Jiffy 4G Operating Manual/Parts Manual

OPERATING MANUAL/PARTS GUIDE
Thank You for purchasing a Jiffy Ice Drill. When properly maintained
and serviced, we are confident your drill will provide you with many
years of trustworthy performance. This manual contains operating
and safety instructions for the Jiffy Series Power Ice Drill. To receive
the greatest possible performance and satisfaction from your Jiffy
Power Ice Drill, and to reduce the risk of injury, it is important that
you read and understand the assembly, operating, maintenance, and
safety instructions before using your Jiffy Power Ice Drill. Contact
Feldmann Engineering if you do not understand any of the
instructions in this manual.
As with any power tool, safety precautions must be observed with
the Jiffy Power Ice Drill to reduce the risk of personal injury.
Careless or improper use may cause serious injury and/or damage
to your Jiffy Power Ice Drill.
INDEX
General Information ........................................ 1
Warranty......................................... ............. 1
Important Safety Precautions ............................ 2
Pre-Use Procedure ........................... ............. 2
Assembly of Drill............................... ............. 3
Oil Recommendations............................
Fueling............................................ ............. 3
Check Before Starting Your Drill........... ............. 3
Operating Instructions...................................... 3
Maintenance and Adjustments............. ............. 4
Service & Repair Information............... ............. 4
Diagram of Main Parts, Parts List......... ............. 6
Emissions Warranty......................................... 7
MANUFACTURER'S Two Year Limited Warranty
(30 days for Commercial and/or Rental Use)
FOR WARRANTY SERVICE - DO NOT RETURN
YOUR DRILL TO THE RETAILER YOU PURCHASED
IT FROM. CALL THE JIFFY® CUSTOMER SERVICE
NUMBER AT 800-344-0712, MONDAY - FRIDAY
FROM 7:00 A.M. TO 4:30 P.M. CST, FOR A RETURN
AUTHORIZATION NUMBER AND INSTRUCTIONS.
Feldmann Engineering & Manufacturing Co., Inc. warrants the Jiffy
Power Ice Drill to be made of first quality materials and workmanship
and will, at its option, repair or replace any drill part thereof found to
be defective in such materials and workmanship if returned to the
factory, prepaid within two years from the date of purchase by the
original purchaser. To obtain warranty service or replacement
instructions, you must have prior approval before shipping
package. Call our customer service department at 800-344-0712
Monday - Friday from 7:00 a.m. to 4:30 p.m. for a return
authorization number. Inbound and outbound transportation
charges are paid by the purchaser. Feldmann Engineering assumes
no responsibility for damage caused by misuse, careless handling, or
where repairs were made or attempted by an unauthorized person.
For replacement parts, go online to www.jiffyonice.com or to an
authorized Jiffy Dealer. See Jiffy Dealer listing on the website.
PAGE
3
Your Jiffy 4G Drill uses a gasoline-fueled 4-stroke engine:
OIL MUST BE ADDED to engine before ice drill is used for the
first time and must be checked and changed regularly after that
(see page 3).
Your Jiffy 4G Ice Drill must be transported, stored or placed on
the ice with engine spark-plug facing upward, carburetor facing
up, or with powerhead in upright (operating) position. Failure to
do so may result in oil leakage, excessive exhaust smoke or
engine damage.
Manufactured by:
FELDMANN ENGINEERING & MANUFACTURING CO., INC.
520 Forest Avenue Sheboygan Falls WI 53085-2513
E-mail: admin@jiffyonice.com
Other products: TurfVent™ Lawn Aeration Eqt. - www.turfvent.com
-1-
Model #___________________
Purchased at________________
Date Purchased______________
Serial #____________________
Drill Size__________________
Register online at
www.jiffyonice.com
Website: www.jiffyonice.com
BADGER™ Earth Augers - www.badgeraugers.com
Form WM4360 (07/14)
