Pixel ROOK Instruction Manual

Instruction Manual
ROOK
Professional Flash Trigger Professional Flash Trigger
Receiver Receiver
1
2
5
3
7
4
6
Indicator Shutter release/test Power/group Output socket
1 2 3 4
button
Light switch
5 Battery 6 Hot shoe foot with 7 Chanel setting
compartment screw
Transmitter Transmitter
1
2
6
3
4
8
5
7
Shutter release/test
Indicator Group Indicate Power/group setting
1 2 3 4
Light button Light
Input/output Battery Trigger point Chanel setting
5 6 7 8
socket compartment
for Olympus/
for Sony
for Canon for Nikon
Panasonic
Compatible
ROOK Model compatible list as below：
Transmitter(TX) Receiver(RX)
Model
For Canon Canon series camera
Nikon series camera, Samsung series camera
For Nikon
Qriginal speedlite,
Fujifilm series camera, Pantex series camera
studio light,Metz,
For Sony
Sony series camera, Minolta series camera SUNPAK,Sigma
for Olympus/
Olympus/Panasonic series camera
Panasonic
Above brand name is registered by the respective owner.

Overview

Thank you so much for purchasing PIXEL product, ROOK is a professional
grouping flash trigger. TTL mode available on transmitter hot shoe and sync with off
shoe trigger together. Off shoe trigger can be grouped the flash and Remote the
camera. ROOK is using global free FSK 2.4GHz which is more stabilize.

Cautions before use

1、
Make sure the camera is powered off before install device.
2、
;
This is electronic products accessories some of the environment causes may
.
affect the working However this is hardly ever to get this situation
3、
This component can't be strong vibration, or may lead to product failure.
4、
For a long time non-use, please turned off the transmitter and the receiver's
power and remove the battery.
5、 ;
The batteries should not install anti-polarity otherwise the batteries may leak
corrosive liquids, heat or explosion.
6、
When the product connected to the device, Do not pull the wires.
7、
Do not put it in high temperature, such as a closed car under direct sunlight, the
- .
control panel and other high temperature areas
8、
keep dry, do not use wet hand contact with the product, the product must not be
immersed in water or exposed to rain, and this may lead to not work properly.
9、
Do not use flammable gases in violation of this warning may cause an explosion
or fire.
10 、
Because of this product is included battery ; please strictly follow the instruction
.
for operation Otherwise its may cause an explosion, fire or personal injury.

Feature

1 ROOK is a professional grouping flash trigger. 、
2 Transmitter hot shoe support TTL and sync with off shoe flash. 、
3 Wake-up function available, the flash will be wake up automatically. 、
4 Through studio light to connect PC or USB socket, the sync speed up to 1/320s 、
(Sync time may have little bit inacurracy as difference camera model )
5 Available to control the shooting or through master camera to control 、
slave camera.
1

Specification

Wireless Frequency System: FSK2.4GHz
Operating Distance: up to 200m
Shutter Sync Speed: 1/200S

Group setting:

3 difference group (7 combinations)
Wireless Channel: 4
Stand-by Time Receiver 250 hours
： :
Transmitter: 5years
Power : AAA x2
Transmitter 48.5g (without batter y)
Weight:
Receiver 44.0g (without batter y)
Included Items
Please check the package and make sure the below items are
already in the box. If there's missed anything, please contact with the
distributor directly.
ROOK 1 pc
Transmitter
ROOK Receiver 1pc
1 pc
Studio light cable (3.5-3.5)
Studio light cable(3.5-1/2) 1pc
Receiver holder: 1pc
Hot shoe protector: 2pc
Manual: 1pc
Hot shoe protector Receiver holder
2
Prepare to use

Battery Installation:

Set transmitter and receiver to the same channel
Please locate the battery according
-
to the icon in the battery compartment.
, ' !
don t worry
Turn power on/off:
Transmitter: Transmitter:
.
Hold [ ] 2 seconds to turn on transmitter, then group LED light on
for 2 seconds, and show which current light. It can be used trigger the
flash and control shutter. You could turn off power by pressing [
2 seconds again, then [LED light] blink red three times.Then power off.
Receiver: Receiver:
Switch [Power/group switch] to A or B or C to turn on receiver
(Turn
power; the receiver will be stayed in the current group and the
power on)
LED light blink as red every 2 seconds.
(Turn Switch [Power/group switch] to OFF; the receiver power is off,
power off)
and the light stop blinking.
For a long time non-use, please turned off the transmitter and the receiver's
power and remove the battery.

Channel Setting:

Set transmitter and receiver to the
same channel
1.Slide the switch to change channel.
2. Channel changing as:
CH1→ CH2→ CH3→CH4 (as figure)
3
* Transmitter and receiver must be set as the same channel.
CH 1 CH 1
Transmitter Receiver Transmitter
Group setting:
Group setting on transmitter
1.wake up group display, and show the current controlling group. Slightly press
[ ] to show group mode which showing the current working group.
2. Press again [ ] to change group.
3. Group changin g a s :
A、 B、 C → A 、 B → A 、 C → B 、 C →
A
4. No action within 2 seconds, the group LED light will off.
* A、B、C LED light on means the current setting will be working with
transmitter.
Group setting on receiver
Put Power/group switch at A/B/C,
and then turn on the receivers.
*Receiver only get signal from transmitter when the current group
setting of receiver is included in the validate group of transmitter.
Testing:
1. Check power on or off.
2. Check the frequency of transmitter and receiver.
3. Check the group setting of transmitter and receiver.
4
Testing the receiver signal as below:
1.Insert flashgun on the receiver and turn on the flash power; set the flash
index as minimum.
2.Full press the test button
3.Trigger the Flash.

How to connect the relative photo equipment

1. Tight the Hot shoe with screw, and then turn right to
]
release.
2. Plug the transmitter on the camera hot shoe.
3. Tight the Hot shoe with screw, and then turn
left to lock.

Connect the transmitter to camera hot shoe

（ Transmitter ）
1. Plug PC-3.5 connecting cable to transmitter 3.5mm socket.
CH 2
CH 1
2. Plug PC-3.5 connecting cable to camera PC socket.
Connect transmitter to camera via PC-3.5 connecting cable.
CH 4 CH 3
*PC-3.5 connecting cable should be purchased separately.
5
1. Split the protecting film on the receiver holder and stick it on
the studio light as figure.
2. Mount the receiver on the receiver holder.
3. Use 3.5-3.5 or 3.5-1/2 according to studio light socket.
CH 1 CH 3
4. Plug 3.5mm side into the transmitter input.
Receiver
5.Insert another side into the studio light socket.

Connect the Receiver to Studio Light

→ → → A、 B、 C
B C
1. Unlock the Speedlite Flash locking screw.
2. Insert the Speedlite Flash into the receiver hot shoe
1 3
as figure.
3. According to the flash locking method to lock the
2
speedlite on receiver.

Connect the Receiver to Speedlite Flash

(1
receiver socket.
the camera shutter release
socket

Connect Receiver to Camera

*The shutter cable should be purchased separately.
6
(1 (2
7
(2
1.Plug shutter connecting
cable (3.5mm side) into the
2.Plug shutter connecting
( )
cable camera side into
.
8
