Wireless Wide Area Network (WWAN)
Getting Started Guide
PLEASE NOTE: This Getting Started Guide is applicable to United States systems only
Congratulations on your purchase of a Fujitsu LIFEBOOK® T901 Tablet PC in Wireless Wide Area Network (WWAN) or
WWAN-ready configuration.
This document first instructs you on how to determine whether there is a WWAN module already installed in your system.
If you not have a WWAN module installed (i.e., your system is "WWAN-ready"), you will learn how to order and install a
module, and (for AT&T customers) how to install and activate a SIM card.
Getting Started
If you haven't already done so, be sure to run the ClickMe! utility to ensure that all applications have
been installed on your system.
ClickMe!
Verifying whether you have a WWAN module installed
Check the icons on your desktop to see if there is an Install WWAN icon present (see the graphic on the
right). If the icon is present, it indicates that your system is WWAN-ready, but there is no WWAN module;
if the icon is not present, it indicates that the WWAN module is already installed.
If you have a WWAN module installed in your system, it is not necessary for you to complete the rest of this procedure;
please proceed to the WWAN Activation flier to connect your device.
If you don't have a WWAN module installed in your system, please continue with the rest of this procedure.
Obtaining a WWAN module for your system
To obtain a WWAN module for your WWAN-ready system, go to the Fujitsu online store at:
http://store.shopfujitsu.com/fpc/Ecommerce/accstore.jsp
O
NLY
ADVISED TO ORDER YOUR
WWAN
THE DEVICE OR YOUR COMPUTER THAT MAY RESULT FROM ITS INSTALLATION
Installing a WWAN module in a WWAN-ready system
If you have a WWAN-ready system, and you would like to install a WWAN module, there are two different things that
could occur when your click the Install WWAN icon.
If you don't have a WWAN module installed yet:
A message will appear stating "This unit is WWAN-ready (upgradable), please shut down the system and then install your
WWAN module and SIM card (if applicable) before continuing".
You want to install a WWAN module at a later date, but you've already run ClickMe!:
The Fujitsu Installer (FjInstaller) will start and allow you to [Select All]. Doing so will install the Gobi driver and Sierra
Wireless AirCard® Watcher™ connection manager. After they are installed, if you launch the Install WWAN icon, FJInstaller
will display Gobi and Sierra Wireless AirCard® Watcher™ as grayed out (already installed).
Note that if you have already installed your WWAN module, and then run ClickMe!, the ClickMe! utility will install the
Gobi and Sierra Wireless AirCard® Watcher™ utilities. Launching FJInstaller will display Gobi and Sierra Wireless AirCard®
Watcher™ as grayed out (already installed).
To install the module, follow the instructions below:
Material Required: WWAN Upgrade Kit - Gobi™3000 Wireless Broadband P/N FPCMDM93AP.
Tools Required: Phillips Screwdriver, #0
Tools Recommended: Tweezers (for attaching cables to antenna posts)
WWAN
MODULES OBTAINED FROM
WWAN
MODULE THAT HAS NOT BEEN AUTHORIZED BY
F
UJITSU ARE FUNCTIONAL ON THIS COMPUTER
F
-
MODULE FROM A
UJITSU
AUTHORIZED SOURCE
F
, F
UJITSU
1
. Y
. I
N THE EVENT YOU INSTALL A
UJITSU ASSUMES NO RESPONSIBILITY FOR DAMAGES TO
.
OU ARE STRONGLY
