Installation and Operation Manual
with a Wood Stone Home Oven
woodstonehome.com
M0005.01
info@woodstonehome.com
Rev. May 2014
MOUNTAIN HOME 4' , 5' , 6' & 7'
WS-MH-(4, 5, 6, 7)-RFG-IR
WS-MH-(4, 5, 6, 7)-RFG-IR-W
Advertisement
Table of Contents
Related Manuals for Wood Stone Mountain Home WS-MH-4-RFG-IR
Summary of Contents for Wood Stone Mountain Home WS-MH-4-RFG-IR
-
Page 1: Installation And Operation Manual
Gas-Fired & Wood-Fired Residential Models enhance your food, home & lifestyle with a Wood Stone Home Oven An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com... -
Page 2: Table Of Contents
Limited Warranty ..... . 35 An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. -
Page 3: Cautions & Warnings
Cautions & Warnings Mountain Home Oven Installation and Operation Manual Installation and Operation Manual THE WOOD STONE RESIDENTIAL MOUNTAIN SERIES STONE HEARTH COOKING EQUIPMENT WS-MH-(4, 5, 6, 7)-RFG-IR Gas Fired Models WS-MH-(4, 5, 6, 7)-RFG-IR-W Gas/Wood Fired Models Please read this entire manual before you install the appliance. - Page 4 Commonwealth of Massachusetts. DO NOT THROW AWAY THIS MANUAL. RETAIN THIS MANUAL FOR FUTURE REFERENCE. Additional copies of this manual and prompt responses to service/maintenance questions are available from Wood Stone at (800) 578-6836 or visit woodstonehome.com ANSI Z21.1-2010 CSA 22.2 No.3-M1998,R2009 CAN1-1.1-M81,R2006...
-
Page 5: Mh-4 Specifications
MH-4 Specifications Mountain Home Oven Installation and Operation Manual plan view facade information All facades or enclosures are by others; all 49 1/2" 1260mm appliances require a 1-inch side clearance, and a 5 3/4" 5 3/4" 14-inch top clearance to combustible construc- 150mm 150mm flue collar... -
Page 6: Specifications
MH-5 Specifications Mountain Home Oven Installation and Operation Manual plan view facade information All facades or enclosures are by others; all appliances require a 1-inch side clearance, and a 64 1/4" 1630mm 4" 6 1/2" 14-inch top clearance to combustible construc- 100mm 170mm flue collar... -
Page 7: Unloading And Moving
DO NOT TURN THE APPLIANCE ON ITS SIDE! Contact Wood Stone if the appliance must be turned on its side for specific instructions. Moving a Wood Stone appliance can present interesting challenges to even the most experienced riggers. Take your time, use your head, secure the proper equipment and make safety your first priority. -
Page 8: Clearances
APPLIANCE BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS. CLEARANCES 1. The Wood Stone MH models require a minimum 1" clearance to combustibles from all sides, and 6" clear- ance to combustibles from the top. If building a facade that will contact the appliance, use completely non-combustible materials. - Page 9 Clearances Mountain Home Oven Installation and Operation Manual THE FOLLOWING CLEARANCE INFORMATION APPLIES TO ALL WOOD STONE MH SERIES APPLIANCES WARNING: Do not pack required air spaces with insulation or other material. Any facade materials above and 6" to either side of the doorway of the appliance, must be NON-COMBUSTIBLE. Note: 0" side and top clearance to non-combustible materials, however the respective clearances to combustibles are transferred to those non-combustibles.
-
Page 10: Facade Details
Go to woodstonehome.com for detailed instructions for constructing a facade around a Wood Stone Appliance. Hatched areas shall not be exposed after installation of facade. Any facade wall 6" to either side of the doorway and above must be constructed of non-combustible building materials. -
Page 11: Outdoor Installations
The appliance may be installed in a weatherproof enclosure. If so be sure to maintain all clearances and adhere to the installation requirements included in this manual. Wood Stone also offers the following options to enclose the area beneath the appliance: Lower Lagging Kit Stand Wrap Kit Keep the area around and beneath the appliance clear of grass, leaves and other combustible materials. -
Page 12: Gas Specifications
The Wood Stone Gas appliances are equipped with a 3/4" FNPT gas connection located at the rear left of the appliance. Have a licensed gas installer provide the hook-up and test all fittings and pipe connections for leaks. - Page 13 9.2" 9.5" Wood Stone recommends that the appliance’s individual shutoff valve (supplied by others) be left readily acces- sible. Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies.
-
Page 14: Electrical Specifications
(3) prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle. Do not cut or remove the grounding prong from the plug. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. -
Page 15: Venting
The following are the manufacturer’s recommendations for venting the Wood Stone MH (Mountain Home Series) appliance. It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone appliance. All duct material must be Listed to UL 1978, or fabricated to the specifications of a grease duct. Submit your venting plans to your local authorities before proceeding with your installation, as there may be additional requirements in your area. -
Page 16: Venting For Outdoors
The appliance is available with an optional collapsible chimney assembly with rain cap (shown below) for use with freestanding outdoor installations without a roof structure above the oven. Contact your dealer or Wood Stone for more information. -
Page 17: Assembly
1 inch of stucco. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com... -
Page 18: Mounting A Mantle
(provided). Clean up any sealant before it dries. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01... -
Page 19: Front Panel Assembly
Pointer the clamp once the throttle knob is in the Control Knob desired position. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01 Bellingham, WA 98226 U.S.A. -
Page 20: Extension Panel Assembly
Make certain the valve is in the full open position by turning the attached throttle rod extension counterclockwise until it stops. Continued An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01... - Page 21 1/8" minimum Pointer collar set screws clearance An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0005.01 Bellingham, WA 98226 U.S.A.
-
Page 22: Stucco Application
Stucco Application Mountain Home Oven Installation and Operation Manual This figure depicts the applica- tion of stucco on a Wood Stone appliance. Use no less than one inch of stucco coating to cover all exposed metal lathing on the appliance. -
Page 23: Controller
ATTENDRE 5 MINUTES AVANT DE RÉALLUMER 1-800-988-8103 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01 Bellingham, WA 98226 U.S.A. -
Page 24: Oven Start-Up
• Small "crazing" cracks will occur with normal heating and cooling. They will not effect the performance or durability of the oven. If cracks 1/8" wide or more develop, contact Wood Stone for evaluation. Night Heat Retention Doors Flame Height Control Knob An ongoing program of product improvement may require us to change specifications without notice. -
Page 25: Daily Operation
100–800 °F. Once proper temperatures for your application have been established, there should be little or no need to change the hearth set point. The hearth temperature readout will display “LO” until the oven floor reaches 100 °F. Go to woodstonehome.com for detailed information on cooking in your Wood Stone oven. CLEANING THE APPLIANCE 1. -
Page 26: Flame Height Control
Each flame height corresponds to a saturated floor temperature. Several factors need to be accounted for in order to determine this relationship for each appliance. FLAME HEIGHT INDICATOR SETTINGS FOR WOOD STONE MOUNTAIN SERIES APPLIANCES 1. Heat Up Flame: Set Flame Height Control Knob to “5”... -
Page 27: Wood Burning
If at any time, you feel the gas components of the appliance are not operating properly, turn the appliance off, shut off the gas supply and call Wood Stone to arrange for servicing of the appliance. An ongoing program of product improvement may require us to change specifications without notice. -
Page 28: Daily Maintenance
OVEN INTERIOR Wood Stone recommends the use of a long-handled, stiff-bristled brush for sweeping aside excess food particles that at will accumulate on the floor of the oven during use. The oven floor can be cleaned with a damp rag. DO NOT USE ICE OR EXCESSIVE WATER ON THE FLOOR. -
Page 29: Thermal Cleaning
Mountain Home Oven Installation and Operation Manual THERMAL CLEANING If a Wood Stone gas-fired appliance is operated at low temperatures (below 450 °F), it is possible that grease residue from food could accumulate on the interior of the cooking chamber. To remove this accumulation, first remove all utensils, and wipe off any excess spillage. -
Page 30: Troubleshooting
2. High limit device has tripped. Allow the cooking chamber to cool and then turn the controller back on. Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your appliance. An ongoing program of product improvement may require us to change specifications without notice. -
Page 31: Electrical Diagrams
Electrical Diagrams Mountain Home Oven Installation and Operation Manual RFG-IR 120 VAC MODELS An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01 Bellingham, WA 98226 U.S.A. - Page 32 For additional interlock options, see Wood Stone Interlock Options supplement in the Manuals section on the website woodstone-corp.com, or contact Wood Stone for additional information.
-
Page 33: Burner Operation Sequence
Floor reaches the set point Temperature- Controller turns off power to SV1 and underfloor burner shuts off An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0005.01 Bellingham, WA 98226 U.S.A. -
Page 34: Fuelwood Facts
(low weight, low-med heat, poor coaling, high sparking and high residual creosote). Do not use pressed wood products in Wood Stone food service equip- ment, they may damage the ceramics. -
Page 35: Limited Warranty
In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser.
