- Page 1 DCQ-2000 Digital Color Quad Processor Operation Manual 15/02/2002...
-
Page 2: Table Of Contents
Index Features ..........3 Introduction........... 4 Important Safeguards ......5 Front Panel Controls ......6 Rear Panel Connectors ......6 Installation ..........7 Connections Typical ........8 Live Zoom Mode ......8 Operating Procedure Quad Mode ........ 9 Single Camera Mode ....9 Sequential Mode ....... -
Page 3: Features
Features True Digital Color Video Quad CCIR-601 Digital Standard NTSC/PAL True Real Time (60 ips Quad image update rate) VCR Input and Output with Playback High Quality Interpolated 2X Zoom Alarming Inputs per Camera NO or NC Programmable Alarm Output Relay NO &... -
Page 4: Introduction
VCRs that do not include this feature. There are separate VCR input and output connectors so playback can be done through the quad itself. Upon video loss the DCQ-2000 will sound a buzzer and output an alarm condition. The DB-9 connector has hardwire inputs for alarm contacts for each camera. -
Page 5: Important Safeguards
Important Safeguards 1. Read manual thoroughly before setup or operation of this product. 2. Save this booklet for further reference. 3. Follow the instructions and heed all warning notices 4. Do not use liquid or aerosol cleaners on this product, use a slightly damp cloth only. -
Page 6: Front Panel Controls
Front Panel 1 Setup Menu/VCR Mode 4 Select Item (in menu) 2 Quad Mode/Sequential 5 Change Status (in menu) 3 Camera Select Rear Panel 1 Video In (1-4) 4 Alarm Port 2 Monitor Out 5 Power In (12VDC) 3 VCR Input (Playback In) 6 VCR Output (Record Out) -
Page 7: Installation
Installation 1. Place the unit on a flat, stable surface. Avoid locations that are subject to direct sunlight, excessive heat, moisture, or dust. 2. Connect the BNC cables from the cameras to the respec- tive Video In ports. Each camera input is terminated with 75 ohms and require 1 V P-P video signal for proper operation. -
Page 8: Typical
Typical Installation 12VDC Power Alarms Monitor Color Cameras Live Zoom Mode Monitor Color Camera... -
Page 9: Operating Procedure
Operating Procedure Upon powering up your quad the unit will sequence between all the cameras and the quad display automatically. The VCR will always record the quad image no matter what the picture is on the monitor display except in the VCR Playback mode. Quad Mode Press the “Quad Key”... -
Page 10: Live Zoom Mode
Live Zoom Mode The DCQ-2000 can be used for live zoom of any video source. However when doing this you must connect your live video source directly to the “VCR Input” on the Quad. Then you will enter the VCR Playback mode without the VCR being con- nected. -
Page 11: Setup Menu
1st OSD Menu Auto Reset: Every time there has been an Alarm or V Loss event, the DCQ-2000 will trigger an internal timer. When the timer reaches the value that the user sets, this unit will clear the event automatically. (Unit:Second) The user can clear the event by pressing any key. -
Page 12: 2Nd Page Menu Screen
spuratic triggers. VLoss Sens: The VLoss event will not occur unless the VLoss trigger is longer than what is set here by the user. (Unit:millisecond) Quad Interval: This is the dwell time for display of the Quad picture while in the sequencing mode. (Unit:second) 2nd OSD Menu Ch:This selects the input channel or camera number that is to be programmed. -
Page 13: 3Rd Page Menu Screen
very low chroma level, it must set to “Fix” to disable the autoremover. This usually happens with a very long cable connection between the camera and the Quad if no frequency compensation is used. The limitation of the length will depend on the specification of the cable. -
Page 14: 4Th Page Menu Screen
Quad: Enable or disable the on-screen display of the Date, Time or Title on the “VCR Out” and monitor. VLoss:Enable or disable the unit to check for video loss for all cameras. 4th OSD Menu P: The selects the page number of the alarm record event log. There are 11 pages with 9 records in each page with a total of 99 records maximum in the alarm log. -
Page 15: Alarms Alarm Pin Outs
Alarm Port DB-9 Female (Looking at Rear of Quad) 1. Alarm Out COM 2. Alarm Out NO 3. Alarm Out NC 4. GND 5. Alarm Control 6. Ch1 Alarm Input 7. Ch2 Alarm Input 8. Ch3 Alarm Input 9. Ch4 Alarm Input Shield - GND Note: The Alarm input 1 to 4 and clear input are pulled high internally. -
Page 16: Alarm Mode Operation
Alarm Mode Operation Alarm Inputs When a single alarm input is activated to a true alarm condition then that camera will become full screen for the duration of the alarm dwell. If the alarm is still true at the end of the dwell time, the Quad screen will display for its dwell period and then repeat the alarm dwell for that camera. -
Page 17: Alarm Output
However the DCQ-2000 can operate in the NTSC format. This requires the changing of the internal jumpers only. Please refer to an AVE approved service technician for converting the DCQ-2000 to NTSC format. There is a total for 4 jumpers. Jumpers... -
Page 18: Specifications
Specifications Video Standard CCIR601 NTSC/PAL Sampling Rate 910 x 525 pixels per line for NTSC 1135 x 625 pixels per line for PAL Total Display Pixels 858 x 512 pixels for NTSC 864 x 576 pixels for PAL Display Rate 60 fps NTSC 50 fps PAL Quad Update Rate... -
Page 19: Warranty Information
Damages caused by fire, flood, lightning, vandalism, collision, acts of God, or other events beyond the control of MTI. External parts such as cabinet and key pad. Damages resulting from loss of use, loss of time or... - Page 20 Multiplexer Technology Inc. 9070 Royal Monarch Ct., Las Vegas, Nevada, 89147 Telepone 702-341-0333 Fax 702-341-0334 Email: MTI@multiplexertechnology.com Website: www.multiplexertechnology.com...
