- Page 1 User Manual Lumerus™ LED Exam Light U.S. & Canada (888) 520-4998 International (801) 875-4998 Strength in patient care. ™ www.mti.net...
- Page 2 THIS PAGE IS INTENTIONALLY BLANK.
-
Page 3: Table Of Contents
T able of Contents APPLICABLE MODEL(S) ........................................................IV REVISION HISTORY TABLE ......................................................IV GENERAL INFORMATION ........................................................1 Purpose of this Manual ......................................................1 Intended Use ............................................................1 Symbols and Warnings......................................................2 Symboles et Avertissements ..................................................2 Safety Instructions ........................................................3 Electromagnetic Interference ..................................................3 Electrical Requirements .......................................................3 Contraindications .......................................................... -
Page 4: Applicable Model(S)
User Manual | MTI Lumerus™ LED Light APPLICABLE MODEL(S) This manual is for the following part numbers and serial numbers.: PART NUMBER DESCRIPTION EFFECTIVE S/N 1000200 Lumerus Exam Light w/Std 3-pronged Plug 160310001- Current 1000205 Lumerus Exam Light w/IEC 320 Plug & Outlet Box... -
Page 5: General Information
User Manual MTI Lumerus™ LED Light GENERAL INFORMATION Purpose of this Manual This manual covers the safety, installation, instructions for use, and maintenance of this equipment. It is intended that it be used by the service professional installing the equipment and by the medical professionals who have been trained to use it. -
Page 6: Symbols And Warnings
User Manual | MTI Lumerus™ LED Light Symbols and Warnings Class 1, Type B, Medical Equipment This manual contains Notices, Cautions, and Warnings, which are meant to call attention to particular parts Proper shipping orientation for the product or sections of this manual. Since safety is our first Orientation d’embarquement correct pour... -
Page 7: Safety Instructions
User Manual | MTI Lumerus™ LED Light Electromagnetic Interference (WEEE) Waste of Electrical and Electronic Equipment This equipment is designed and built to minimize electromagnetic interference with other devices. Déchets d’équipements électriques et However, if interference is noticed between another électroniques... -
Page 8: Contraindications
The Lumerus™ is an exam light that comes with a 3” light head. It can be mounted to a 1" post accessory or to the back of an MTI Exam Chair. The expected position of the operator is to the front of, to the side of, or behind the light. - Page 9 User Manual | MTI Lumerus™ LED Light 1" POST ACCESSORY LIGHT MOUNTING BRACKET MOUNTED TO LIGHT IN P/N 1000207 Mounting Post Mounting hole Set Screw CHAIR MOUNTED LUMERUS™ LED LIGHT Installed bolts Lumerus™ LED Light Replacement bolts Motor Access Panel...
-
Page 10: Installation
User Manual | MTI Lumerus™ LED Light INSTALLATION Required Tools Allen Wrenches, 3/32" (for 1" post mounted CAUTION/PRÉCAUTION light) and 5/32" & 3/16" (for chair back To move equipment, lift only from the equipment’s main mounted light) structure. Phillips Screw Driver (for chair back Pour déplacer l’appareil, soulevez seulement de la... -
Page 11: Installation
User Manual | MTI Lumerus™ LED Light Installation The Lumerus™ can be purchased for installation on a 1" post accessory for your MTI Exam Chair or for installation on the back of an MTI Exam Chair. 1" Post Accessory Installation 1. -
Page 12: Operation
User Manual | MTI Lumerus™ LED Light To install the Lumerus™ with an IEC 320 plug to the back of an MTI Exam Chair Remove the four bolts 2. Attach the Lumerus™ with 3. Remove the motor access 4. Connect the 4-pin... -
Page 13: Controls
Flexible Neck Pivot Head The MTI Lumerus lights have a flexible neck to position The MTI Lumerus lights have a pivot head, which has a the light head in the desired position. 160˚ vertical and 180˚ horizontal rotation. 1. To move the light: 1. -
Page 14: List Of Accessories
User Manual | MTI Lumerus™ LED Light Adjustable Bracket The MTI Lumerus lights may have an adjustable bracket that allows a 90˚ pivot at the mounting location (1" post mounted and back mounted versions). 1. To adjust the bracket: A. Loosen the knob on the bracket. -
Page 15: Maintenance
La procédure de La Maîtrise des Énergies Dangereuses (lockout/ déconsignation) § 1910.147 doit être suivie pour MTI understands that many customers prefer to use a désactiver l’équipement, empêchant la libération des pre-mixed disinfecting solution in a spray or wipe. It is énergies dangereuses lors de l’exécution des activités de... -
Page 16: Preventative Maintenance
All fasteners and pins should be in place and Medical Technology Industries, Inc. (hereinafter referred to tightened securely. as MTI), shall repair or replace products of its manufacture, Lubricate pins and moving joints as needed with which prove to be defective in material and/or workmanship lithium grease. -
Page 17: Troubleshooting Guide
User Manual | MTI Lumerus™ LED Light TROUBLESHOOTING GUIDE NOTICE/AVIS For more information on this equipment, including circuit diagrams, parts and service manuals, and other descriptions, please contact MTI. Pour plus d’informations sur cet équipement, y compris des schémas de circuits, les manuels de service et pièces, et autres descriptions, s’il vous plaît contacter MTI. -
Page 18: Specifications Lumerus
User Manual | MTI Lumerus™ LED Light SPECIFICATIONS LUMERUS™ DESCRIPTION SPECIFICATION Number of LEDs 1 White LED LED Life 70,000 hours Color Temperature (CCT) 4,100˚ K , ±300˚ K Working Distance 16” (40.6 cm) Light Intensity 24,800 lux (2,300 fc) Spot Size 5”... - Page 19 THIS PAGE IS INTENTIONALLY BLANK.
- Page 20 Salt Lake City, Utah, 84104-6572 (800) 924-4655 • (801) 875-4999 • Fax (801) 952-0548 www.mti.net © MTI, Inc. All rights reserved. Strength in patient care. ™ MTI reserves the right to make any product changes without notice. 073092 Rev C...
