  • Page 1: Programming Guide

    INSTALLATION AND PROGRAMMING GUIDE HARDWIRED CONTROL PANEL Scantronic...
  • Page 2 Every effort has been made to ensure that the contents of this book are correct, errors and omissions excepted. However, neither the authors nor Cooper Security Limited accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this book. The contents of this book are subject to change without notice.

  • Page 3: Table Of Contents

    Contents Contents 1. INTRODUCTION ..................1 Operator Controls and Displays - 9930 ..................3 Operator Controls and Displays - 9925 ..................4 System Features ..........................5 Detectors ..............................5 9755 Hardwired Expander ......................... 5 9955 Radio Expander ..........................5 User Control ............................... 6 2.
  • Page 4 Contents 4. Programming ..................29 Entering Programming Mode ...................... 29 Programming Commands ......................29 Communications Programming ........................ 34 Leaving Programming Mode ........................36 Engineer Reset ............................36 Re-entering Programming Mode ......................36 Restoring the Access Codes (1st stage reset) ..................36 Restoring All Factory Default Programming .....................
  • Page 5 Contents Access Mode (Command 114) ......................52 Communicator Telephone Numbers (Command 115/116) ..............52 Account Number (Command 117) ....................53 Downloader Telephone Numbers (Commands 118/119) ..............53 Fast Format Channels (Command 121) ....................54 Report Restorals (Command 123) ......................54 Country Defaults (Command 126) ......................
  • Page 6 Contents 496478...

  • Page 7: Introduction

    1. Introduction 1. INTRODUCTION The 9750 is designed to be fully programmable to suit individual site require- ments and user needs. The system comprises a control unit in a metal case, up to four separate keypads and one keyswitch interfaces (see Figure 1 on the next page). You should always fit at least one keypad.
  • Page 8 715rEUR 725rEUR Wire free PIR Telecommand 726rEUR detector 735rEUR 9955 Universal transmitter 719rEUR Smoke detector Keypads Wired 9855 Detectors Keypads Control Unit Keyswitch PIRs Door contacts Fused mains spur Figure 1. 9750 System Layout 496478...

  • Page 9: Operator Controls And Displays - 9930

    1. Introduction Operator Controls and Displays - 9930 Figure 2. 9930 Remote Keypad. The 9930 keypad has a single line 16 character LCD display that shows first to alarm information, level status, and programming commands. In addition there are three LEDs with the following functions: Glows steadily when mains power is present.

  • Page 10: Operator Controls And Displays - 9925

    1. Introduction Operator Controls and Displays - 9925 Figure 3. 9925 Arming Station. The 9925 arming station is intended for use solely in setting and unsetting the system. The 9925 has the following LEDs: Glows steadily when mains power is present. Flashes when the system is working from battery backup.

  • Page 11: System Features

    1. Introduction System Features Detectors The control unit provides connections for up to eight separate detector zones. Each zone can be connected as a four-wire closed circuit loop (CCL). See "4. Programming - Programming Commands" for the factory default settings and instructions on how to change the zone types and attributes. 9755 Hardwired Expander The 9755 expander provides an extra eight CCL zones to give a total of 16 zones.

  • Page 12: User Control

    1. Introduction User Control The control unit provides eight independent user access codes and a sepa- rate Duress code. The user can change these codes at any time, but cannot program the system with these codes. The user can set the system in the following modes: Full Set All the zones function as programmed during installation.

  • Page 13: Technical Description

    2. Technical Description 2. Technical Description Specification Operating temperature = -10° to +55°C Humidity = 96% RH Dimensions = 243mm W, 234mm H, 87mm D Weight = 2.45 kg (without stand-by battery) Conforms to EN50131-1 Grade 1 and current BS4737 Part 1 for remote signalled systems, ACPO-IAS Policy, NACOSS NACP14, ABI log require- ments.

  • Page 14: Control Unit Pcb And Case

    2. Technical Description Control Unit PCB and Case Figure 4 shows the layout of the control unit PCB. AC from transformer 12V Aux fuse Outputs Battery fuse Battery connector Aux Power Reset pins Connector for Tamper switch Plug-by communicator Zones Telephone line for built-in communicator...

  • Page 15: 9755 Expander

    2. Technical Description 9755 Expander The 9755 Expander provides connectors for eight four-wire CC loop zones. Figure 5 shows the layout of the PCB. Zone CCT9 Keypad bus Connectors CCT10 CCT11 CCT12 DATA Spare CCT13 Lid Tamper Connectors switch CCT14 CCT15 CCT16 Spare...

  • Page 16: Compatible Equipment

    2. Technical Description Compatible Equipment 715rEUR-00 Radio PIR. 719rEUR-00 Radio Smoke Detector. 725rEUR-00 Radio Remote Setting Device. 726rEUR-00 Radio PA. 735rEUR-00 Universal Transmitter. 746rEUR-00 868MHz Test transmitter. 747rEUR-00 868MHz Go/No Go test receiver. 9925EUR-00 Arming Station. 9928EUR-00 Keyswitch interface. 9930EUR-00 LCD Keypad.

  • Page 17: Installation

    3. Installation 3. INSTALLATION Note: The following instructions assume that you have already run the necessary cabling. Caution: Always remove mains power before opening the case lid. Do not work inside the control unit with mains power present. Fitting the System Fitting the Control unit Case Remove the control unit case from the packing.

  • Page 18: Fitting A 9930 Lcd Keypad

    3. Installation 6). Make sure that the bottom left corner of the PCB is seated on its support pillar. Fitting a 9930 LCD Keypad The backplate of the 9930 LCD keypad contains an adjustable cam that you can use to make sure the tamper switch will operate correctly when the keypad is mounted on an uneven surface.

  • Page 19: Fitting A Remote 9925 Arming Station

    3. Installation Mount the front of the keypad (containing the keypad pcb) onto the backplate and make sure that the tamper switch operates. If the tamper switch does not operate then rotate the cam until the tamper switch operates correctly when the front of the keypad is mounted on the backplate.

  • Page 20: Wiring The Control Unit

    3. Installation Wiring the Control Unit Cable Entries The control unit case back provides several cable entries. The back is designed to stand away from the wall to leave space for cables. Mains Connection The control unit must be permanently connected to a spur outlet fitted with a readily accessible disconnect device.

  • Page 21: Remote Keypads

    Remote Keypads Keypad Addressing The 9750 control unit is supplied with one remote keypad. If you have fitted more keypads then each one must be given a separate "address". Links LK2 to LK4 set the keypad address, as shown in Figure 10.

  • Page 22: Connecting Keypads

    -ve Tamper Return +ve Hold Off -ve Apply trig 12V AUX 12V AUX 9930 Keypad 0V12V CLK DATA ET 0V 12V CLK DATA 4-core To other keypads Exit terminate button (NO, push to make) Figure 11. 9750 Keypad and Sounder Connections 496478...

  • Page 23: Detector Circuit Connections

    "A/T".The control panel provides enough connectors for eight four wire circuits. If you wish to connect 16 four wire circuits you must fit a 9755 hardwired expander card (see "Connecting a 9755 Expander"). 9750 9755 Tamper Contacts (in series) Zone 09...

  • Page 24: Using Programmable Outputs

    3. Installation Using Programmable Outputs OP1, 2 and 3 are "pull down type" outputs that provide negative applied control signals. The system adjusts the output polarity when you select the output type. Use programming command 81 for OP1, command 82 for OP2 and command 83 for OP3 (see "4.

  • Page 25: Wiring Keyswitches

    3. Installation Wiring Keyswitches Figure 15 shows the connections for a 9928 Keyswitch Interface. Note: You can fit only one keyswitch interface per system. Momentary or Continuous Keyswitches The 9928 keyswitch interface can be connected to either momentary or continuous keyswitches, see Figure 15. When using a momentary keyswitch remove the jumper from link M/C.

  • Page 26: Installing A Communicator

    Note: Ideally, no other equipment should be connected to an exclusive line. Three Way Calling The 9750 also provides a Three Way Calling facility to make sure the built in communicator can always use a shared telephone line. To use this facility, the local exchange must provide the Three Way Calling service on the customer's line.

  • Page 27: Statutory Information

    3. Installation If either of these functions detect a failure the system gives a programmable Line Fault Response (programming command 106). Statutory Information Application The built in communicator is suitable for connection to the following type of networks: (a) Direct exchange lines (PSTN) supporting DTMF (tone) dialling. (b) PABX exchanges (with or without secondary proceed indication).

  • Page 28: Ren

    S.E.L.V. cct CCT2 Main Connector S.E.L.V. cct CCT3 CCT4 CCT5 CCT6 CCT7 Telephone Line CCT8 Connections T.N.V. cct. 0V 12V CLK DATA RJ11 Connector T.N.V. cct. Keypad Connector S.E.L.V. cct Figure 16. SELV and TNV Connectors on the 9750 496478...

  • Page 29: Connecting The Telephone Line

    Using a three core cable (type 1/05mm CW1308), strip back 5mm of two cores and feed through one of the cable entries in the rear of the 9750 casing. Connect the two cores to the terminals, A and B on the built communicator.

  • Page 30: Fitting A Plug-By Communicator

    Figure 17. Connecting the Built In Communicator Fitting a Plug-by Communicator The 9750 can be fitted with a communicator or speech dialler (for example the Scantronic 8400, 8440, 660 or RedCare STU). To fit a communicator, follow the instructions below.
  • Page 31 3. Installation Figure 18. Fitting a Plug ByCommunicator Make any necessary connections from the communicator to the Comms Wiring Harness. Figure 19 shows the outputs available on the free ends of the Comms Wiring Harness. 1 (Brown) Fire. -ve applied (+ve removed) in alarm 2 (Orange) PA.

  • Page 32: Fitting A Battery

    3. Installation If the system has already been installed: Re-connect the battery. Fit the case lid (don't forget to attach the earth lead from the case to the left hand support pillar). Apply mains power. 10. Test communicator operation. Fitting a Battery Fit a rechargeable battery into the back of the case.

  • Page 33: Initial Start Up

    3. Installation Initial Start Up Before applying power to the control unit, ensure that any remote keypad(s) have been addressed, and expanders, zone circuits and sounders are connected. Connect the battery to the control unit PCB. The green power LED flashes and the internal sounder may sound. Ignore any other display at this stage.
  • Page 34 3. Installation 496478...

  • Page 35: Programming

    1. The factory default Access Codes 02 to 08 and the Duress Code must be changed by USER 1 to a four digit number to activate them. See “9750 User Guide” for a more detailed explanation of changing user access codes.
  • Page 36 4. Programming To change: Key-in: Notes Default Zone nn nn = zone number 01 to 16 (Note: for zones 1 to 9 key a = Zone type, one of: in “01” to “09”.) 0 = NU (not used) Z01 =FEb 1 = PA (panic alarm) Z02=ERb 2 = FR (fire zone)
  • Page 37 4. Programming To change: Key-in: Notes Default System Reset 0 Eng reset off 1 Eng reset on PA Reset 0 PA cust reset 1 PA eng reset First circuit lockout 0 Lock out on 1 Re-arm Alarm Abort 0 Abort off 1 Abort on Day tamper comms 0 Day Tamper off...
  • Page 38 4. Programming To change: Key-in: Notes Default Level A Exit Time 1 10 Seconds 2 20 seconds 3 30 seconds 4 45 seconds 5 60 seconds 6 120 seconds Entry/Exit Volume 0 No Entry/Exit tones from Loudspeaker n EE tone volume from LS (1=low, 9=max) CSID Code n..n Seed code for remote reset none...
  • Page 39 4. Programming To change: Key-in: Notes Default Output 1 Type, one of 0 Bell 1 EE follow 2 Armed lamp 3 Set latch 4 Shock sensor reset 5 Walk test 6 Ready lamp 7 24 hour alarm 8 Strobe 9 Smoke sensor reset Output 2 Type, one of 0 Bell 1 EE follow...

  • Page 40: Communications Programming

    1 Dynamic on Three way calling (UK) 0 Three way off 1 Three way on Download Mode Remote (No other option available on 9750) Rings to answer 0 3 rings Downloading option 1 5 rings 2 7 rings 3 10 rings...
  • Page 41 4. Programming To change: Key-in: Notes Default Downloader Tel No 1 Maximum 31 digits Downloader Tel No 2 Maximum 31 digits Fast Format channels For built in Communicator a is the channel number 1 to 8 b is one of the following: 0 Not Used 1 Fire 2 PA...

  • Page 42: Leaving Programming Mode

    4. Programming Leaving Programming Mode When all programming has been completed: Key-in ‘99 Y’ at the keypad 99:Exit Eng ? The display shows: Press Y. 99:Checking Sys The display shows: followed by the time and date. The system is now in user mode. Note: If there is a fault on the system , for example an open tamper circuit, the display shows this and will not return to Day mode.

  • Page 43: Restoring All Factory Default Programming

    4. Programming Restoring All Factory Default Programming If you wish to restore all factory default options then: Enter programming mode (if you are not already there). Key in 98 Y at the keypad. 98:Load Default The display shows: Press 1. (You can press X to stop the procedure if you change your mind at this stage.) Press Y.

  • Page 44: Zone Attributes

    4. Programming alarms operate whether the system is set or unset and cannot be omitted, and will always trigger communica- tions if fitted. Normal Alarm (NA) (Key in 3) A zone programmed as ‘Normal Alarm’ will start an alarm when the system is set. 24 Hr Zone (24) (Key in 4) This zone causes an internal alarm if violated when the system is unset, and a full alarm if the system is...
  • Page 45 4. Programming Chime (C) (Key in X1) When enabled by the user, the system gives a non-alarm warning tone when any zones programmed as ‘Chime’ are opened. This facility operates only while the system is in Day. Notes: 1. ‘Chime’ is available only for Normal Alarm, Final Exit, Entry Route and Shock Analyser zone types.

  • Page 46: Change Engineer Code (Command 20)

    4. Programming adjust the sensitivity you must enter the complete com- mand, for example to change the sensitivity to 3 you must key in: X7 + 3. Change Engineer Code (Command 20) To change the Engineer access code: Make sure you are in programming mode. Key in 20 and press Y.

  • Page 47: Local Sounder Delay On Entry (Command 26)

    4. Programming Local Sounder Delay on Entry (Command 26) Use option 1 (default) to delay local sounders for silent communications when an entry alarm is triggered (required by some police forces). This option is only valid if you have programmed a Bell Delay. Use option 0 for no delay.

  • Page 48: Pa Reset (Command 34)

    Alarm Abort (Command 36) Users occasionally trigger false alarms by accident. The 9750 can be pro- grammed to allow users to abort an alarm by enabling option 1. If a user accidentally triggers an alarm while the system is set, then the control unit activates Channel 3, starts the bell delay timer and alarm abort timer.

  • Page 49: System Auto Re-Arm (Command 40)

    4. Programming system by pushing an exit terminate button connected to a keypad. Note that the exit time is infinite in this option. Option 2: Final door set. Use this option to complete setting the system by closing a door fitted with a Final Exit zone detector. Note that the exit time is infinite in this option.

  • Page 50: Csid Code (Command 50)

    4. Programming strates the volume of the tone when you enter the digit. CSID Code (Command 50) To allow the customer to use the ‘Remote Reset’ facility, you must program the control unit as ‘Engineer Reset’ (Command 33 option 1) and then install a four digit Central Station Identification (CSID) code.

  • Page 51: Abort Reset (Command 53)

    4. Programming “Installer Mode”. The system sets its internal clock/calendar to the time you have given it. Abort Reset (Command 53) Option 0 ensures that reset after abort is the same as system reset (see Command 33). Option 1 enables customer reset after an abort if they unset the system within 90 seconds of the alarm.

  • Page 52: Level B Exit Time (Command 65)

    4. Programming Level B Exit Time (Command 65) This command sets the exit time for Level B. See “Programming Commands” for options. Output Programming (Commands 81, 82 and 83) The system has three transistorised, high current, programmable outputs. Command 81 programs output 1, command 82 programs output 2 and command 83 programms output 3.

  • Page 53: Dual Ply Entry Warning (Command 86)

    “9928 Installation Guide”.) Alarm Confirmation (Command 89) Option 1 allows you to program the 9750 for Alarm Confirmation (verified alarm), if required by your local Police Intruder Alarms Policy. When a detec- tor causes an alarm the control unit activates Channel 3 (Burg). If a second detector is triggered then the control unit activates the programmed alarm confirmation channel.

  • Page 54: Load Full Defaults (Command 98)

    4. Programming Load Full Defaults (Command 98) Use this command to load default values for all commands. Enter programming mode (if you are not already there). Key in 98 Y at the keypad. Load Defaults The display shows: Press 1. (You can press X to stop the procedure if you change your mind at this stage.) Press Y.

  • Page 55: Reporting Type (Command 103)

    4. Programming then close down and dial the second telephone number and attempt to connect to the remote receiver. If received and acknowledged on this attempt, the system will close down and the alarm transmission will be complete. If the system fails to connect to the second telephone number, it will close down again and re-attempt to connect to the first telephone number.

  • Page 56: Line Integrity Checking (Command 107)

    4. Programming Entering a valid access code silences the sounders and the displays indicates a telephone line fault. The system can be set again with the line fault present. Note: Audible response is the NACOSS recommendation for line fault. If the system is set then the control unit logs the event but the keypads do not give any tone or display.

  • Page 57: Download Mode (Command 110)

    Download Mode (Command 110) The 9750 can be programmed from a PC using <Downloader> software. You can connect the PC to the control unit over the telephone network. Key in 110 Y Y to manually accept a call from the PC.

  • Page 58: Access Mode (Command 114)

    4. Programming Access Mode (Command 114) This function allows you to provide extra security when a remote PC is dialling into the system. Once the PC is connected to the system then the <Downloader> has access to all system programming commands. If you wish to provide secure access then either use Option 0 or Option 1 below.

  • Page 59: Account Number (Command 117)

    4. Programming The system can store telephone numbers up to 31 digits long. You can use the A key to insert a pause (four seconds). To enter a number: Enter programming mode (if you are not already there). Key in 115 (or 116) Y at the keypad. 115:Tel No 1_ The display shows (for example): Press Y.

  • Page 60: Fast Format Channels (Command 121)

    4. Programming Fast Format Channels (Command 121) If you selected Fast Format reporting type in command 103 then you can use command 121 to allocate one of the following events to each of the 8 chan- nels: Not used Detector Low Battery Fire Supervision Loss X1 RF Jamming...
  • Page 61 4. Programming l l u t i x s t l t t i l i a t e l l i a Figure 28. SIA Telegram Reports 496478...

  • Page 62: Modem Tone Format (Command 132)

    4. Programming The system also provides a “custom” mode which allows any combination of event information. However, you must use <Downloader> to create the combination required. SIA alarm transmissions will take considerably more telephone time than Scancom Fast format since the system transmits extended alarm data to the central station.

  • Page 63: Testing

    5. Testing 5. Testing Reading the Log (Command 90) The control unit keeps a 250 event log of recent events. Each event is represented by a two digit code, shown on the next page. To review the event log, make sure the system is in programming mode, then: Key in 90y.
  • Page 64 5. Testing Unn Znn Omit Unn Znn Unomit Fire Znn Alarm Fire Znn Rstr Fire Znn Reset PA Znn Alarm PA Znn Rstr Unn System Unset PA Knn Alarm Burg Znn Alarm Set Fail Znn Burg Znn Rstr Tamper Znn Knn Missing Knn Restore Knn Tamper...

  • Page 65: Engineer Walk Test (Command 97)

    5. Testing Engineer Walk Test (Command 97) Allows the engineer to test all devices on the system. Enter programming mode. Key in 97 Y 97: Walk Test The display shows: Open and close each alarm and tamper contact in turn. The system gives a chime tone each time you open and close a detec- tor contact.
  • Page 66 5. Testing 496478...

  • Page 67: Index

    Index 115, 116 ..............52 117 ................ 53 118, 119 ..............53 121 ..............35, 54 122 ................ 54 Symbols 126 ................ 54 131 ................ 54 132 ................ 56 143 ................ 56 20 ................40 22 ................40 23 ................40 25 ................
  • Page 68 restoring ..............37 addressing ............15 backlight ..............15 backplate ............... 12 pause ..............53 connection ............. 16 current ..............7 displays ..............41 dual key PA ............47 fitting ..............12 tamper ..............12 Audible displayed alarm ........49 input ................
  • Page 69 entering ..............27 connection ............. 23 leaving ............36, 48 sharing ..............23 re-entering ............36 contact ID .............. 56 fast format ............. 54 SIA ................ 54 Contact ID ............. 56 fast format ............. 54 after abort .............. 45 engineer ..............36 first stage ..............
  • Page 70 496478...
  • Page 71 Cooper Security Ltd Security House Xerox Business Park Mitcheldean Gloucestershire GL17 0SZ Product Support (UK) Tel: (09068) 616343 Between 09:00 and 17:30 Monday to Thursday, 09:00 to 17:00 Friday (CALLS CHARGED AT 60p PER MINUTE) Product Support Fax: (01594) 545401...
