev. 3 C – 11...
  • Page 127 K M 413 2G 271A /G 512 K M 413 2G 271A /G 512 NO TE: If v ideo RA M s iz e w as 2 MB then c anc el this res is ter R 54 C – 12 2800 rev. 3...
  • Page 128 0 .1 U 1 0U / 1 6V 1 0U / 1 6V E N P V D D 2 N 70 0 2 Q 1 9 D TC 1 1 4 E U A 2800 rev. 3 C – 13...
  • Page 129 74HCT 164 CA164 0.1U Z 1309 74LVC32A T O LED BOARD PCMSPKR# PX4-SPKR +5VS R386 100K +5VS +3VS POWER/SUS_LED# BAT T LED# 28 CA132 CA116 C136 CA49 CA46 AC/CHARGER-LED# 0.1U 0.1U 10U/16V 0.1U 0.1U C – 14 2800 rev. 3...
  • Page 130 8, 21, 25, 27, 31 S U S B # P R 2# G N D D 38 C A 162 C A 163 F 01J 2E 74LV C 74 0. 1U 0. 1U 2800 rev. 3 C – 15...
  • Page 131 % P I O R D Y % S D D A C K # S D D A C K # 30 S IO R D Y 30 % S I O R D Y C – 16 2800 rev. 3...
  • Page 132 R430 R(0) TE RM INAL PCMUSE R189 475PCLK +CBVCC3 475PCLK PCMRI# PCMSPKR# R191 PME# 18,25,31 C139 R431 Z1612 R432 +CBVCC3 PCMUSE R188 R245 R433 R(0) Z1613 R434 R(220K) +CBVCC3 475SUS# DT A114EUA C267 C(0.47u) 2800 rev. 3 C – 17...
  • Page 133 V C C 5E N G N D 0. 1U 10U / 16V LA Y OUT NOTE: MI C 2562A This arae c omponent s hould be c los e to the U28 [ MIC2562A ]. C – 18 2800 rev. 3...
  • Page 134 IRDY # C110 .01U 3,7,16,19,23,31 IRDY # IRDY # DVDDCO LA NPCLK 5,19 LA NPCLK DVDDCO R200 C147 AMD973 PV3LA N R231 100K 1N4148 9,14,16 P CIRS T NS# A MDRST # 19 C161 0.1U/25V 2800 rev. 3 C – 19...
  • Page 135 DVDDT X PV3LAN ST OP# 3,7,16,18,23,31 ST OP# ST OP# DEVSEL# DVDDRX 3,7,16,18,23,31 DEVSEL# DEVSEL# T RDY# 3,7,16,18,23,31 T RDY# T RDY# DVDDRX IRDY# 3,7,16,18,23,31 IRDY# IRDY# DVDDCO LANPCLK 5,18 LANPCLK DVDDCO AMD973-T QFP C – 20 2800 rev. 3...
  • Page 136 T XCT Z2002 T D_CT T X_CT . C – 20 RXC T Z2003 RD_CT RX_CT 18,19 18,19 H0014 PV3LAN 49.9,1%(0805) 49.9,1%(0805) Z2001 PV3LAN CT 2 CB10 CB11 CT 1 10U/16V .01U .01U .01U 10U/16V 2800 rev. 3 C – 21...
  • Page 137 WRPRT # T RK0# U39A CA172 0.1U 74LVC32 SA12 +3VS R239 SA13 U18D 74HC08 Z2101 769CS# Z2104 Z2103 RING-IN# +3VS U39D PCMRI# Z2102 DT C114EUA 74LVC32 U39B 74LVC32 SA14 SA15 U39C 74LVC32 7,14,25 SA[0..16] C – 22 2800 rev. 3...
  • Page 138 IR R X C 47 C 46 IR R X R XD IR MO D E 0.47U 10U /10V_1206 IR MO D E F IR _SE L G N D AG N D H SD L-3600 2800 rev. 3 C – 23...
  • Page 139 R EQ 1# R EQ # G P7 8,16, 31 SE R IR Q SE R IR Q # Z 2 309 R es erv e0 C 229 R 379 TP 309 Y MF 744 C – 24 2800 rev. 3...
  • Page 140 MUT E OUT CA54 C243 GND/HS Z 2427 T P210 GND/HS 0.1U 10U/10V 3.3u Z 2428 R393 T P211 GND/HS (0805) Z 2429 T P212 GND/HS 3.3u (0805) T PA0202 AGND AGND AGND AGND:25,26,27,28,29,30,31,32,33 AGND 2800 rev. 3 C – 25...
  • Page 141 Q 17 Z2509 Z2514 1N4148 EXT AL R360 Z2540 DT C114EUA Q 34 2SJ190 C150 C151 H8/3434F H8FLASH Z2510 V_ST B AC-IN Q 12 F 01J2E CA124 DT C114EUA R252 R137 0.1U 100K 0_0805 C – 26 2800 rev. 3...
  • Page 142 CN20 BCLK SMBCLK 1,25 V_H8 Z2636 R335 BCLK BDAT A DT C114EUA 12,13,14,25,27,28,31 V_H8 BAT T EMP BDAT A SMBDAT A 1,25 R123 C274 C200 C206 R125 BAT CON 6.8K,1% .1u_0805 1N4148 1N4148 V_H8 2800 rev. 3 C – 27...
  • Page 143 Z 2724 T R2 AS431M1 R174 8,14,21,25,31 SUSB# PIN A1=G ND DT C114EUA 43.2K,1% + 1.8V 0_0805 + 2.5VS R179 R(0)0805 + 1.8V 1,4 + 1.6V CORE1.6V JUMPER OPEN_PW CORE1.6V + 1.6V 1,2,3,4 JUMPER OPEN_PW C – 28 2800 rev. 3...
  • Page 144 G N D G N D G N D G N D G N D G N D N 1 1 G N D G N D D I XO N C P U 2800 rev. 3 C – 29...
  • Page 145 T O U C H _ P A D C 2 4 8 C 2 4 7 2 7 K 2 7 K 2 7 0 P 2 7 0 P AGND AGND AGND C – 30 2800 rev. 3...
  • Page 146 T P224 Z3008 T P225 Z3007 USB_CON2 GND :6.7 ACM4532-801-2P-T C164 CA115 LVDS_JAE 10U/16V 0.1U D-USBP0- Z3005 D-USBP0- D-USBP0+ Z3006 D-USBP0+ D-USBP1+ D-USBP1+ D-USBP1- MODEM_CON D-USBP1- DK-USBP0- DK-USBP0- DK-USBP0+ DK-USBP0+ DK-USBP1- DK-USBP1- DK-USBP1+ DK-USBP1+ 2800 rev. 3 C – 31...
  • Page 147 M-MARK1 4,7,8,12,13,21,22,24,29,30 +5VS +5VS 4,7,8,12,13,21,22,24,29,30 PIN18=A18 21,30 WGATE# 1,3,4,5,6,7,8,9,12,13,14,16,18,21,22,23,25 +3VS +3VS 1,3,4,5,6,7,8,9,12,13,14,16,18,21,22,23,25 PIN19=A19 PIN20=A20 21,30 T RK0# 26,27,29 VIN 26,27,29 PIN21=A21 PIN22=A22 21,30 WRPRT# PIN23=A23 D/D-M/B_CON PIN24=A24 21,30 RDATA# PIN25=A25 PIN26=A26 21,30 HDSEL# FDD_CON C – 32 2800 rev. 3...
  • Page 148 10U/16V 25,26 SMBDAT A SMBDAT A SMI# 1206 1206 +1.8V CFERR# INT R 4,7 Z0149 PREQ# 25,26 SMBCLK SMBCLK 4,27 +1.8V +1.6V IGNNE# FLUSH# A20M# FERR# NMI 4,7 ADD0 2N3904 ADD1 + 3VS MAX1617 2800 rev. 4 C – 33...
  • Page 149 ST OP# RBF# 10 GDEVSEL# GST OP# 9 7,16,18,19,23,31 DEVSEL# SERR# 7,16,18,19,23,31 GAD-ST BA 10 GT RDY# GIRDY# 9 7,16,18,19,23,31 IRDY# GNT 0# 16 GAD-ST BB 10 7,16,18,19,23,31 FRAME# GNT 4# 8P4RX8.2K T RDY# 7,16,18,19,23,31 C – 34 2800 rev. 4...
  • Page 150 433MHz OFF OFF +1.6V INT R_CPU NMI_CPU 466MHz +1.6V QS3257 CA35 CA36 CA87 CA63 CA19 CA71 CA21 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U CPU SELECT D efault: OFF=1 O N= 0= L OFF=1=H 2800 rev. 4 C – 35...
  • Page 151 CA119 CA129 CA128 C176 CA120 CA121 CA130 CA122 C180 VSS1 Z0531 Z0511 VSS2 SDRAM8 T P45 VSS3 VSS4 0.01U 0.1U 0.1U 10U/16V 0.1U 0.1U 0.1U 0.1U C181 Z0512 10U/16V VSS5 SDRAM9 T P46 W40S11-02 C – 36 2800 rev. 4...
  • Page 152 10P8RX10K T P326 R296 150K Z0811 +3VS RST -IN DRAMENA PHDPWR + 3V +5VS SHDRESET # R288 PHDRESET # SHDPWR DRAMENB R276 100K CA133 MAX6306 RSMRST # 0.1U CA131 0.1U GPI5 GPI16 FUNCTION HiFD 2800 rev. 4 C – 37...
  • Page 153 GC/BE2# 3 GC/BE3# 3 GDEVSEL# 3,7,16,23,31 CLKRUN# R(0_0805) Install for Mobility-P PIPE# GAD[0..31] VMD54 R(10K) VMD41 VMD59 PVDD VMD61 R(10K) R(0_0805) +2.5V R(0_0805) +2.5V +2.5V 10,27 0_0805 AVDD 0_0805 0.1U 10U/10V CA13 0.1U 10U/10V 0.01U/50V C – 38 2800 rev. 4...
  • Page 154 74 H C T14 2N 7 002 Q 19 D TC 1 14E U A +5 V S U 24 E 74 H C T14 +5 V S U 24 F 74 H C T14 2800 rev. 4 C – 39...
  • Page 155 CA164 0.1U Z 1309 74LVC32A T O LED BO ARD PCMSPKR# PX4-S PKR +5VS R386 100K +5VS +3VS POWER/SUS_LED# BAT T LED# 28 CA132 CA116 C136 CA49 CA46 AC/CHARGER-LED# 0.1U 0.1U 10U/16V 0.1U 0.1U C – 40 2800 rev. 4...
  • Page 156 T RDY # T RDY # DVDDRX IRDY # C110 .01U 3,7,16,19,23,31 IRDY # IRDY # DVDDCO LANPCLK 5,19 LANPCLK DVDDCO R200 C147 AMD973 PV3LAN R231 100K 1N4148 9,14,16 PCIRST NS# AMDRST # 19 C161 0.1U/25V 2800 rev. 4 C – 41...
  • Page 157 T RK0# U39A CA172 0.1U 74LVC32 SA12 +3VS R239 SA13 U18D U18C LVC08 LVC08 Z2101 769CS# Z2104 Z2103 RING-IN# +3VS U39D PCMRI# Z2102 DT C114EUA U39B 74LVC32 74LVC32 SA14 SA15 U39C 74LVC32 7,14,25 SA[0..16] C – 42 2800 rev. 4...
  • Page 158 MUT E OUT CA54 C243 GND/HS Z 2427 T P210 GND/HS 0.1U 10U/10V 3.3u Z 2428 R393 T P211 GND/HS (0805) Z 2429 T P212 GND/HS 3.3u (0805) T PA0202 AGND AGND AGND AGND:25,26,27,28,29,30,31,32,33 AGND 2800 rev. 4 C – 43...
  • Page 159 10MHZ Q 17 Z2509 Z2514 1N4148 EXT AL R360 Z2540 DT C114EUA Q 34 2SJ190 C150 C151 H8/3434F H8FLASH Z2510 V_ST B AC-IN Q 12 R454 F01J2E CA124 DT C114EUA R252 R137 0.1U 0_0805 C – 44 2800 rev. 4...
  • Page 160 CN20 BCLK SMBCLK 1,25 V_H8 Z2636 R335 BCLK BDAT A DT C114EUA 12,13,14,25,27,28,31 V_H8 BAT T EMP BDAT A SMBDAT A 1,25 R123 C274 C200 C206 R125 BAT CON 6.8K,1% .1u_0805 1N4148 1N4148 V_H8 2800 rev. 4 C – 45...
  • Page 161 R177 C121 2SA1797 + 5V C 1:+ 1.8V F 01J2E 0.1U 10U/16V C120 22.1K R459 88.7K,1% D400# 12 Z 2722 Z 2724 T R2 AS431M1 R174 8,14,21,25,26,31 SUSB# PIN A1=G ND DT C114EUA 84.5K,1% C – 46 2800 rev. 4...

  • Page 162: Appendix C: 2820/2850 Circuit Diagrams

    Appendix D 2820/2850 Circuit Diagrams This appendix has circuit diagrams of the major parts of the 2820/2850 notebook’s mainboard. We’ve included all available diagrams for version 2 of this board. If the mainboard you are repairing is a different version, consult the manufacturer for the appropriate diagrams.
  • Page 163 D i a g r a m s 2820/2850 AINBOARD NOTE: HAS INTERNAL PULLUP IN COPPERMAIN PROCESSOR CORE BSEL[1:0 ] SYSTEM BUS FREQENCY 66 MHz HD[0..63] 100MHz HA[3..31] DEP[7:0] DEP0 VCCT DEP0# T 21 DEP1 VCCT DEP1# DEP2 DEP2# DEP3 DEP3# DEP4 DEP4#...
  • Page 164 VCCT VCCT VCCT JUMPER CLOSE VCCT VCCT P_GND VCCT VCCT VCCT VCCT VCCT V_CORE VCCT VCCT VCCT CA52 CA68 CA83 CA78 CA72 CA73 VCCT VCCT 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U VCCT VCCT VCCT VCCT VCCT VCCT VCCT VCCT VCCT VCCT VCCT V_CORE...
  • Page 165 D i a g r a m s MAB6# R403 HD[0..63] MAB7# R420 R(10K) MAB10# R421 (10K) MAB11# R404 (10K) U25A MAB12# R407 HA[3..31] For CPU HOST 100MHz HA3# RS0# HA4# RS0# N OTE : *Board Default Setting HA5# RS1# RS1# RS2# R420 STU FF for BX Mobile PSB Buffers*...
  • Page 166 10,19,21,25,33 C/BE1# C/BE2# 10,19,21,25,33 10,19,21,25,33 C/BE0# C/BE3# 10,19,21,25,33 AD[0..31] REQ0 : C ARD BUS INTA : C ard Bus 10,19,21,25,33 AD[0..31] GNT4# GNT3# 33 REQ1 : AUD IO INTB : AUD IO 10,19,21,25,33 DEVSEL# GNT2# 21 GNT1# 25 LOCK# REQ2 : L AN INTC : LAN , MODEM 10,19,21,25,33 FRAME#...
  • Page 167 D i a g r a m s MD[0..63] MD[0..63] SDMD[0..63] RN30 SDMD[0..63] 16P8RX10 SDMD0 VCCT 1,2,4,6,7,29 SDMD1 SDMD33 MD33 VCCT SDMD2 SDMD32 MD32 CA80 CA65 CA51 CA88 CA90 CA104 CA105 SDMD36 MD36 SDMD4 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U SDMD3 C193...
  • Page 168 PIIX4 sideband(open-drain) signals pull-up resistor The Follow ing are NOT stuffed for Non-G eys erv ille VCCT Do Not S tuff U19 Do Not S tuff R6 7 R97 R10 3 R114 R27 6 R2 85 R5 28 R529 R5 56 Do Not S tuff C5 2 C5 3 C56 C5 7 C58 Do Not S tuff Y4 A20M#...
  • Page 169 D i a g r a m s G TL AG P CM O S CLO CK V_CORE : 0.925V~2.0V RE F E RE NCR RE F E RE NCE RE F E RE NCR RE F E RE NCR V O LTAG E V O LTAG E V O LTAG E...
  • Page 170 +2.5VS 29 +2.5VS CLK2.5VS CLK3VS CLK3VS 0_0805 CA122 C199 CA124 C196 +3VS 0.1U 10U/16V 0.01U 330P R287 CA125 CA123 C202 CA126 CA128 C203 C213 R288 R(10K) 0.01U 0.01U 10U/16V 0.1U 0.1U 10U/16V 330P R289 CLK3VS 2.5V Z0828 R299 769-14M CLK2.5VS VDDQ2 REF1/SPREAD# CLK3VS...
  • Page 171 D i a g r a m s CA158 CA165 CA166 CA162 CA164 CA161 CA175 C260 C249 C250 C265 C261 CA172 CA170 CA155 CA156 CA157 CA174 CA160 CA154 CA159 CA163 CA152 CA153 CA151 10U/16V 10U/16V 10U/16V 10U/16V 10U/16V 10U/16V 10U/16V 10U/16V 0.1U 0.1U...
  • Page 172 %PDA[0..2] %SDA[0..2] %PDA[0..2] %SDA[0..2] %PDD[0..15] %SDD[0..15] %PDD[0..15] %SDD[0..15] %PDCS3# %SDCS3# %PDCS1# %PDIO R# %SDCS1# %SDIO R# %PDIOW# %PDDACK# %SDIOW# %SDDACK# PDDREQ %PIO RDY SDDREQ %SIO RDY USBP1- 32 USBP1+ 32 USBP0- 32 USBP0+ 32 OC-0# 32 AD[0..31] 4, 19,21,25,33 AD[0..31] U32A NMI 6 INT R...
  • Page 173 D i a g r a m s +3VS R410 R354 R425 REQA# +3VS +3VS +3VS RN35 8P4RX10K Z 1128 GNT A# 25 Z 1129 USB48MHZ PX4PCLK PX 4-14M USB48MHZ PX4PCLK PX 4-14M 8 IOCHK 10 R426 DACK0# DREQ0 R398 R353 DREQ1 DACK1#...
  • Page 174 R563 MID1 R564 MID0 VMD47 R397 LCD-SEL1 VMD[0..63] VMD48 R402 VMD[0..63] LCD-SEL2 VMD49 R411 R(10K) LCD-SEL3 11,15 VMD51 R(10K) R173 VRAMCLK C103 VMA[0..7] Z1213 VMA0 Z1214 VMA1 R174 VRAMCLK_OUT Z1215 VMA2 MCK/OE#0 Z1216 VMA3 MEMORY INTERFACE R171 Z1201 VMA4 WE#/OE#1 R169 Z1202 Z1217...
  • Page 175 D i a g r a m s LT _MO B0 + 5V R5_VDDQ R176 R(0) + 3V LT _MO B7 R180 R(10K) LT _MO B2 R217 R(10K) LCDDO0 R1IN0- LCDDO1 R1IN0+ LCDDO2 In sta ll fo r M ob i lity-P R1IN1- LCDDO3 R1IN1+...
  • Page 176 R N 9 8 P 4R X3 3 C A 1 0 C A 9 C A 1 1 C 2 4 C 32 9 V MA 9 V MA 9 V MA 9/A 8 1 4 V MA 8 V MA 8 VM A8 /N C 1 4 VM A1 0...
  • Page 177 D i a g r a m s PA NEL TY PE SW -1 SW -2 SW -3 Defa ult=OFF= 0 +3 V 1 2.1 " S- TFT FUJITSU- FL C 3 1SV C6 S-1 7 O F F O F F S W 3 1 3.3 "...
  • Page 178 +12V +3VS Z1608 T R6 R350 C325 100K C327 V_HDD +3VS 33U/16V_D 33U/16V_D R312 Z1602 V_HDD 18,32 100K SI3456DV C219 C220 CA140 DT C114EUA C217 Z1601 0.1U 10U/16V 0.1u 10U/16V 23,27 EXT FDD# LPT DRV2 33 PHDPWR 2N7002 74AHC1G04 +12V T R3 V_BAY 100K...
  • Page 179 D i a g r a m s +3V S U 41 10, 23,27 S A [0..18] S A 0 V C C S A 1 V C C S A 2 S D [0..15] 10, 23,27 S A 3 C A 193 S A 4 S D 0...
  • Page 180 R 34 7 V _H D D P I O R D Y R 23 2 S I O R D Y V _B A Y R N 21 1 6P 8 R X3 3 P D D 0 3 2 % P D D 0 % P D D 1 P D D 1 3 2...
  • Page 181 D i a g r a m s +VCC_A VPP1 20 VPP0 20 +CBVCC3 VCC3# R530 Z1915 VCC5# R531 R290 R(33K) CAD[0..31] 12,20 RL5C475A2 R270 0_0805 CCLKRUN# R231 +CBVCC3 ZV-PCLK CAUDIO R326 4,10,21,25,33 AD[0..31] ZV-SDAT A 12,25 CAD18 R316 ZV-SCLK 12,25 CA86 CA111...
  • Page 182 C N 27 1 2, 19 C AD [ 0. .3 1 ] G N D C AD 0 C AD 0 /D 3 C AD 1 C AD 1 /D 4 C AD 3 C AD 3 /D 5 C AD 5 C AD 5 /D 6 C AD 7...
  • Page 183 D i a g r a m s PPME# PPME# EAR# EAR# PV3LAN LED2# LED2# WUMI# WUMI# EBD0 EBD0 EBD1 EBD1 R330 R329 EBD2 EBD2 1. 5K 1. 5K EBD3 EBD3 EBD4 EBD4 PV3LAN EBD5 EBD5 EBD6 EBD6 EBD7 EBD7 EBD8 EBD8 LANLNK#...
  • Page 184 PV3LAN +12V T R5 R334 100K CT 2 CB10 CB11 CT 1 Z2205 10U/16V 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.01U 0.01U 0.01U 10U/16V 0.1U PV3LAN R325 100K SI3456DV C210 CA133 C211 DT C114EUA Z2204 0.1U 10U/16V 10U/16V LANPW R 2N7002 LAN P HYSICAL...
  • Page 185 D i a g r a m s SD[0..15] 10,17,27 +3VS +3VS 37N769 10,17,27 SA[0..18] POWER CA190 CA184 C312 RN42 DRVSEL0# 16,32,33 DS0# 10P8RX4.7K 0.01U 0.01U 10U/16V DS1# MT R0# 32,33 MT R0# MT R1# +3VS DIR# FDD-DIR# 32,33 SD10 F LOPPY ST EP# 32,33 ST EP#...
  • Page 186 R N 43 1 0P 8R X2. 7 K L P TD 0 L P D 0 L P TD 1 L P D 1 L P TD 2 L P D 2 L P TD 3 L P D 3 L P TD 4 L P D 4 L P TD 5...
  • Page 187 D i a g r a m s R 47 6 Z 25 0 1 Z 25 5 3 L 38 0 _0 80 5 + 3V S R 47 5 C A 17 3 C 26 2 C A 17 8 0 .
  • Page 188 R524 R507 + A3V CA187 CA189 C301 Z2670 0.1U 0.1U 10U/16V Z2601 R515 R(4.7_0805) Z2654 C303 0.1U Z2613 Z2614 DVDD1 PC_BEEP PC_BEEP Z2611 C271 0.1U R516 R523 + A5V MODEMSPK 33 DVDD2 PHONE C307 Z2655 C292 0.1U R522 AUX_L CA188 CA192 C313 Z2656...
  • Page 189 D i a g r a m s V_H8 Z2713 Z2717 OUT PUT INPUT VA 15,28,30,33 Z2701 1N4148 0_0805 Z2712 V_H8 SENSE FEEDBACK Z2715 R265 CA138 C227 R(150K) SHOUT DOWN C226 WDO# 0.1U 10U/16V ERROR H8RESET# 5.1V_LL34 1N4148 10U/16V V_H8 RESET# CA31 WAT CH-DOG...
  • Page 190 R381 9435 100m ,1W_2512 NSQ 03A04 Z2819 Z2820 Z2821 15,27,30,33 33uH_CDRH127 C332 C230 22U/50V EC10Q S04 22U/50V C242 2220 2220 R366 0.1U 100K 22U/50V 22U/50V DT A114EUA Z2808 R148 C259 Z2805 EC10Q S04 EC10Q S04 2220 2220 Z2807 Z2801 0.01U/50V_1206 R153 R447 R149...
  • Page 191 D i a g r a m s VRM Power Plan V_CORE : 15A C119 0.1U VCCT : 2A RUN/SS +2.5V : 1.2A R212 680K Z2913 R203 R213 Z2901 C120 C118 INT VCC 0.1U SI4416 SI4416 R214 22U/50V_2220 22U/50V_2220 C135 Z2902 Z2914 COSC...
  • Page 192 V _H 8 + 3V + 3V V _H 8 V _H 8 C 2 14 Q 52 C 3 06 C 2 07 Q 50 1 0 U / 1 6V D T A 11 4 E U A 1 0 U / 1 6V 0 .1 U D T A 11 4 E U A...
  • Page 193 D i a g r a m s L 2 0 Z 3 1 0 3 + 5 V S S P C L K Z 3 1 0 4 S P D A T A 2 N 7 0 0 2 R 1 8 C 1 0 6 + 5 V S...
  • Page 194 V_BAY V_BAY CN19 PHDRESET # CN13 PDD7 PDD8 PDD6 PDD9 INDEX# 23,33 INDEX# PDD5 PDD10 PDD4 PDD11 DRVSEL0# 16,23,33 DRVSEL0# PDD3 PDD12 PDD2 PDD13 BAY DASP# PDD1 PDD14 SDCS3# SDCS1# PDD0 PDD15 DSKCHG# 23,33 DSKCHG# SDA0 SDA2 SDA1 PDMARQ 23,33 MT R0# SHDIRQ15 PDIOW#...
  • Page 195 D i a g r a m s Z3302 +3VS CN15 LPST ROBE# LPD0 LPACK# LPD1 4,11,21 INT C# +5VS LPBUSY LPD2 INT D# 4,11,12 LPPE LPD3 LPSLCT LPD4 LPAFD# LPD5 MODEMPCLK SY SPCIRST # 4,10,17 LPERROR# LPD6 LPINIT # LPD7 4,11 REQ3#...
  • Page 196 EBD0 EBD0 EBD1 EBD1 EBD2 EBD2 EBD3 EBD3 EBD4 EBD4 EBD5 EBD5 EBD6 EBD6 EBD7 EBD7 EBD8 CS 18 EBD8 EBD9 LANLNK# EBD9 EBD10 SK 18 EBD10 LED2# EBD11 LED2# EBD11 EBD12 DO 18 EBD12 EBD13 EBD13 EBD14 EBD14 EBD15 EAR# EBD15 L-T CK...
  • Page 197 D i a g r a m s DC/DC B OARD 0_2010 4A_1206 N101 N104 0_2010 60QC04 N102 L1-1 1SS355 EMI FILT ERS N111 V_H8 0.1U_1206 0.1U_1206 0.1U_1206 0.001U 100K 220U/25V POWER JACK 0.1U_1206 22U_2220 0_2010 L1-2 SI2305 100K N103 N105 1SS355 N125...
  • Page 198 12V_IN 1SS355 +12V N250 VIN1 AS2951 +12V N222 SENSE 10QS10 5V_T AP ERROR 4.7U_1210 1SS355 INT VCC 876K,1% 0.1U_1206 0.1U_1206 N221 4.7U_1210 0.001U 100K,1% 1U_0805 N219 Q 21 10U_1206 1SS355 IR7807 1SS355 22U_2220 10U_6.3*7 N201 N210 T G2 T G1 IR7807 N202 N211...
  • Page 199 D i a g r a m s 33_8P4R N301 DCD# DT R# T O1 T I1 DT R1# N302 DSR# T XD T XD1 T O2 T I2 N303 RT S# T O3 T I3 RT S1# N304 RT S# DSR# DSR1# N305...
  • Page 200 NVERTER V I N V I N _ O U T 1 A _ 1 20 6 C N 1 N 00 8 N 02 3 N 02 4 3 3P _ 3K V 2 2U / 5 0 V _ 2 22 0 S M 02 B -B H S S -1 0 .
  • Page 201 D i a g r a m s OTES D – 40 notes...

This manual is also suitable for:

28502820

Table of Contents
