- Page 1 HDVS IP CAMERA MD20 & MD50 User Manual...
-
Page 2: Table Of Contents
Table of Contents Overview ..........................3 Features ........................3 Package Contents ....................... 4 Dimensions ........................5 Installation (For Rugged Camera) ................6 Connectors ........................7 Camera Cabling ........................8 Connect Ethernet Cable ..................... 8 Indoor Camera 2.1.1 ..................... 8 Rugged Camera 2.1.2 .................. -
Page 3: Overview
Overview The Full HD Multiple Streams Compact Fixed Dome IP Camera is capable of serving real-time streaming and makes image quality more smoothly. In addition to MJPEG real time streaming, this camera develops H.264 codec to apply for high resolution digital broadcast. With compact and sophisticated mechanical design, the Full HD Multiple Streams Com- pact Fixed Dome IP Camera is easy installed and aesthetic. Features Progressive Scan CMOS Sensor Quad Streams Compression: H.264 Baseline/ Main/ High Profile + MJPEG Multi-language Support ... -
Page 4: Package Contents
Package Contents Please check the package contains the following items listed below. Rubber Washer (×1, Casing) Indoor Camera/ Rubber Washers (×3, Baseplate) Rugged Camera (with Cable) (Rugged Camera only) Plastic Anchors (×3) Self-tapping screws (×3) Quick Guide Security Torx NOTE: The type of the supplied self-tapping screws is mainly for softer substrate/ material installation such as wood. For other installation environment such as cement wall, it is required to pre-drill and use plastic anchors before fastening the supplied self- tapping screw on the wall. -
Page 5: Dimensions
Dimensions The IP Camera’s dimensions are shown below. -
Page 6: Installation (For Rugged Camera)
Installation (For Rugged Camera) For Rugged Camera, we suggest you to install the Camera as the following steps to make sure the Camera is well waterproof. Step 1: Put the Rubber Washers in both sides of the holes on the Bottom Plate of the Camera. Step 2: Aim the installing hole to the target installing posi- tion and fasten the screws to attach the Camera to the ceiling. -
Page 7: Connectors
Connectors The diagram below shows the IP Dome Camera’s reset button and various adjusting screws. Definition for each will be given as follows. Designation Description Restore to default setting; 1 Reset Button press the button with a proper tool 2 Lens Rotate the lens right/left to adjust focus 3 Focus Fixed Screw Loosen the screw to adjust the lens 4 Tilt Fixed Screw Loosen the screw to adjust tilt angle 5 Micro SD Card Slot For video recording storage... -
Page 8: Camera Cabling
Camera Cabling Please follow the instructions below to complete IP Camera connection. Connect Ethernet Cable Please follow the instructions below to connect Indoor/Rugged IP Dome Camera’s Ethernet cable. 2.1.1 Indoor Camera The Ethernet connector, which is located in the rear of the camera, is shown below: PoE Connection Connect the one end of the Ethernet cable to the network port on the camera, and the other end to Power Sourcing Equipment (PSE) like hubs or routers. Check the status of the link indicator and activity indicator LEDs; if the LEDs are unlit, please check the connections. Green Link Light indicates good network connection. Orange Activity Light flashes for network activity indication. -
Page 9: Rugged Camera
2.1.2 Rugged Camera The Rugged IP Dome Camera supports two kinds of Ethernet cable; one is M12 D-Coded Cable, and the other is RJ-45 Dongle Cable. RJ-45 Dongle Cable Connection RJ-45 Dongle RJ-45 Dongle Cable Connection Run the Ethernet cable through the Waterproof RJ-45 Screw-On Plug. Then con- nect one end of the Ethernet cable to the RJ-45 dongle, tightening the sealing nut of the Waterproof RJ-45 Screw-On Plug completely. Later on connect the other end of the Ethernet cable to Power Sourcing Equipment (PSE) like hubs or routers. -
Page 10: System Requirements
System Requirements To perform the IP Camera via web browser, please ensure your PC is in good network connection, and meet system requirements as described below. Items System Requirement 1. Intel Pentium M, 2.16 GHz or ® ® Personal Computer Intel Core 2 Duo, 2.0 GHz ® 2. 2 GB RAM or more Operating System Windows VISTA/ Windows XP/ Windows 7 Web Browser Microsoft Internet Explorer 6.0 or later Firefox Chrome Safari Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation Viewer ActiveX control plug-in for Microsoft IE... -
Page 11: Access Camera
Access Camera For initial access to the IP Camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Device Search Software Setup Step 1: Double click on the program Device Search.exe. After its window appears, click on the <Device Search> button on the top side. Step 2: The security alert window will pop up. Click on <Unblock> to continue. Device Search Step 3: Click on <Device Search> again, and all the finding IP devices will be listed in the page. The IP Camera’s default IP address is: 192.168.0.250. - Page 12 Additionally, users can change the IP Camera’s network property, either DHCP or Static IP, directly in the device finding list. Refer to the following section for changing the IP Camera’s network property. Example of Changing IP Camera’s Network Property Users can directly change an IP Camera’s network property, ex. from static IP to DHCP, in the finding device list. The way to change the IP Camera’s network property is speci- fied below: Step 1: In the finding device list, click on the IP Camera that you would like to change its network property. On the selected item, right click and select “Network Setup.” Meanwhile, record the IP Camera’s MAC address, for future identifica- tion. Step 2: The “Network Setup” page will come out. Select “DHCP,” and press “Apply” button down the page. Step 3: Click on <OK> on the Note of setting change. Wait for one minute to re-search the IP Camera. Step 4: Click on the <Device Search> button to search all the devices. Then select the IP Camera with the correct MAC address. Double click on the IP Camera, and the login window will come out.
- Page 13 The download procedure of DC Viewer software is specified as follows. Step 1: In the DC Viewer installation window, click on <Next> to start installation. Step 2: The status bar will show the installation progress. After the installation is completed, click on <Finish> to exit the installation process. Step 3: Click on <Finish> to close the DC Viewer installation page. Once the DC Viewer is successfully installed, the IP Camera’s Home page will be able to correctly display as the figure below. Viewer Window Main Tabs Languages Selection Time Display Live Video Panel Video Format Selection Web Recording Button Display Mode Video Compression Info Video Streaming Pause Button Snapshot Button Speaker Button Talk Button Image and Focus Adjustment...
-
Page 14: Setup Video Resolution
Setup Video Resolution Users can setup Video Resolution on Video Format page of the user-friendly browser- based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of Video Resolution is as below: H.264- 1920 x 1080 (15 fps) + H.264- 1280 x 720 (30 fps) 2M Real time H.264- 1920 x 1080 (30 fps) + H.264 720 x 480 (30 fps) For more Video Resolution combination detail, please refer to Appendix: Video Resolu- tion. Click on <Save> to confirm the setting. -
Page 15: Configuration Files Export/ Import
Configuration Files Export/ Import To export/ import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera. Export Users can save the system settings by exporting the configuration file (.bin) to a speci- fied location for future use. Click on the <Export> button, and the popup File Download window will come out. Click on <Save> and specify a desired location for saving the configuration file. Upload To copy an existing configuration file to the IP Camera, please first click on <Browse> to select the configuration file, and then click on the <Upload> button for uploading. -
Page 16: Appendix A: Technical Specifications
Appendix A: Technical Specifications Camera 2M Real-time Image Sensor 1/2.7” Progressive CMOS Effective Pixels 1920(H) x 1080(V) Minimum Illumination 0.1 lux (Color) White Balance Manual / AWB / ATW Shutter Speed 1~ 1/10000 sec. Lens Focal Length 4.0 mm F Number F 1.5 78° Operation English / French / German / Italian / Korean / Simplified Chinese / Multiple Languages Traditional Chinese / Russian Backlight Compensation On / Off White Balance Auto / Manual Noise Reduction (3D) On / Off Wide Dynamic Range On / Off Privacy Mask On / Off... - Page 17 Network Interface RJ-45, 10/100 Mbps Ethernet Video Compression H.264 / MJPEG Dual Streams- H.264 + H.264 / MJPEG Video Streaming Quad Streams- H.264 + H.264 + H.264 + H.264/ MJPEG H.264- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF Video Resolution MJPEG- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, Protocol DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF Security HTTPS / IP Filter / IEEE 802.1X Event Notification HTTP / FTP / SMTP Micro SD* microSDHC 32GB support Supported Web Browser Internet Explorer (6.0+) / Chrome / Firefox / Safari User Account Password Levels User and Administrator Mechanical Lens Mounting M12 Board Lens Connectors Ethernet RJ-45 General Operating Temperature -10°C ~ 50°C (14°F ~ 122°F) User and Administrator 10% ~ 90%, No Condensation ∅ 110.2 x 47.7 mm (∅ 4.3 x 1.9 in.)
-
Page 18: Appendix B: Delete The Existing Dc Viewer
Appendix B: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing to the IP Camera. Deleting the DC Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. In the <Currently installed programs> list, select <DCViewer> and click on the button <Remove> to uninstall the existing DC Viewer. -
Page 19: Appendix C: Setup Internet Security
Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>. Step 3: Click on the <Security> tab, and select <Internet> zone. Step 4: Down the page, click on the <Default Level> button and click on <OK> to confirm the setting. Close the browser window, and restart a new one later to access the IP Camera. ActiveX Controls and Plug-ins Settings Step 1: Repeat Steps 1~3 of the previous section above. -
Page 20: Appendix D: Video Resolution
Appendix D: Video Resolution 2M- Quad Streams... -
Page 24: Triple Streams
2M- Triple Streams... -
Page 26: Dual Streams
2M- Dual Streams 2M- Single Streams... -
Page 27: Real Time- Quad Streams
2M Real time- Quad Streams... -
Page 31: Real Time- Triple Streams
2M Real time- Triple Streams... -
Page 33: Real Time- Dual Streams
2M Real time- Dual Streams... -
Page 34: Real Time- Single Stream
2M Real time- Single Stream *1920 x 1080 (30 fps) Low Latency does not support BNC, 3DNR and Motion Detection.
