- Page 1 INSTALLATION & SERVICE MANUAL Reverse Osmosis + DI Water Systems Model: 6-Stage RO+DI system, 100GPD, dual output +tank+faucet Made in U.S.A. www.purenex.com...
-
Page 2: Product Specification
PRODUCT SPECIFICATION 6- Stage Reverse Osmosis + DI Water Purification Systems Model no: RD-100 and RD-106 Capacity: Generates 50 to 100 gallons per day depends on water temperature, pressure, chemistry variations) System includes • RO+DI unit: 6-stage unit, all filters included. -
Page 3: Installation Kit
Thank you for choosing Watergeneral Reverse Osmosis Water Systems. You now own a superb Reverse Osmosis (RO) + Deionization (DI) system that effectively reducing most contaminants, organic and inorganic compound, unwanted taste and odor from tap water. It is designed to transform your tap water into distill water. Read carefully and follow the instruction in this manual before proceeding with actual installation. - Page 4 ASSEMBLY QUICK VIEW (RD-106, follow the photo below, for RD -100 filters are already installed) Carbon Carbon Sediment 1. Put upper portion of the unit on top of the filter housing 2. Screw on the filter housing vertically to the filter housing cap 1.
- Page 5 4 connections Color tubing Feed water Orange valve or Red DI water Blue dispensing valve Drain saddle Black valve Model: RD-100 4 connections Color tubing Feed water Orange valve or Red Drain saddle Blue valve Tank ball Black valve Dispensing...
- Page 6 INSTALLATION (for under-the-sink installation) STEP 1: TAPPING INTO COLD WATER SUPPLY CAUTION: • The water supply to your RO unit MUST be from COLD water line . Hot water will damage your RO system. Locate cold water shut off valve under the sink and turn it off. Open cold-water faucet to release the pressure, and make sure there is no water.
-
Page 7: Step 2: Installing The Dispensing Faucet
STEP 2: INSTALLING THE DISPENSING FAUCET 1. faucet base The faucet should be positioned with aesthetics, function 2. small washer+ and convenience in mind. An ample flat surface is chrome plate required for the faucet base so that it can be drawn down 3. - Page 8 STEP 3: MOUNTING THE TANK BALL VALVE (for RD-106 only) Do not release air from the air valve on the lower side of the storage tank. It has pre-charged at 7-10psi at the factory. the tank can be positioned screw on ball valve tight, push tubing through laying down or standing upright put Teflon tape, 6-8 turns the nut, put tube insert, screw on the nut...
-
Page 9: Step 5: System Start-Up
7. Turn the RO faucet lever to OFF. Now the purified water will start going into the storage tank. (for RD-106) 8. Wait 3 hours for the storage tank to be filled up. 9. DO NOT DRINK THE FIRST BATCH OF WATER PRODUCED BY THE SYSTEM. For RD-100 let pure water drain out for about 1 gallon 10. - Page 10 Changing Filters Procedures • Shut off the system by turning off the water supply, and turn off the tank valve, open the spigot to depressurize • Prepare a towel under the unit for water spills • Use a filter wrench (part no. 566, not supplied with the unit) or use hands to open the filter housing, unscrew it from right to left.
-
Page 11: Troubleshooting
TROUBLE SHOOTING NOTE: Turn off the system before servicing. Installation Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION No or low water production 1. Feed water valve in not turn on 1. Turn on feed water valve 2. Tank valve is not turn on 2. -
Page 12: Limited One-Year Warranty
RECHARGING TANK PROCEDURE PROBLEMS : • When you turn on the spigot you get small water pressure and water flow. • When you turn on the spigot, only a quick burst of water comes out of the system, then it dies down to trickles. •...
