Centrix MW20IR User Manual

Full hd multiple streams micro bullet ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Full HD Multiple Streams
Micro Bullet IP Camera
User's Manual
Ver. 1.5
001B0JWXZ1A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MW20IR and is the answer not in the manual?

Questions and answers

Related Manuals for Centrix MW20IR

Summary of Contents for Centrix MW20IR

  • Page 1 Full HD Multiple Streams Micro Bullet IP Camera User’s Manual Ver. 1.5 001B0JWXZ1A1...

  • Page 2: Table Of Contents

    Table of Contents Overview ..........................2 Features ........................2 Package Contents ......................3 Dimensions ........................6 All in One Cable ......................8 1. 4 1. 5 microSD Card Slot / Default Button ................10 Camera Cabling .

  • Page 3: Overview

    Overview The Full HD Multiple Streams Micro Bullet IP Camera is a compact camera with an easy setup design. PoE is supported to reduce complicated cabling without sacrificing performance. 3 Megapixel Resolution is available for providing high definition images. Quad Streams Compression (H.264 Baseline / Main / High Profile + MJPEG) are supported for efficient bandwidth and storage management.

  • Page 4: Package Contents

    Package Contents Please check the package contains the following items listed below. Outdoor (without Cable Management) Full HD Multiple Streams Micro Bullet IP Camera Self Tapping Screws Plastic Screw Anchors Desiccant (x5) (x5) Quick Guide (bundled software and documentation)
  • Page 5 Outdoor (with Cable Management) Full HD Multiple Streams Micro Bullet IP Camera Self Tapping Screws Plastic Screw Anchors Desiccant (x5) (x5) Quick Guide (bundled software and documentation)

  • Page 6: Dimensions

    Dimensions Outdoor (without Cable Management)
  • Page 7 Outdoor (with Cable Management)

  • Page 8: All In One Cable

    All in One Cable (Outdoor Models Only) All in One Cable Pin Definition Connector Definition Remarks RJ-45 For Ethernet Cable and PSE connection Power DC Jack DC 12V connectors / Power connection...

  • Page 9: Microsd Card Slot / Default Button

    microSD Card Slot / Default Button The positions of the microSD Card Slot and the Default Button are shown as below. microSD Card Slot Insert the SD Card in the microSD Card Slot to store videos and snapshots. Default Button Press the button with a proper tool to restore the system to default setting.

  • Page 10: Camera Cabling

    Camera Cabling Please follow the instructions below to complete IP Camera connection. Connect Power For power connection, please refer to section 1.4 All in one cable for Outdoor models. Alternatively, users can power the camera by PoE. Refer to the section below to connect the Ethernet Cable for PoE connection.

  • Page 11: System Requirements

    System Requirements To perform the IP Camera via web browser, please ensure the PC is in good network connection, and meet system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or ® Personal Computer Intel Core 2 Duo, 2.0 GHz...

  • Page 12: Access Camera

    Access Camera For initial access to the camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “Device Search” folder in the supplied CD. Access Device Search Software Step 1: Double click on the program Device Search.exe. After its window appeared, click on the <Device Search>...
  • Page 13 Additionally, users can change the network property of the camera to DHCP or Static IP directly in the device finding list. Refer to the following section for changing the camera’s network property. Example of Changing IP Camera’s Network Property- Static IP to DHCP Step 1: In the finding device list, click on the camera which its network property is going to be changed.
  • Page 14 The download procedure of DC Viewer software is specified as follows. Step 1: In the DC Viewer installation window, click on <Next> to start the installation. Step 2: A status bar will be displayed to show the installation progress. After the installation is completed, click on <Finish> to exit the installation process.

  • Page 15: Setup Video Resolution

    Setup Video Resolution Users can setup Video Resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of Video Resolution is as below. H.264- 1920 x 1080 (30 fps) + H.264- 720 x 480 (30 fps) For more Video Resolution combination details, please refer to Appendix D: Video...

  • Page 16: Configuration Files Export / Import

    Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera.
  • Page 17 Camera 2M Real Time 1/2.7” Progressive CMOS Image Sensor Effective Pixels 1920 (H) x 1080 (V) Minimum Illumination White Balance Manual / AWB / ATW Shutter Speed 1 ~ 1/10000 sec. Lens Focal Length 3.6 mm 3.0 ~ 6.0 mm- F 2.0 3.6 mm- F 1.8 F Number 4.0 mm- F 1.5...
  • Page 18 Mechanical Working Distance up to 15 m Built-in IR Wavelength 850 nm Illuminator* Number of LEDs Power Connection PoE / DC Jack* Bracket Cable Management* LED Indicator Power / Link / ACT Indoor DC Jack Power Outdoor DC Jack of All in One Cable* Indoor RJ-45 Connectors...

  • Page 19: Appendix B: Delete The Existing Dc Viewer

    Appendix B: Delete the Existing DC Viewer For users who have installed DC Viewer in the PC previously, please remove the existing DC Viewer before accessing the IP Camera. Deleting the DC Viewer Activate the <Control Panel>, and then double click on <Add or Remove Programs>. In the <Currently installed programs>...

  • Page 20: Appendix C: Setup Internet Security

    Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>. Step 3: Click on the <Security>...

  • Page 21: Appendix D: Video Resolution

    Appendix D: Video Resolution 2M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 352 x 240 (30 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps) 352 x 240 (30 fps) 352 x 240 (30 fps)
  • Page 22 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 800 x 600 (15 fps) 640 x 480 (30 fps) 800 x 600 (30 fps)
  • Page 23 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 1280 x 720 (15 fps) 800 x 600 (30 fps)
  • Page 24 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 640 x 480 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps)

  • Page 25: Triple Streams

    2M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (15 fps) 720 x 480 (15 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps) 1280 x 720 (15 fps) 800 x 600 (15 fps) 1280 x 720 (15 fps)
  • Page 26 H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)

  • Page 27: Dual Streams

    2M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 1280 x 1024 (15 fps) 1280 x 720 (30 fps) 1024 x 768 (30 fps) 1920 x 1080 (15 fps) 800 x 600 (30 fps) √ 720 x 480 (30 fps) √...

  • Page 28: Real Time / 3M / 5M- Quad Streams

    2M Real time / 3M / 5M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (12 fps) 352 x 240 (12 fps) 640 x 480 (12 fps) 720 x 480 (12 fps) 640 x 480 (12 fps) 352 x 240 (12 fps) 2592 x 1944 (12 fps)
  • Page 29 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 1280 x 720 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 800 x 600 (15 fps) 640 x 480 (30 fps) 800 x 600 (30 fps)
  • Page 30 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 1280 x 1024 (15 fps) 800 x 600 (30 fps)
  • Page 31 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 352 x 240 (30 fps) 1280 x 720 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 352 x 240 (30 fps)
  • Page 32 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 720 x 480 (30 fps) 640 x 480 (30 fps) 800 x 600 (30 fps) 352 x 240 (30 fps) 640 x 480 (30 fps)

  • Page 33: Real Time / 3M / 5M- Triple Streams

    2M Real time / 3M / 5M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 720 x 480 (12 fps) 720 x 480 (12 fps) 640 x 480 (12 fps) 2592 x 1944 (12 fps) 352 x 240 (12 fps) 640 x 480 (12 fps) 640 x 480 (12 fps)
  • Page 34 H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 1280 x 1024 (15 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 1280 x 1024 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 1280 x 1024 (15 fps) 1280 x 720 (15 fps)
  • Page 35 H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 640 x 480 (30 fps)

  • Page 36: Real Time / 3M / 5M- Dual Streams

    2M Real time / 3M / 5M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 720 x 480 (12 fps) 2592 x 1944 (12 fps) 640 x 480 (12 fps) 352 x 240 (12 fps) *The resolution is for 5M Model only.

  • Page 37: Real Time / 3M / 5M- Single Stream

    2M Real time / 3M / 5M- Single Stream H.264 Only BNC SUPPORT 2592 x 1944 (12 fps)* 2048 x 1536 (15 fps)** 1920 x 1080 (30 fps) Low Latency*** √ 1920 x 1080 (30 fps) √ 1280 x 1024 (30 fps) √...
