Hase Spezialräder Pino User Manual

Hide thumbs Also See for Pino:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Owner`s
manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pino and is the answer not in the manual?

Questions and answers

Related Manuals for Hase Spezialräder Pino

Summary of Contents for Hase Spezialräder Pino

  • Page 1 Owner`s manual...

  • Page 2: Table Of Contents

    PINO Contens H A S E S P E Z I A L R Ä D E R Delivery: General warning page 4 On receipt of delivery page 5 Items supplied page 5 Assembly page 6-7 Ergonomic adjustments: ength page 8...
  • Page 3 With these instructions we offer you assistance in ensuring the Pino remains fun and safe to use over a long period of time. The Pino is the result of many years of development work. But as with any product, it is important that it is continually improved. We are therefore interested in your experiences from normal daily use and from cycling holidays/tours.

  • Page 4: General Warning

    On the Pino the rider should wear clothing that is close-fitting enough to make it impossible for garments to get caught in the wheel or the drive.

  • Page 5: On Receipt Of Delivery

    Waltrop Germany to the recipient. The parcel service is liable in case of damage. Items supplied: For better handling during shipping, we took a few parts off the Pino and split it in two boxes. Please check the contents of both boxes.

  • Page 6: Assembly

    PINO Assembly H A S E S P E Z I A L R Ä D E R Slide bearing foil Mark for maximum length Plug Quick release Insert frontboom At first connect both light-cables then insert the frontboom without twisting the chain.
  • Page 7 PINO Assembly H A S E S P E Z I A L R Ä D E R Put on the seat Slide one side of the seat on the seat mount of the frame, then pull the opposite seat tube away from the frame until you can slide it on the seat mount.

  • Page 8: L Ength

    PINO Length H A S E H A S E S P E Z I A L R Ä D E R S P E Z I A L R Ä D E R Quick release Adjusting screw chain tensioner For length adjustment open the adjusting screw at the chain tensioner.

  • Page 9: Steering

    PINO Steering H A S E H A S E Handlebar S P E Z I A L R Ä D E R S P E Z I A L R Ä D E R Screw D Screw A und B...

  • Page 10: Seat Angle

    PINO Seat angel H A S E H A S E S P E Z I A L R Ä D E R S P E Z I A L R Ä D E R Quick release For adjusting the seat angle, open the quick release and move the seat up or down..

  • Page 11: Safety, Health

    Always cycle with lights from dusk til dawn. Carrying luggage: If you ‘re planning a long journey with the Pino and intend taking a lot of luggage, we recomend the use of a Hase lowrider luggage rack in addition to the rear bike rack.

  • Page 12: Frame-No

    S P E Z I A L R Ä D E R Frame number The frame number of your Pino is stamped into the left rear dropout.. Make a note of the frame number and kep it somewhere safe. Page 12...

  • Page 13: Chain

    S P E Z I A L R Ä D E R Renewing the chain: The Pino has a relatively long chain, which means it has a longer service life. Thus the chain need not be renewed so often compared with normal bicycles.

  • Page 14: Brake Adjustment

    PINO Brake adjustment H A S E S P E Z I A L R Ä D E R For adjusting, service and all works on the brake, read the brake manufacture’s instructions - “Magura Workshop 2002” or “Magura Workshop 2003”.
  • Page 15 Whats special on Magura’s Julie andem version: On your Pino you find the tandem version of Magura’s Julie. It is an extra powerful version with some special features. For servicing or working on the brake, keep some points in mind: Allways use the original Magura steelflex tubes only.

  • Page 16: Gear Adjustment

    PINO Gear adjustment H A S E S P E Z I A L R Ä D E R Adjusting lowest gear -Select 9th gear on the right-hand shifter. The chain should be on the smallest sprocket. -Turn the crank via the pedal. If the chain already...

  • Page 17: Trouble Shooting

    PINO Gear adjustment H A S E S P E Z I A L R Ä D E R Trouble shooting Problem Cause Remedy CHANGING GEAR Chain slips o ff smal lest -Adjusting screw H is Turn screw H clockwise sprocket onto frame.

  • Page 18: Gear Adjustment

    PINO Gear adjustment H A S E S P E Z I A L R Ä D E R Adjusting the front derailleur: If you need to adjust the front Chainring derailleur work like followed: Outer chain guide plate When carrying out adjustment, set the chain to the largest chainring.

  • Page 19: Spokes

    If you aligne the wheel in a work stand, keep in mind that the wheel has to be aligned 2,5mm to the left (discbrake). The Pino is build asymmetric to get the same spoke angle on both sides. This will result in a stronger wheel.

  • Page 20: Removing Handlebar

    PINO Removing handlebar H A S E S P E Z I A L R Ä D E R Removing handlebar, change headset Handelbar skrew1 Handlebar skrew2 Excenter clamp screw Headset adjusting nut Excenter for steering rod Lock nut Remove handlebar screw 1 and 2.
  • Page 21 PINO Removing handlebar H A S E S P E Z I A L R Ä D E R Steerer tube head Bearing race Needle bearing Bearing race Upper cup Head tube Top tube Lower cup Bearing race NEEDLE BEARING...
  • Page 22 S P E Z I A L R Ä D E R On the next side you will find a technical drawing of the bottom bracket. The Pino has a drive-train on both sides. Taking off the crank requires an ordinary crank puller. Disassembling the bottom bracket: Due to the on the left side mounted freewheel, the bb axle can be removed to the right only.

  • Page 23: Removing Botom Bracket

    PINO Removing bottom bracket H A S E S P E Z I A L R Ä D E R Chain guard Spiderarm ( Mounting diameter 110 mm) Chainring Counter sunk bolt C-clip Selflocking nut Freewheel Right bb-cup (Lefthand thread)

  • Page 24: Steering Rod

    Steering rod Self locking nut Self locking nut When the Pino leaves our workshop, the steering rod length is pre adjusted. If you have to change or readjust the steering rod length, watch the following steps. Open the self locking nut of either the front or rear joint and remove the screw.

  • Page 25: Rohloff Hub

    For mounting the Rohloff Speedhub with 14-gears, no separate torque arm will be needed. The Pino is build with an extra long dropout to cope with the torque from the Rohloff Speedhub. This gives you the opportunity for an easy upgrade any time you want.

  • Page 26: Technical Data

    PINO Technical data H A S E S P E Z I A L R Ä D E R Total length: 110 - 2370 cm Total width: from 65 cm Total height: from 100 cm Seat height front position: Weight:...

  • Page 27: Warranty

    Packages sent to us must always have the correct postage or we cannot accept them. The weight on the Pino (rider and luggage) must not exceed 225kg. If the Kettwiesel is used in competition, on rough terrain or placed under similar stress, the statutory and additional warranty become void.
  • Page 28 A S E Hiberniastr.2- 45731 Waltrop Hiberniastr.2- 45731 Waltrop Tel.:++49 (0) 2309 782582 Tel.:++49 (0) 2309 782582 S P E Z I A L R Ä D E R Fax:++49 (0) 2309 782586 Fax:++49 (0) 2309 782586 www.hasebikes.com www.hasebikes.com Infotasche: Auf vielfachen Wunsch unserer Kunden ist Sie endlich da: Die Infotasche mit Post- karten für interessierte “noch Fußgänger”.
