Sumo SML34GEN Safety And Operating Manual

780w 2 stroke generator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SML34GEN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sumo SML34GEN

Summary of Contents for Sumo SML34GEN

  • Page 2 SML34GEN 780w 2 STROKE GENERATOR SAFETY AND OPERATING MANUAL...
  • Page 3 GUARANTEE This Sumo product carries a guarantee of 12 months. If your product develops a fault within this period, you should, in the first instance contact the retailer where the item was purchased.

  • Page 4: Safety Instructions

    PLEASE NOTE: The generator supplied is NOT suitable for providing power to any electronic products such as computers, laptops or televisions etc. If in doubt please refer to the specific product manual for advice on supply connection. If using for a caravan, motor home or boat etc refer to the manufacturers manual regarding connection of a generator.
  • Page 5 5) Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 780w 2 STROKE GENERATOR SML34GEN...
  • Page 6 ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR GENERATOR Electrical generators must always be grounded, (connected to earth). Petrol or diesel powered generators must never be used in an unventilated closed spaces.The exhaust fumes are highly dangerous and can cause “Carbon Monoxide Poisoning” which will cause drowsiness and death.
  • Page 7 Before transporting the generator in a vehicle, drain all fuel to prevent leakage. To prevent an electric shock and fire, never connect an electrical load with the electrical output switched on. Do not connect the generator to any other electrical source. 780w 2 STROKE GENERATOR SML34GEN...
  • Page 8 The engine speed has been factory set to provide safe operation.Tampering with the engine speed adjustment could result in overheating of attachments and could cause a fire. Never attempt to “speed- up” the engine to obtain more performance. Both the output voltage and frequency will be thrown out of standard by this practice, endangering attachments and the user.
  • Page 9 4. Recoil starter 5. Engine on-off switch 6. Choke lever 7. Ail filter housing 8. AC socket 9. Reset button 10. Exhaust 11. Engine 12. DC socket 13. DC charger leads 14. Spark plug wrench 780w 2 STROKE GENERATOR SML34GEN...

  • Page 10: Technical Data

    TECHNICAL DATA AC output 230Vac ~ 50Hz Rated power 0.65kVA Peak power 0.78KvA Phase Single Power factor cosø=1 Displacement 63cc DC output 12V, 8.3A Motor 1.8HP, 2 stroke Fuel tank capacity 4.2L Fuel type 50:1 or 40:1 of unleaded petrol and two stroke oil Spark plug type F5TC NOISE DATA...

  • Page 11: Operation Instructions

    Spike is pushed into the ground by at least 100mm so that it is firm and a litre of water poured around it to ensure good Earth continuity. 780w 2 STROKE GENERATOR SML34GEN...

  • Page 12: Fuel Mixing

    3. FUELING The generator is powered by a two-stroke engine, 1L : 0.02L which uses a petrol oil mix fuel.The correct fuel mixture is a ratio of either 50:1 or 40:1 of petrol and two stroke oil (depending on the ambient temperature) i.e.
  • Page 13 Continue this procedure until the engine starts. When the engine has been successfully started and is Fig 7 running smoothly return the choke lever to the OFF position (See fig 10). Fig 8 Fig 9 Fig 10 780w 2 STROKE GENERATOR SML34GEN...

  • Page 14: Overload Protection

    5. STOPPING THE GENERATOR ENGINE Before stopping the engine, switch off all the electrical loads and turn the generator ON/OFF switch to the OFF position (See fig 11). Before stopping the engine make sure that all the electrical loads are disconnected from the generator AC outlet socket.
  • Page 15 Plug the 12v charger lead into the socket on the generator (Fig 16). The specific gravity for the fully charged battery shall be within 1.26 to 1.28. It is advisable to check the specific gravity every hour. Fig 15 Fig 16 780w 2 STROKE GENERATOR SML34GEN...

  • Page 16: Maintenance

    MAINTENANCE Spark plug After every 50 hours of running the spark plug should be removed. Check the colour of the deposits on the end of the spark plug (Fig.17), it should be a “Tan” colour. Remove all deposits using a stiff brush a brass wire brush is ideal.

  • Page 17: Maintenance Schedule

    Carburetor Check choke operation Cooling Check fan damage system Starting Check recoil starter system operation Decarbon- More frequently isation if necessary Fittings/ Check all fittings and fixtures Fastenings and tighten if required 780w 2 STROKE GENERATOR SML34GEN...

  • Page 18: Engine Troubleshooting

    ENGINE TROUBLE SHOOTING CONDITION PROBABLE CAUSE CORRECTIVE ACTION Loose spark plug Tighten plug Insufficient Loose cylinder head Tighten bolt compression bolt Damaged gasket Replace gasket FUEL SYSTEM PROBLEMS Insufficient pulling Pull rope sharply speed for starting rope Foreign matter in Clean tank No fuel supplied to fuel tank...

  • Page 19: Generator Trouble Shooting

    Locate and tighten Internal generator Consult dealer problem SPARES HELPLINE 01302 721791 ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. For further information visit www.recycle-more.co.uk 780w 2 STROKE GENERATOR SML34GEN...

  • Page 20: Declaration Of Conformity

    We, Importer Powersmith Ltd. BA22 8RT Declare that the product 780W Generator SML34GEN Complies with the essential health and safety requirements of the following directives: 89/336/EEC - EMC Directive. 2006/95/EC - Low Voltage Directive. 98/37/EEC - Machinery Directive. 2000/14/EC - Noise Directive.
