Installation and
Operation Manual
CASCADE
WS-GFR-6-MB
WS-GFR-10-MB
tf. 800.988.8103
t. 360.650.1111
f. 360.650.1166
woodstone-corp.com
Revised November 2014
Doc no: M0050.01
Advertisement
Table of Contents
Related Manuals for Wood Stone WS-GFR-6-MB
Summary of Contents for Wood Stone WS-GFR-6-MB
- Page 1 Installation and Operation Manual ROTISSERIES CASCADE Cascade WS-GFR-6-MB Gas-Fired Rotisserie with Charbroiler WS-GFR-10-MB wood stone corporation tf. 800.988.8103 woodstone-corp.com 1801 w. bakerview rd. t. 360.650.1111 Revised November 2014 bellingham, wa 98226 usa f. 360.650.1166 Doc no: M0050.01...
-
Page 2: Table Of Contents
ELECTRICAL DIAGRAMS � � � � � � � � � � � � � � � � � � � � � 21 LIMITED WARRANTY � � � � � � � � � � � � � � � � � � � � � � � 23 wood stone corporation tf. 800.988.8103 1801 w. -
Page 3: Cascade Rotisserie
WOOD STONE CASCADE ROTISSERIE-CHARBROILER STONE FIRED COOKING EQUIPMENT WS-GFR-6-MB (6 SPIT) AND WS-GFR-10-MB (10 SPIT) GAS-FIRED ROTISSERIE-CHARBROILER ADDITIONAL COPIES AVAILABLE UPON REQUEST WS-GFR-6-MB shown with left side drive and front skirting wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. -
Page 4: Cautions And Warnings
Cascade Gas-Fired Rotisserie & Charbroiler Installation and Operation Manual INSTALLATION AND OPERATING INSTRUCTIONS FOR THE GFR-(6,10)-MB-(NG, LP) WOOD STONE CASCADE GAS-FIRED ROTISSERIE-CHARBROILER RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual at woodstone-corp�com� For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�... - Page 5 WARNING: This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth of Massachusetts. SAVE THE INSTRUCTIONS Wood Stone’s Gas-Fired Cascade Rotisserie-Charbroiler has been tested and approved by Intertek Testing Services, and is ETL Listed to ANSI Z83.11b - 2009, CSA 1.8b-2009 and to NSF/ANSI Standard 4 - 2009.
-
Page 6: Specifications
OR Propane (LG) of the unit� NEMA 5-15 plug Maximum gas inlet pressure Refer to data plate when installing� 1/2 psi (14 inches W�C�) wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 7: Clearances & Venting
VENTING The Wood Stone Cascade Gas-fired Rotisserie must be vented using a Listed Type 1 exhaust hood or one constructed in accordance with the Standard for Ventilation Control and Fire Protection of Commercial Cooking Operations, NFPA 96, and all relevant local and national codes, and in a manner acceptable to the authority having jurisdiction�... -
Page 8: Assembly
(6) 10-32 x 1/2" stainless steel pan head machine screws (supplied) as shown at right� (6) 10-32 x 1/2" stainless steel pan head machine screws wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. - Page 9 From the inside of the rotisserie cabinet, feed the yellow electrical cable through the controller cutout in the front of the charbroiler table� d. Secure the electrical harness to the back of the Controller faceplate and reinstall the controller� wood stone corporation tf. 800.988.8103 1801 w. bakerview rd.
- Page 10 Charbroiler and the controller housing� No fasteners are required to hold the pieces in place� See the picture at left for the proper positioning of the flashing� wood stone corporation tf. 800.988.8103 1801 w. bakerview rd.
- Page 11 Use the high-temperature silicone sealant (provided) to fill spaces between the charbroiler and the rotisserie cabinet. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f.
-
Page 12: Utility Connections
The gas connection to the charbroiler should be made from below the unit through the gap at the rear of the charbroiler table� Refer to the Montague Legend installation and operation manual for proper gas connection to the charbroiler� Make sure regulator assembly is installed (pg� 8)� wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. -
Page 13: Gas Information
DO NOT USE A FLAME TO TEST FOR LEAKS! Wood Stone recommends that a manual, individual appliance shutoff valve be supplied, located between the rotisserie and the main gas supply, and be left readily accessible� ROTISSERIE BURNER PRESSURE TESTING There are (2) pressure test ports (one for each burner), located on the respective valves�... -
Page 14: Utility Information
Wood Stone recommends that the appliance’s individual shutoff valve (supplied by others), located between the rotisserie and the main gas supply, be left readily accessible� Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies�... -
Page 15: Controller
ALWAYS WAIT FIVE MINUTES BEFORE ATTEMPTING TO RELIGHT THE BURNERS. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 16: Daily Operation
Failure to fill the cabinet with water can result in warping of the cabinet and fire hazard from grease accumulation� Wood Stone recommends allowing the water to trickle into the tray while the rotisserie is in use to allow grease to flow safely out of the cabinet through the drain, which must be connected to a grease trap�... - Page 17 2. Press the Push Button Circuit Breaker, located in center of controller SPIT DIMENSIONS GFR-6 Using 10 spits GFR-10 Using 5 spits wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com...
-
Page 18: Cleaning The Rotisserie
All rotisserie attachments (spits, forks, basket pins) should be cleaned between uses using an approved mild detergent, hot water, and an approved sanitizing solution� Alternatively, these items can be cleaned in a dishwasher� EXHAUST HOOD Refer to the exhaust hood manufacturer’s recommendations for inspection, maintenance and cleaning� wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. -
Page 19: Optional Spits
Cascade Gas-Fired Rotisserie & Charbroiler Installation and Operation Manual A. STANDARD ANGLE SPIT This Standard Angle Spit included with all Wood Stone rotisseries� Six to seven average-sized birds can be quickly loaded� The perforations are convenient for securing the string or skewers used to bind the legs�... -
Page 20: Preventive Maintenance
One pump is sufficient� MOTOR BRUSHES REPLACEMENT (APPROXIMATELY EVERY 3 YEARS) The three year replacement recommendation is based upon an average daily use of 10 hours� Contact the Wood Stone Service Department or your local service technician for service�... -
Page 21: Electrical Diagrams
These electrical schematic diagrams can also be found panel affixed to the inside of the drive-side Service Panel of the rotisserie. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... - Page 22 Cascade Gas-Fired Rotisserie & Charbroiler Installation and Operation Manual ELECTRICAL LINE DIAGRAM This electrical line diagram can also be found affixed to the inside of the drive-side Service Panel of the rotisserie� wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f.
-
Page 23: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
