Summary of Contents for HVCAM HV-72BIC
-
Page 1: User Manual
User Manual (For Web browser viewing) Mode: HV-72BIC Outdoor Wireless IP Camera... -
Page 2: Chapter 1 Camera Installation Guide
Chapter 1 Camera installation guide Product overview 1，WIFI antenna, wireless signals acceptor, 2 Waterproof Cases 3 led lights it will flashing when no lights 4 Lens 5 Brackets 6 Extend line 7 Reset button 8 Network interface 9 Power interface... -
Page 3: Chapter 2 Features
Chapter 2 Features 1. Basic features The basic function of IPCAM is to provide remote video on the IP network. Real-time video images (720P, QVGA and VGA) quality are transmitted at up to 30fps on the LAN/WAN by using H.264/MJPEG hardware compression technique. IPCAM is completely based on TCP/IP standard network protocol, Embedded WEB server in IPCAM supports IE browser, Centralized monitoring the client and mobile phone client browser. -
Page 4: Chapter 3 Web Instructions
Chapter 3 web instructions 1. Search Tool: 1.1 Please connect the camera to the power and network cable, then open from CD to enter the following interface: 1.2 Then click to search online camera list, double click the selected camera:... -
Page 5: Select Languages
1.3 Input the user name: “admin”(no password). Click 2. Select Language and Login mode Select languages 2.1 Double click the selected mode to enter IE page, It will appear a prompt as below:... - Page 6 2.2 You need to download and install OCX plug-in for first time using IE 2.3 Install directly after decompression 2.4 Refresh the IE page to watch video after installation...
- Page 7 3. Direction for using IE operating interface 3.1 Direction for main interface ：OSD message ：Flip vertical ：mirroring image image ：IO switch : You can choose 50HZ or 60HZ to adjust indoor and outdoor mode. Resolution adjustment; 720p（1280×720） VGA(640×480) and QVGA(320×240) can be set.
- Page 8 ： Frame rate adjustment；1-30 frame rate can be ：Adjustable if needed； Factory default: It’s used to restore factory default in case you adjust disorderly ：You can create 16 preset positions ：Snapshot : Recording Local video ： parameters settings One camera viewing Four cameras viewing Nine cameras viewing Adjust the Pan/tilt speed...
- Page 9 3.2.1 Device information Click as follows: : The version number of system software The version number of application software : Display the name of device (customers can set the name if they want)
- Page 10 : That is Factory Series Number : Alarm status display : You can see whether the device enabled UPNP function and its state : You can see a prompt of DDNS server if DDNS is set normally, : Display wired MAC address of the device : Display Wireless MAC address of the device 3.2.2 Video path Click...
- Page 11 The camera will record automatically according to your time schedule. 3.3 Alarm service settings 3.3.1 Alarm service Click as shown below: Choosing alarm mode: If you select , you will see:...
- Page 12 There are some Alarm modes for selection: IO Linkage, sending mails, uploading images, Alarm preset linkage. for example: all-day motion detection Arming, you can set detection sensitivity to 10; it will output high level via liking IO, sending mails, uploading a ftp image every 10 seconds, then aiming at preset position”1”;...
- Page 13 3.3.2 Mail service settings Click , the following screen will appear: key feature is E-mail Alarm, if the camera is triggered alarm, it will send alar m messages to your settled email address. : fill in E-mail address of the sender. : Fill in E-mail address to receive Alarm messages.
- Page 14 3.3.3 FTP service Click as shown below: This feature is used to upload snapshots to specified folder on FTP server, it can’t be normally used if there is no access to internet. : Fill in URL of the site on which you want to upload : The default is 21 : Fill in FTP username : Fill in FTP user’s password...
- Page 15 3.3.4 Alarm log Click , you can check alarm information in below blank form: 4. Network configuration Click Get DHCP, device will obtain IP automatically:...
- Page 16 Unlike legacy solutions, HVCAM does not require port forwarding. There is no risk from leaving ports open on the network. HVCAM uses secure peer to peer networking solution which provides a secure, encrypted connection each time your camera is viewed from a remote location.
- Page 17 : Without preset function when start using. : 0-16 preset positions can be chosen, aiming at matched position when start the device; if it’s prohibited, default position is in the center. : Adjust the PTZ speed : set and start “up and down “or “left and right” to inspect cruise laps 6.
- Page 18 Then video show, you can add 9 cameras at the same time. 6. Back Click , It will back to monitoring main interface.
- Page 19 If you have problems using the camera, check the following points before you request service. If you still have a problem, please leaving your message at www.hvcam.com directly contact your sales person to get support. Cannot viewing your camera on iPad When camera normal working, the power light blinks green.
- Page 20 Video streaming is slow or has a delay. The speed of login and getting the video feed from the camera highly depends on the speed of the connection you are using The Internet speed either from your Wi-Fi network or 3G/Edge highly infuences the ...
