Page 1: User Manual
User Manual (For Web browser viewing) Mode: HV-72CIC Indoor Wireless IP Camera Color: White... -
Page 2: Chapter 1 Camera Installation Guide
Chapter 1 Camera installation guide Product overview... -
Page 4: Chapter 2 Features
Chapter 2 Features 1. Basic features The basic function of IPCAM is to provide remote video on the IP network. Real-time video images (720P, QVGA and VGA) quality are transmitted at up to 30fps on the LAN/WAN by using H.264/MJPEG hardware compression technique. IPCAM is completely based on TCP/IP standard network protocol, Embedded WEB server in IPCAM supports IE browser, Centralized monitoring the client and mobile phone client browser. -
Page 5: Chapter 3 Web Instructions
Chapter 3 web instructions 1. Search Tool: 1.1 Please connect the camera to the power and network cable, then open from CD to enter the following interface: 1.2 Then click to search online camera list, double click the selected camera:... - Page 6 1.3 Input the user name: “admin”(no password). Click 2. Select Language and Login mode Select languages 2.1 Double click the selected mode to enter IE page, It will appear a prompt as below:...
- Page 7 2.2 You need to download and install OCX plug-in for first time using IE 2.3 Install directly after decompression 2.4 Refresh the IE page to watch video after installation...
- Page 8 3. Direction for using IE operating interface 3.1 Direction for main interface ：Flip vertical ：mirroring image image ：IO switch : You can choose 50HZ or 60HZ to adjust indoor and outdoor mode. Resolution adjustment; 720p（1280×720） VGA(640×480) and QVGA(320×240) can be set.
- Page 9 ： Frame rate adjustment；1-30 frame rate can be ：Adjustable if needed； Factory default: It’s used to restore factory default in case you adjust disorderly ： Speaker, You can listen to the sound from the camera where it is located ：Microphone, When click both icons, the operator and front of the camera can achieve two-way voice talking.
- Page 10 3.2 Basic information Click to enter parameter management page in the main interface as follows: 3.2.1 Device information Click as follows: : The version number of system software...
- Page 11 The version number of application software : Display the name of device (customers can set the name if they want) : That is Factory Series Number : Alarm status display : You can see whether the device enabled UPNP function and its state : You can see a prompt of DDNS server if DDNS is set normally, : Display wired MAC address of the device : Display Wireless MAC address of the device...
-
Page 12: Alarm Service Settings
3.3 Alarm service settings 3.3.1 Alarm service Click as shown below: Choosing alarm mode: If you select , you will see:... -
Page 13: Mail Service Settings
There are some Alarm modes for selection: IO Linkage, sending mails, uploading images, Alarm preset linkage. for example: all-day motion detection Arming, you can set detection sensitivity to 10; it will output high level via liking IO, sending mails, uploading a ftp image every 10 seconds, then aiming at preset position”1”;... - Page 14 key feature is E-mail Alarm, if the camera is triggered alarm, it will send alar m messages to your settled email address. : fill in E-mail address of the sender. : Fill in E-mail address to receive Alarm messages. : Fill in the sender’s mailbox website, such as QQ mailbox: smtp.qq.com : Fill in username of sender’s mailbox : Fill in the password of sender’s mailbox Note: The camera need to connect Internet, if the password of sender’s mailbox changed,...
- Page 15 3.3.3 FTP service Click as shown below: This feature is used to upload snapshots to specified folder on FTP server, it can’t be normally used if there is no access to internet. : Fill in URL of the site on which you want to upload : The default is 21 : Fill in FTP username : Fill in FTP user’s password...
-
Page 16: Network Configuration
3.3.4 Alarm log Click , you can check alarm information in below blank form: 4. Network configuration Click Get DHCP, device will obtain IP automatically:... - Page 17 Unlike legacy solutions, HVCAM does not require port forwarding. There is no risk from leaving ports open on the network. HVCAM uses secure peer to peer networking solution which provides a secure, encrypted connection each time your camera is viewed...
- Page 18 5. Multi-Device Settings Click , you can control 9 camera(in LAN) simultaneously. Then video show, you can add 9 cameras at the same time.
- Page 19 6. Back Click , It will back to monitoring main interface. Product Parameters: Model HV-72CIC Platform Smartphones Android，IOS app in CD Sensor CMOS sensor Image Display resolution 720P sensor Lens f: 3.6mm, Audio Input/Output Linear input/output, two-way voice intercom Video compression...
